Summary of Contents for AG Neovo PN-46D
- Page 1 PN-46D / PN-55H Digital Signage Display...
- Page 2 Disclaimer This company makes no representations or warranties, either expressed or implied, with respect to the contents of this document. This company reserves the right to revise this publication and to make changes from time to time in the contents thereof without obligation to notify any person of such revision or changes.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Safety warnings and precautions .......... 1 Important safety instructions ..........2 Notes on the LCD panel of this display..........2 Safety notice for remote control ............3 Battery safety notice ................3 Notes on moving the display..............4 Package contents .............. - Page 4 Table of Contents Dimensions ..................35 Supported input signal resolution............37 Supported PBP input signal combination........... 39 Troubleshooting..............40...
-
Page 5: Safety Warnings And Precautions
Safety warnings and precautions Safety warnings and precautions THIS EQUIPMENT MUST BE GROUNDED To ensure safe operation, the three- pin plug must be inserted only into a standard three-pin power outlet which is effectively grounded through normal household wiring. The lightning flash with arrowhead Extension cords used with the symbol, within an equilateral triangle, equipment must have three cores... -
Page 6: Important Safety Instructions
Important safety instructions Important safety instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. -
Page 7: Safety Notice For Remote Control
Important safety instructions • LCD screens, like plasma (PDP) and conventional CRT (Cathode Ray Tube) screens, are also susceptible to 'screen burn-in' or 'image retention' which can be found on the screen as visible fixed lines and shades. To avoid such damage to the screen, avoid displaying still images (like On-Screen Display menus, TV station logos, fixed/inactive text or icons) for more than two hours. -
Page 8: Notes On Moving The Display
Important safety instructions Notes on moving the display The display has limited mechanical strength. To prevent the display from performance failure caused by line defects, front bezel bending, glass scratch/ broken, light leakage, etc., it must be handled with care. •... -
Page 9: Package Contents
Package contents Package contents Open the sales package and check the contents. If any item is missing or damaged, please contact your dealer immediately. D-Sub (15-pin) LCD display Power cord Remote control cable AAA batteries User manual CD IR cables Note •... -
Page 10: Setting Up The Display
2. Gently lay the display on the cloth with the LCD screen facing down. 3. Remove the desktop stands from the display if installed. 4. Identify the wall mounting screw holes on the back of the display as shown in the illustration. PN-46D PN-55H 400mm 400mm (15.75”) - Page 11 Setting up the display Note • To maintain proper ventilation, keep at least 10 mm 10mm (0.39") of clear space from the back cover of the display to the wall. • Please consult a professional technician for wall mount installations. The manufacturer accepts no liability for installations not performed by a professional technician.
-
Page 12: Parts Of The Display And Their Functions
Parts of the display and their functions Parts of the display and their functions Rear panel PN-46D PN-55H Name Description • Receives command signals from the remote control. • Detects ambient lighting conditions around the display and adjusts screen brightness automatically when the Ambient Light Sensor function is activated. - Page 13 Parts of the display and their functions Indicates the power status of the display: - Lights up green when the power is turned on. - Lights up red when the display is turned off. - Lights up red when the display is in Power Save Power indicator High mode.
-
Page 14: Input/Output Terminals
Parts of the display and their functions Input/output terminals PN-46D PN-55H RS-232C-OUT RS-232C-IN 10 11 12 Name Description RJ-45 Connects to the RJ-45 port on your Ethernet or router. For external control and multi-display operation. • RS232C IN: receives control signals from a computer or RS232C IN/OUT another display. - Page 15 Parts of the display and their functions Receives analog RGB signals from an external device (such VGA IN as a computer). AUDIO IN Receives audio signals from an external device (such as a (AUDIO1) computer). AUDIO IN Receives audio signals from an external device (such as a (AUDIO2) VCR or DVD player).
-
Page 16: Remote Control
Parts of the display and their functions Remote control INFO Shows the current input source and resolution. Numeric buttons (1-9) /Input source buttons • Performs as numeric buttons when the OSD menu is on. • Performs as input source buttons when the OSD menu is off. -
Page 17: Using The Remote Control
In this situation, change the light source, readjust the angle of the display or operate the remote control from a location closer to display’s remote control sensor window. PN-46D Max. 10 m (32.8 feet) -
Page 18: Connection
Connection Connection Connecting audio/video signals Pay attention to the following notes when you connect cables: • Please turn off all devices. • Familiarize yourself with the audio/video ports on the display and the devices you want to use. Be aware that incorrect connections may adversely affect picture quality. -
Page 19: Connecting The Digital Input
Connection Connecting the digital input 1. Connect the DVI-IN jack on the display to the DVI-D output jack on a computer using a DVI-D cable. If the computer has a DisplayPort/HDMI output jack, con- nect the computer’s DisplayPort/HDMI output jack to the DISPLAY PORT/ HDMI-1/HDMI-2 input jack on the display using a DisplayPort/HDMI cable or a DVI-D to HDMI conversion cable. -
Page 20: Connecting The Ypbpr Component Video Input
Connection Connecting the YPbPr component video input 1. Connect the VIDEO IN (YPbPr) jacks on the display to the component output jacks on an A/V device (such as a VCR or DVD player) using a component video cable. 2. Connect the DVD player’s audio output jacks to the AUDIO IN (AUDIO2) jacks on the display using a suitable audio cable. - Page 21 Connection Connecting the AV and S-Video inputs 1. Connect the VIDEO IN (S-VIDEO) or AV IN jack on the display to the output jack on an A/V device (such as a VCR) using an appropriate video cable. 2. Connect the VCR’s audio output jacks to the AUDIO IN jacks on the display using a suitable audio cable.
-
Page 22: Connecting External Speakers
Connection Connecting external speakers The built-in amplifier on the display allows you to output audio signals through external speakers. Connect external speakers to the SPEAKERS (R/L) jacks on the display. RS-232C-OUT RS-232C-IN External speakers Note: You can use the remote control or the control panel on the display to adjust the volume. -
Page 23: Connecting Multiple Displays
Connection Connecting multiple displays You can connect multiple displays serially (daisy chain) to a computer for management. The number of displays you can connect serially depends on the resolution of the input signal you use. Additional display RS-232C-OUT RS-232C-IN RS-232C D-Sub (15-pin) IR cable cable... -
Page 24: Connecting Power
Connection Connecting power 1. Plug one end of the power cord into the AC IN jack on the display and the other end into an appropriate power outlet (if the outlet is switched, turn on the switch). 2. Press the power switch to turn on the main power. Note •... -
Page 25: Basic Operations
Basic operations Basic operations Turning the display on or off To turn on or off the display, press the power button on the display’s control panel or on the remote control. Note • The display’s standby mode still consumes power. To completely cut off power supply, set the power switch to the off position or disconnect the power cord from the power outlet. -
Page 26: Network Connection
Network connection Network connection Connecting to a LAN To set the display to connect to a local area network: 1. Connect a RJ45 cable to the corresponding ports on the display and your LAN switch or router. 2. Enter the OSD menu Setting > Control Setting. Select LAN. 3. -
Page 27: The Osd (On-Screen Display) Menu
The OSD (On-Screen Display) menu The OSD (On-Screen Display) menu OSD menu overview Menu name Options/functions See page • Picture Mode • Backlight • Contrast • Brightness • Chroma Picture • Phase • Sharpness • Color Temp. • Noise Reduction •... -
Page 28: Operations In The Osd Menu
The OSD (On-Screen Display) menu Operations in the OSD menu Using the control panel buttons Using the remote control 1. Press MENU to open the OSD 1. Press MENU to open the OSD menu. menu. ENTER VIDEO SOURCE 2. In the OSD menu, press or to 2. -
Page 29: Picture Menu
The OSD (On-Screen Display) menu Picture menu Picture Picture Mode Standard Backlight Contrast Brightness Chroma Phase Sharpness Color Temp. Cool Noise Reduction Film Mode Auto Reset :Move :Exit :Enter EXIT ENTER Name Description Picture Mode Sets the display mode. Adjusts the backlight intensity for the screen. Backlight Note: This feature is not available if the Ambient Light Sensor or Adaptive Contrast function is set to On. -
Page 30: Sound Menu
The OSD (On-Screen Display) menu Sound menu Sound Sound Mode Standard Treble Bass Balance Center Surround Speaker Internal Audio Source Audio1 Reset :Move :Exit :Enter EXIT ENTER Name Description Adjusts the sound output from the speakers. Dynamic: Enhances treble and bass. Sound Mode Standard: Flat settings. - Page 31 The OSD (On-Screen Display) menu Screen menu Screen PAP Setting Display Wall Aspect Full Adjust Screen Freeze :Move :Exit :Enter EXIT ENTER Name Description • PAP: Turns on or off the PIP (Picture in Picture) and PBP (Picture by Picture) functions. •...
- Page 32 The OSD (On-Screen Display) menu • Full: Enlarges the picture horizontally to fill the screen when the picture source is 4:3 (Standard definition). When the picture source is 16:9 (High definition), it displays in the same 16:9 aspect ratio. • 4:3: Displays all picture source in 4:3 aspect ratio. •...
- Page 33 The OSD (On-Screen Display) menu • Auto Adjustment: Sets whether to optimize image display for each VGA input. • Phase: Adjusts the phase of the VGA input image. • Clock Frequency: Adjusts the clock frequency of the VGA input Adjust Screen image.
-
Page 34: Setting Menu
The OSD (On-Screen Display) menu Setting menu Setting Language English Schedule Power Save High Control Setting RS-232C Network Settings Set Monitor ID HDMI Control Advanced Information All Reset :Move :Exit :Enter EXIT ENTER Name Description Language Sets your preferred language for the OSD menu. •... - Page 35 The OSD (On-Screen Display) menu • RS-232C/LAN: Sets a terminal to control the display. • IR Passthrough: Select it when multiple displays are connected via RS-232C cables. - Primary: Designate the display as the primary unit for remote control operation. Only this display will be operated by the remote Control control.
- Page 36 The OSD (On-Screen Display) menu • Auto Search: Automatically detects available input sources. • Auto Adjustment: Automatically optimizes image display for the VGA input. • Overscan: Turns the overscan function on or off. • RGB Signal: Sets the type of signal for a piece of video equipment or PC connected to the HDMI of the display •...
-
Page 37: Product Information
Product information Product information Specifications Model PN-46D PN-55H Item Specifications Backlight D-LED Panel size 46" 55” Pixel pitch (mm) 0.53025 0.630 Native resolution 1920 x 1080 (pixels) LCD panel Brightness (cd/m (typical) Contrast (typical) 4000:1 1400:1 Response time (ms) (typical) Color depth 1.07 billion... - Page 38 Product information Weight (kg), approximate value Mechanical Dimensions 1023.68 x 578.27 x 1215.2 x 686 x 115.25 111.8 (W x H x D) (mm) Note: Specifications and functions are subject to change without notice.
-
Page 39: Dimensions
Product information Dimensions PN-46D 578.27 311.14 312.54 244.64 246.04 Unit: mm... - Page 40 Product information PN-55H 406.9 408.3 569.8 323.4 Unit: mm...
-
Page 41: Supported Input Signal Resolution
Product information Supported input signal resolution Input source Resolution Display S-Video YPbPr HDMI Port 640 x 480 @ 60Hz 640 x 480 @ 72Hz 640 x 480 @ 75Hz 720 x 400 @ 70Hz 800 x 600 @ 60Hz 800 x 600 @ 75Hz 1024 x 768 @ 60Hz 1024 x 768 @ 75Hz 1280 x 768 @ 60Hz... - Page 42 Product information 1080i (50Hz) 1080i (60Hz) 1080p (50Hz) 1080p (60Hz) Note • : supported • Blank: not supported...
-
Page 43: Supported Pbp Input Signal Combination
Product information Supported PBP input signal combination Main/Left picture signal source Display S-Video YPbPr HDMI Port S-Video YPbPr Sub/ Right picture signal source HDMI Display Port... -
Page 44: Troubleshooting
Troubleshooting Troubleshooting Problem Solution Check the following: • Is the display turned on? Check the power indicator of the display. • Is the signal source device turned on? Turn on the device and try again. • Are there any loose cable connections? Make sure that all cables are connected firmly. - Page 45 Troubleshooting • Have you locked the remote control function? Unlock the function and try again. • Check for incorrect battery orientation. • Check for dead batteries. • Check your distance and angle from the display. • Check whether remote control is properly being pointed at the display’s remote control sensor window.
