PD-42, PD-49 & PD-55 LCD Display
User Manual
www.agneovo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD-49 and is the answer not in the manual?

Questions and answers

Related Manuals for AG Neovo PD-49

Summary of Contents for AG Neovo PD-49

  • Page 1 PD-42, PD-49 & PD-55 LCD Display User Manual www.agneovo.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ................1 Federal Communications Commission (FCC) Notice (U.S. Only) ............1 CE ................................1 Polish Center for Testing and Certification Notice ..................2 Electric, Magnetic and Electromagnetic Fields (“EMF”) ................2 Information for U.K. only ........................... 3 North Europe (Nordic Countries) Information ...................
  • Page 3 TABLE OF CONTENTS 2.3 Connecting External Equipment (DVD / DVD-B) ................26 2.3.1 Using COMPONENT Video Input ................... 26 2.3.2 Using Video Source Input ......................26 2.3.3 Using HDMI Video Input ......................27 2.4 Connecting Audio Equipment ......................27 2.4.1 Connecting External Speakers ....................
  • Page 4 6.5 Troubleshooting ..........................72 6.6 Transporting the LCD Display ......................73 CHAPTER 7: SPECIFICATIONS ..............74 7.1 Display Specifications ........................74 7.2 Display Dimensions ..........................75 7.2.1 PD-42 Dimensions ........................75 7.2.2 PD-49 Dimensions ........................76 7.2.3 PD-55 Dimensions ........................76...

  • Page 5: Safety Information

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. PD-42 / PD-49 / PD-55 WARNING: This equipment is compliant with Class A of EN55032/CISPR 32. In a residential...

  • Page 6: Polish Center For Testing And Certification Notice

    SAFETY INFORMATION Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source.

  • Page 7: Information For U.k. Only

    SAFETY INFORMATION Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: Remove fuse cover and fuse. Fit new fuse which should be a BS 1362 5A,A.S.T.A.

  • Page 8: North Europe (Nordic Countries) Information

    SAFETY INFORMATION How to connect a plug The wires in the mains lead are coloured in accordance with the following code: BLUE - “NEUTRAL” (“N”) BROWN - “LIVE” (“L”) GREEN & YELLOW - “EARTH” (“E”) • The GREEN & YELLOW wire must be connected to the terminal in the plug which is marked with the letter “E”...

  • Page 9: End-Of-Life Disposal

    SAFETY INFORMATION End-of-Life Disposal Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of. Please find out about the local regulations on how to dispose of your old display from your local dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.

  • Page 10: Turkey Rohs

    SAFETY INFORMATION E-Waste Declaration for India This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment .

  • Page 11: Precautions

    PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN Symbols used in this manual This icon indicates the existence of a potential hazard that could result in personal injury or damage to the product. This icon indicates important operating and servicing information. Notice •...

  • Page 12: Cautions When Using

    PRECAUTIONS Cautions When Using • Use only the power cord supplied with the LCD display. • The power outlet should be installed near the LCD display and Warning: be easily accessible. • If an extension cord is used with the LCD display, ensure that the Unplug the power cord from the power outlet and total current consumption plugged into the power outlet does not...

  • Page 13: Notice For The Lcd Display

    PRECAUTIONS Notice for the LCD Display • In order to maintain the stable luminous performance, it is recommended to use low brightness setting. • Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease with time.

  • Page 14: Chapter 1: Product Description

    CHAPTER 1: PRODUCT DESCRIPTION 1.1 Package Contents When unpacking, check if the following items are included in the package. If any of them is missing or damaged, contact your dealer. LCD Display Note: Quick start guide Remote control ♦ Remote control is shipped with the supplied AAA batteries.

  • Page 15: Preparing For The Installation

    PRODUCT DESCRIPTION 1.2 Preparing for the Installation • Due to the high power consumption, always use the plug exclusively designed for this product. If an extended line is Warning: required, please consult your service agent. • The product should be installed on a flat surface to avoid tipping. ♦...

  • Page 16: Wall Mounting Installation

    400mm kit. Failure to follow correct mounting procedures could result in damage to the equipment or injury to the user or installer. Product warranty 400mm does not cover damage caused by improper installation. PD-49 400mm 400mm PD-55...

  • Page 17: Vesa Grid

    For wall or ceiling installation, we recommend installing the ♦ Unit weight= 15.3 kg (PD- display with metal brackets which are commercially available. For 42),19.0 kg (PD-49) or 24.7 kg detailed installation instructions, refer to the guide received with the (PD-55). The equipment and respective bracket.

  • Page 18: Mounting In Portrait Position

    PRODUCT DESCRIPTION 1.5 Mounting in Portrait Position This display can be installed in portrait position. Remove the table stand, if attached. Rotate 90 degrees counter-clockwise. 1.6 Using the Remote Sensor and Power Status Indicator • If you want to obtain a better reception of remote control function, please adjust the indicator location to easily check the power status indicator.

  • Page 19: Lcd Display Overview

    PRODUCT DESCRIPTION 1.7 LCD Display Overview 1.7.1 Control Panel PD-42 PD-49...
  • Page 20 PRODUCT DESCRIPTION PD-55 [ ] Down [ ] Power Move the highlight bar down to adjust Turn the display on or put the display the selected item while OSD menu is to standby. MUTE MENU Switch the audio mute ON/OFF. •...

  • Page 21: Input/Output Terminals

    PRODUCT DESCRIPTION 1.7.2 Input/Output Terminals 13 14 15 16 PD-42 13 14 15 16 PD-49...
  • Page 22 PRODUCT DESCRIPTION 13 14 15 16 PD-55...
  • Page 23 PRODUCT DESCRIPTION AC IN DisplayPort IN/ DisplayPort OUT AC power input from the wall outlet. DisplayPort video input / output. Main power switch VGA IN (D-Sub) Switch the main power on/off. VGA video input. IR IN/ IR OUT COMPONENT IN (BNC) &...

  • Page 24: Remote Control

    PRODUCT DESCRIPTION 1.8 Remote Control 1.8.1 General Functions POWER Turn the display on or to put the display into standby mode. PLAY Control playback in multimedia mode. ] SOURCE Choose input source. Press the button to choose from USB, Network, HDMI 1, HDMI 2, DisplayPort, Card OPS, DVI-D, YPbPr, AV, or VGA.

  • Page 25: Id Remote Control

    PRODUCT DESCRIPTION 1.8.2 ID Remote Control To set the remote control ID: Press the ID button. The red LED blinks You can set the remote control ID when you twice. want to use this remote control on one of several Press the ID SET button for 3 seconds different displays.

  • Page 26: Inserting The Batteries In The Remote Control

    PRODUCT DESCRIPTION 1.8.3 Inserting the Batteries in the Remote Control Caution: The remote control is powered by two 1.5V AAA batteries. The incorrect use of batteries can To install or replace batteries: result in leaks or bursting. Be sure to follow these instructions: Press and then slide the cover to open it.

  • Page 27: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS 2.1 Connecting the Power Connect one end of the power cord to the AC IN connector at the rear of the LCD display. Connect the other end of the power cord to a power outlet or a power supply. Set the Main Power switch to ON.

  • Page 28: Connecting A Computer

    MAKING CONNECTIONS 2.2 Connecting a Computer 2.2.1 Using VGA Input Connect one end of a D-sub cable to the VGA IN connector of the LCD display and the other end of a D-sub cable to the VGA OUT (D-Sub) connector of the computer. For audio input, connect one end of an audio cable to the AUDIO IN connector of the LCD display and the other end of an audio cable to the AUDIO OUT connector of the computer.

  • Page 29: Using Hdmi Input

    MAKING CONNECTIONS 2.2.3 Using HDMI Input Connect one end of an HDMI cable to the HDMI1 IN/ HDMI2 IN connector of the LCD display and the other end of an HDMI cable to the HDMI OUT connector of the computer. Computer RJ-45 HDMI1 IN...

  • Page 30: Connecting External Equipment (Dvd / Dvd-B)

    MAKING CONNECTIONS 2.3 Connecting External Equipment (DVD / DVD-B) 2.3.1 Using COMPONENT Video Input Connect one end of a component cable to the COMPONENT IN connector of the LCD display and the other end of a component cable to the COMPONENT OUT connectors of the video player (DVD / DVD-B). For audio input, connect one end of an audio cable to the AUDIO IN connectors of the LCD display and the other end of an audio cable to the AUDIO OUT connectors of the video player (DVD / DVD-B).

  • Page 31: Using Hdmi Video Input

    MAKING CONNECTIONS 2.3.3 Using HDMI Video Input Connect one end of an HDMI cable to the HDMI1 IN/ HDMI2 IN connector of the LCD display and the other end of an HDMI cable to the HDMI out connector of the video player (DVD / DVD-B). RJ-45 HDMI1 IN HDMI2 IN...

  • Page 32: Connecting An External Audio Device

    MAKING CONNECTIONS 2.4.2 Connecting an External Audio Device Connect one end of an audio cable to the AUDIO OUT connector of the LCD display and the other end of an audio cable to the AUDIO IN connector of the audio device. AUDIO AUDIO IN Audio Device...

  • Page 33: Connecting Multiple Displays In A Daisy-Chain Configuration

    MAKING CONNECTIONS 2.5 Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a video wall. Caution: To avoid unnecessary strain on the bezel, it is highly recommended to keep a minimum space of 0.5mm in which a business card is able to slip between all displays on all sides.
  • Page 34 MAKING CONNECTIONS Connect the DisplayPort OUT connector of DISPLAY 1 to the DisplayPort IN connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [DP] [DP IN] [DP OUT] [DP IN] Note: ♦ Before selecting the DisplayPort 1.1a (DP 1.1a) version, make sure the Tiling > Enable setting is set to Off.

  • Page 35: Analog Video Connection

    MAKING CONNECTIONS 2.5.3 Analog Video Connection Connect the DVI OUT connector of DISPLAY 1 to the VGA IN connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [VGA] [VGA IN] [DVI OUT] [VGA IN] 2.6 IR Connection Connect the IR sensor cable to the IR IN connector of the LCD display. External IR Receiver DISPLAY...

  • Page 36: Ir Pass-Through Connection

    MAKING CONNECTIONS 2.7 IR Pass-Through Connection Connect one end of an IR extender cable to the IR OUT connector of the LCD display and the other end of an IR extender cable to the IR IN connector of the video player (DVD / DVD-B). [IR OUT] DISPLAY DVD / DVD-B...

  • Page 37: Chapter 3: Using The Lcd Display

    CHAPTER 3: USING THE LCD DISPLAY 3.1 Turning on the Power POWER button Plug the power cord to a power Note: outlet or power supply. ♦ The LCD display still consumes Press the button to turn the power as long as the power cord is connected to the power LCD display on.

  • Page 38: Adjusting The Volume

    USING THE LCD DISPLAY 3.3 Adjusting the Volume Note: ♦ After pressing the button, the volume icon is displayed on the screen VOLUME buttons automatically. ♦ Press the button to mute the Press the button to adjust the volume. audio. 3.4 Changing the Picture Format Note: The available picture formats...

  • Page 39: Choosing Your Preferred Picture Settings

    USING THE LCD DISPLAY 3.5 Choosing Your Preferred Picture Settings Note: The available picture styles include: ♦ Personal: Apply your personalised picture settings. ♦ Vivid: Rich and dynamic settings, ideal for daytime viewing. ♦ Natural: Natural picture settings. ADJUST button ♦...

  • Page 40: Playing Multimedia Files Via Local Area Network

    USING THE LCD DISPLAY 3.7 Playing Multimedia Files via Local Area Network To play files via Local Area Network, you will need: • A wired home network, connected with a Universal Plug and Play (uPnP) router. • Optional: A LAN cable that connects your display to your home network. •...

  • Page 41: How To Use Dlna-Dmp

    USING THE LCD DISPLAY Set Up Media Sharing Install a media server on your computer to share media files. These are some media servers: • For PC: Windows Media Player 11 (or higher) or TVersity • For Mac: Twonky Switch on media sharing on your computer using the media server. For more information on how to set up the media server, refer to the website of the media server.

  • Page 42: How To Use Dlna-Dmr From Pc

    USING THE LCD DISPLAY 3.7.3 How to Use DLNA-DMR from PC Press the button. Then choose Network settings and press the button. Picture View network settings Sound Network configuration Tiling Static IP configuration General settings Digital Media Render... Network settings Network name Set the Digital Media Renderer -DMR setting to On.

  • Page 43: Playing Multimedia Files From Usb Device

    USING THE LCD DISPLAY Now, go to the directory of your media files. Choose the media file by right click. On the submenu from Play To, You can find all displays connected to your network. Choose the display, and click the media file to play.
  • Page 44 USING THE LCD DISPLAY Press the button to enter the USB mode. USB device 1 By default, it displays the files in Folder view. Movie Video_001.mp4 Music Video_002.mp4 Photo Video_003.mp4 System Volume Information USB device Options Press the button to go up the top layer in the screen. Then press the button to select the desired file type: Music,...

  • Page 45: Play Options

    USING THE LCD DISPLAY 3.9 Play Options 3.9.1 Playing Music Files Choose Music in the top bar. Music Choose one music track, and press the button. Blackout (Promo) 1. Song_001 03:09 2. Song_002 03:32 3. Song_003 04:15 4. Song_004 03:15 Music >...

  • Page 46: Playing Movie Files

    USING THE LCD DISPLAY 3.9.2 Playing Movie Files Choose Movie in the top bar. Movie Choose a video, and press the button. Others Video_001.mp4 Video_002.mp4 Video_003.mp4 01:10:03 01:50:03 00:30:15 1020.51MB 1785.41MB 458.20MB 2017-03-28 2017-03-28 2017-03-28 Movie > Video_001.mp4 Info Play All Sort USB device Options...

  • Page 47: Playing Photo Files

    USING THE LCD DISPLAY 3.9.3 Playing Photo Files Choose Photo in the top bar. Photo Choose a photo thumbnail, then press the button. Mar. 28.2017 Photo > Img_001.jpg Info Play All Sort USB device Options Start a Slideshow button to Play All. If there are multiple photos in a folder, choose a photo.

  • Page 48: Chapter 4: On Screen Display Menu

    CHAPTER 4: ON SCREEN DISPLAY MENU 4.1 Using the OSD Menu Operation Menu Navigation Control Panel Remote Control Press the MENU Display the main menu screen. Press the button. button. Picture Picture style Sound Restore style Tiling Backlight General settings Colour Network settings Sharpness...
  • Page 49 ON SCREEN DISPLAY MENU Operation Menu Navigation Control Panel Remote Control Exit the submenu. Press the button Press the button to return to to return to the the previous menu. previous menu. Close the OSD window. Press the MENU Press the button button again.

  • Page 50: Osd Menu Tree

    ON SCREEN DISPLAY MENU 4.2 OSD Menu Tree Picture Picture style Sound Restore style Tiling Backlight General settings Colour Network settings Sharpness Noise reduction MPEG artifact reducti... Digital Crystal Clear Advanced Game or computer HDMI input range Main Menu Submenu Remarks 1.
  • Page 51 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 4. General settings • Menu language See page 55. • Monitor ID • Auto search • Clock • Scheduling • Sleep timer • EasyLink • Auto adjust (for VGA input only) • Local KB lock •...

  • Page 52: Chapter 5: Adjusting The Lcd Display

    CHAPTER 5: ADJUSTING THE LCD DISPLAY 5.1 Picture Settings 1 Press the MENU button on the control Picture Picture style panel or the button on the remote Sound Restore style control to call out the OSD window. Tiling Backlight General settings Colour 2 Select Picture, then press the INPUT Network settings...
  • Page 53 ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjust the noise reduction to help Press the button on the Minimum remove noise from images. This control panel or the / button on the helps produce clearer and crisper Medium remote control to select the setting. images.
  • Page 54 ADJUSTING THE LCD DISPLAY Item Function Operation Range • Color temp.: Change the colour balance. - Cool: Applies a bluish tint for cooler colours. Cool - Normal: commonly used for normal Press the button on the Normal lighting conditions. control panel or the / button on the Warm - Warm: Applies a reddish tint for remote control to select the setting.
  • Page 55 ADJUSTING THE LCD DISPLAY Item Function Operation Range • Game: Choose when viewing content from a connected game console. • Computer: Choose when a Press the button on the Game or computer is connected through Game control panel or the / button on the computer HDMI.

  • Page 56: Sound Settings

    ADJUSTING THE LCD DISPLAY 5.2 Sound Settings 1 Press the MENU button on the control Picture Sound style panel or the button on the remote Sound Restore style control to call out the OSD window. Tiling Bass General settings Treble 2 Select Sound, then press the INPUT Network settings Balance...

  • Page 57: Tiling Settings

    ADJUSTING THE LCD DISPLAY Item Function Operation Range • Auto volume leveling: Enable Press the button on the the reduction of sudden volume control panel or the / button on the changes. remote control to select the setting. Press the button on the •...
  • Page 58 ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjust the position of this display Press the button on the in the screen matrix. Please see 0 to 10 control panel or the / button on the the Example1 and Example2 for remote control to adjust the value.

  • Page 59: General Settings

    ADJUSTING THE LCD DISPLAY 5.4 General Settings 1 Press the MENU button on the control Picture Menu language panel or the button on the remote Sound Monitor ID control to call out the OSD window. Tiling Auto search General settings Clock 2 Select General settings, then press Network settings...
  • Page 60 ADJUSTING THE LCD DISPLAY Item Function Operation Range Set the current date and time for the display’s internal clock. Press the button on the Daylight • Daylight saving: Choose the saving time control panel or the / button on the daylight saving time.
  • Page 61 ADJUSTING THE LCD DISPLAY Item Function Operation Range HDMI 1 HDMI 2 Display port Press the button on the • Source: Choose the source for Card OPS control panel or the / button on the the schedule. DVI-D remote control to select the setting. YPbPr •...
  • Page 62 ADJUSTING THE LCD DISPLAY Item Function Operation Range • Play setting: Choose the file to be included in the playlist. Note: ♦ Each playlist supports up to 30 files. ♦ Playlist will not be cleared after Factory settings. You have to manually remove the files or delete usb_schedulinglist.txt on the USB disk drive.
  • Page 63 ADJUSTING THE LCD DISPLAY Item Function Operation Range Use this function to automatically Press the button on the optimize the display of VGA input Cancel control panel or the button image. Auto adjust Start on the remote control to select the Note: This option is available only if setting.
  • Page 64 ADJUSTING THE LCD DISPLAY Item Function Operation Range Choose to enable or disable the button function of the remote control. • Unlock: Enable the button function of the remote control. • Lock all: Lock all button functions of the remote control. Unlock •...
  • Page 65 / button on the their ID number when multiple remote control to adjust the value. displays are connected. When enabled, the AG Neovo Press the button on the Logo logo will be shown on the startup control panel or the / button on the screen.
  • Page 66 ADJUSTING THE LCD DISPLAY Item Function Operation Range Set the cooling fan operation. • Off: Cooling fan is turned off. • On: Cooling fan is turned on all the time during the LCD display is in operation. • Auto: Cooling fan turns on when the LCD display temperature reaches 60°C (140°F).

  • Page 67: Network Settings

    ADJUSTING THE LCD DISPLAY 5.5 Network Settings 1 Press the MENU button on the control Picture View network settings panel or the button on the remote Sound Network configuration control to call out the OSD window. Tiling Static IP configuration General settings Digital Media Render...
  • Page 68 ADJUSTING THE LCD DISPLAY Item Function Operation Range Enable this function to allow the Digital Media Press the button on the display to receive multimedia files Renderer - control panel or the / button on the from the connected device from the remote control to select the setting.

  • Page 69: Chapter 6: Appendix

    CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution or the the graphics card of the computer refresh rate of the graphics Cannot display this video mode is set too high. card.

  • Page 70: Usb Device Compatibility

    APPENDIX 6.2 USB Device Compatibility USB Video Subtitle Formats (for language subtitles, etc.). Max. Bit File Video Maximum Max. Frame Rate Rate Container Audio codec Extensions codec resolution (fps) (Mbps) MPEG-1 1920x1080 25p,30p,50i,60i MPEG- 1(L1&L2), MPEG-2 1920x1080 25p,30p,50i,60i .mpg MPEG-4 MPEG-1,2,2.5 1920x1080 25p,30p,50i,60i...
  • Page 71 APPENDIX Max. Bit File Video Maximum Max. Frame Rate Rate Container Audio codec Extensions codec resolution (fps) (Mbps) MPEG- 1(L1&L2), 1920x1080i@field MPEG-1,2,2.5 rate=50, 60Hz 1920x1080p@frame .m2ts AVCHD AAC/HE-AAC rate=24, 25,30Hz .mts (v1&v2), 1280x720p @ frame AC3,E-AC3, rate=50, 60Hz Dolby Pulse .m4v H.264 1920x1080...
  • Page 72 APPENDIX USB Multimedia Formats Frequency Max. Bit Rate File Maximum Container Video codec Audio codec Extensions resolution (kHz) (Mbps) MPEG-1,2,2.5 .mp3 .wma (V2 up to .asf V9.2) WMA,WMA .wma WMA Pro .wav(PC) LPCM LPCM .aif(mac) LPCM LPCM .aiff(mac) .aac AAC,HE- .mp4 1024 AAC(v1&v2)

  • Page 73: Supported Resolution

    APPENDIX 6.3 Supported Resolution VGA Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz Wide Video Graphic WVGA 70 Hz 33.75 MHz...

  • Page 74: Cleaning

    APPENDIX UHDTV Resolution: Active Resolution Refresh Rate Pixel Rate Aspect Ratio Stand for Mode UHDTV H Pixels V Lines Resolution 3840 2160 30 Hz 297 MHz 16:9 Video wall application. Note: ♦ UHD resolution is supported only on video wall arrays. Each individual LCD display supports a max resolution of 1080p.
  • Page 75 APPENDIX Cabinet Cleaning Instructions • If the cabinet becomes dirty, wipe the cabinet with a soft, dry cloth. • If the cabinet is extremely dirty, soak a lint-free cloth in a mild detergent solution. Wring the cloth to remove as much moisture as possible. Wipe the cabinet. Use another dry cloth to wipe over until the surface is dry. •...

  • Page 76: Troubleshooting

    APPENDIX 6.5 Troubleshooting Symptom Possible Cause Remedy No picture is displayed • The main power switch on 1 Plug in the power cord. the back of the display is not 2 Make sure the power switch is switched on. switched on. •...

  • Page 77: Transporting The Lcd Display

    APPENDIX 6.6 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. 1 Put all the accessories in the box (if necessary). 2 Place the lower foam cushion inside the lower box (a). 3 Place the LCD display down in the lower box.

  • Page 78: Chapter 7: Specifications

    CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications PD-42 PD-49 PD-55 Panel Panel Type LED-Backlit TFT LCD LED-Backlit TFT LCD LED-Backlit TFT LCD (IPS Technology) (IPS Technology) (IPS Technology) Panel Size 41.9" 48.5" 54.6" Max. Resolution FHD 1920 x 1080 FHD 1920 x 1080...

  • Page 79: Display Dimensions

    SPECIFICATIONS PD-42 PD-49 PD-55 Dimensions Product w/o Base 946.9 x 541.0 x 71.1 mm 1092.8 x 623.0 x 71.1 mm 1228.6 x 699.4 x 71.1 mm (W x H x D) (37.3” x 21.3” x 2.8”) (43.0” x 24.5” x 2.8”) (48.4”...

  • Page 80: Dimensions

    (outline dimension) 1228.6 71.1 (opening dimension) 1215.6 56.8 414.3 414.3 4-M6*10L 266.3 266.3 AG Neovo Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan. Copyright © 2021 AG Neovo. All rights reserved. PD-42/49/55 Eprel registration number: 532065/532080/431802 PD5500/PD4900/PD4200_UM_V012...
