AG Neovo PS Series User Manual

Led-backlit display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PS-Series LED-Backlit Display
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS Series and is the answer not in the manual?

Questions and answers

Related Manuals for AG Neovo PS Series

Summary of Contents for AG Neovo PS Series

  • Page 1 PS-Series LED-Backlit Display User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ..................... 4 REGULATORY INFORMATION ................... 6 CHAPTER 1: UNPACKING AND INSTALLATION ............11 1.1. Unpacking ........................11 1.2. Package Contents ......................11 1.3. Installation Notes ......................11 1.4. Installing and Removing Table Stands (optional) ............12 1.4.1.
  • Page 3 TABLE OF CONTENTS OSD Menu Overview ...................... 27 4.2.1 PICTURE menu ....................27 4.2.2 SCREEN menu ....................28 4.2.3 AUDIO menu ....................... 31 4.2.4 PIP menu ......................31 CHAPTER 5: INPUT MODE ....................42 VGA Resolution ......................42 SDTV Resolution ......................42 HDTV Resolution ......................

  • Page 4: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION Warnings and Precautions KNOW THESE SAFETY SYMBOLS CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact with any inside part of this product.
  • Page 5 SAFETY INFORMATION Read and follow follow these instructions when connecting and using your Public Information Display: • Unplug the display if you are not going to use it for an extensive period of time. • Unplug the display if you need to clean it with a slightly damp cloth. The screen many be wiped with a dry cloth when the power is off.

  • Page 6: Regulatory Information

    REGULATORY INFORMATION REGULATORY INFORMATION CE Declaration of Conformity We declare under our responsibility that the product is in conformity with the following standards: • EN60950-1:2006 (Safety requirement of Information Technology Equipment) • EN55022:2006+A1:2007 (Radio Disturbance requirement of Information Technology Equipment) •...
  • Page 7 REGULATORY INFORMATION Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, monitor, printer, and so on) should have the same power supply source. The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A).
  • Page 8 REGULATORY INFORMATION Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. IMPORTANT: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: Remove fuse cover and fuse. Fit new fuse which should be a BS 1362 5A,A.S.T.A.
  • Page 9 REGULATORY INFORMATION North Europe (Nordic Countries) Information Placering/Ventilation VARNING: FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS. Placering/Ventilation ADVARSEL: SØRG VED PLACERINGEN FOR, AT NETLEDNINGENS STIK OG STIKKONTAKT ER NEMT TILGÆNGELIGE. Paikka/Ilmankierto VAROITUS: SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA.
  • Page 10 REGULATORY INFORMATION Attention users in United States: Like all LCD products, this set contains a lamp with Mercury. Please dispose of according to all Local, State and Federal Laws. For the disposal or recycling information, contact: www. mygreenelectronics.com or www.eiae.org. End of Life Directives-Recycling Your new Public Information Display contains several materials that can be recycled for new users.

  • Page 11: Chapter 1: Unpacking And Installation

    CHAPTER 1: UNPACKING AND INSTALLATION CHAPTER 1: UNPACKING AND INSTALLATION 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Due to the size and weight of this display it is recommended for two people to move it. •...

  • Page 12: Installing And Removing Table Stands (Optional)

    UNPACKING AND INSTALLATION 1.4. Installing and Removing Table Stands (optional) 1.4.1. To install table stands Ensure your display is powered off. Spread a protective sheet on a flat surface. Grab the carrying handles and place the display face-down on the protective sheet. After inserting the stand in the guide block, tighten the screws on both sides of the display. NOTE: The longer side of the stand should face the front of the display.

  • Page 13: Mounting On A Wall

    UNPACKING AND INSTALLATION 1.5. Mounting on a Wall To mount this display to a wall, you will have to obtain a standard wall-mounting kit (commercially available). We recommend using a mounting interface that complies with TUV-GS and/or UL1678 standard in North America. Protective Sheet Table Tabletop stand...

  • Page 14: Ventilation Requirements For Enclosure Locating

    UNPACKING AND INSTALLATION 1.5.2. Ventilation Requirements for enclosure locating To allow heat to disperse, leave space between surrounding objects as shown in the diagram below. 100 mm 100 mm 100 mm 100 mm...

  • Page 15: Chapter 2: Parts And Functions

    CHAPTER 2: PARTS AND FUNCTIONS CHAPTER 2: PARTS AND FUNCTIONS 2222 Control Panel MUTE INPUT MENU POWER button NOTE: “Keyboard Control Lock Mode” Use this button to turn the display on or put This function completely disables the display to standby. the access to all Keyboard Control MUTE button functions.
  • Page 16 PARTS AND FUNCTIONS • Indicates the operating status of the display with OPS: Lights green when the display is on, but the OPS is off Lights blue when the display and the OPS is on Lights red when the display is in standby mode Lights amber when the display enters APM mode When { SCHEDULE} is enabled, the light blinks green and red...

  • Page 17: Input/Output Terminals

    PARTS AND FUNCTIONS 2.2. Input/Output Terminals 9 10 12 13 AC IN VGA IN (D-Sub) AC power input from the wall outlet. VGA video input. MAIN POWER SWITCH PC AUDIO IN Switch the main power on/off. Audio input for VGA/DVI source (3.5mm stereo phone).

  • Page 18: Remote Control

    PARTS AND FUNCTIONS 2.3. Remote Control • Standard : Used for normal images (factory setting) • Highbright : Used for moving image such as Video • sRGB : Used for text based images POWER [PIP] (Picture In Picture) button [ON/OFF]: Turn PIP mode ON/OFF. VIDEO AUDIO SMART...

  • Page 19: Inserting The Batteries In The Remote Control

    PARTS AND FUNCTIONS Picture Format button Press to switch screen aspect ratio. • For PC signal: FULL, NORMAL, CUSTOM and REAL. FULL, NORMAL, DYNAMIC, CUSTOM, REAL, and 21:9. • For Video signal: [BRIGHTNESS] button Press to toggle Brightness Menu. Press [ ] or [ ] button to adjust the value. Press [MENU] button to confirm and exit.

  • Page 20: Handling The Remote Control

    PARTS AND FUNCTIONS Caution: The incorrect use of batteries can result in leaks or bursting. Be sure to follow these instructions: • Place “AAA” batteries matching the (+) and (–) signs on each battery to the (+) and (–) signs of the battery compartment.

  • Page 21: Chapter 3: Connecting External Equipment

    CHAPTER 3: CONNECTING EXTERNAL EQUIPMENT CHAPTER 3: CONNECTING EXTERNAL EQUIPMENT Using the Switch Cover A cover for the power switch is provided to prevent the display from being turned on or off accidentally. To lock the cover into position: Align and insert the cover to the indentation located beside the power switch. Use the screw to lock the cover.

  • Page 22: Using Hdmi Video Input

    CONNECTING EXTERNAL EQUIPMENT 3.2.2 Using HDMI video input DVD / VCR / VCD HDMI Out [HDMI IN] Connecting a PC 3.3.1 Using VGA input VGA Out D-Sub 15 pin Audio Out [AUDIO IN] [VGA IN] [PC AUDIO IN]...

  • Page 23: Using Dvi Input

    CONNECTING EXTERNAL EQUIPMENT 3.3.2 Using DVI input DVI Out Audio Out [AUDIO IN] [DVI IN] [PC AUDIO IN] 3.3.3 Using HDMI input HDMI Out [HDMI IN]...

  • Page 24: Connecting Audio Equipment

    CONNECTING EXTERNAL EQUIPMENT Connecting Audio Equipment 3.4.1 Connecting external speakers External speakers 3.4.2 Connecting an external audio device Audio In Stereo Amplifier [AUDIO OUT]...

  • Page 25: Connecting Multiple Displays In A Daisy-Chain Configuration

    CONNECTING EXTERNAL EQUIPMENT Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a video wall. NOTE: M aximum 25 displays (5x5) can be used in a daisy-chain configuration. 3.5.1 Display control connection Connect the [RS232C OUT] connector of DISPLAY 1 to the [RS232C IN] connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [RS-232C] [RS-232C IN]...

  • Page 26: Chapter 4: Osd Menu

    CHAPTER 4: OSD MENU CHAPTER 4: OSD MENU An overall view of the On-Screen Display (OSD) structure is shown below. You can use it as a reference for further adjusting your display. Navigating the OSD Menu 4.1.1 Navigating the OSD menu using the remote control MENU EXIT Press [...

  • Page 27: Osd Menu Overview

    OSD MENU OSD Menu Overview 4.2.1 PICTURE menu PICTURE BRIGHTNESS CONTRAST SHARPNESS BLACK LEVEL TINT COLOR COLOR TEMPERATURE NATIVE USER COLOR GAMMA SELECTION NATIVE NOISE REDUCTION FILM MODE PICTURE RESET :SEL :NEXT :RETURN :EXIT MENU EXIT MENU Item Description BRIGHTNESS Adjust the overall image brightness by changing the intensity of the LCD panel’s backlight.

  • Page 28: Screen Menu

    OSD MENU Item Description NOISE Adjust to remove the noise in the image. You can select a suitable noise REDUCTION reduction level. The options are: {OFF} / {LOW} / {MIDDLE} / {HIGH}. NOTE: This item is functional for HDMI(Video mode), S-Video, Video, and YPbPr inputs only.
  • Page 29 OSD MENU Item Description ZOOM MODE The pictures you receive may be transmitted in 16:9 format (wide screen) or 4:3 format (conventional screen). The 16:9 pictures sometimes have a black band at the top and bottom of the screen (letterbox format). This function allows you to optimize the picture display on screen.
  • Page 30 OSD MENU Item Description CUSTOM ZOOM You can use this function to further customize the zoom settings to suit the image you want to display. NOTE: This item is functional only when the {ZOOM MODE} setting is set to {CUSTOM}. ZOOM Expands the horizontal and vertical sizes of the image simultaneously.

  • Page 31: Audio Menu

    OSD MENU 4.2.3 AUDIO menu AUDIO BALANCE TREBLE BASS AUDIO RESET :SEL :NEXT :RETURN :EXIT MENU EXIT MENU Item Description BALANCE Adjust to emphasize left or right audio output balance. TREBLE Adjust to increase or decrease higher-pitched sounds. BASS Adjust to increase or decrease lower-pitched sounds. AUDIO RESET Reset all settings in the AUDIO menu to factory preset values.
  • Page 32 OSD MENU Item Description PIP RESET Reset all settings in the PIP menu to factory preset values. NOTES: • The PIP function is available only for certain signal source combinations as shown in the table below. • The availability of the PIP function will also depend on the resolution of the input signal being used.

  • Page 33: Configuration1 Menu

    OSD MENU 4.2.5 CONFIGURATION1 menu CONFIGURATION1 OFF TIMER SCHEDULE DATE AND TIME CONFIGURATION1 RESET :SEL :NEXT :RETURN :EXIT MENU EXIT MENU Item Description OFF TIMER Set the display to turn itself off to standby mode within an amount of time specified.
  • Page 34 OSD MENU Item Description Press [ ] or [ ] button to select the schedule: POWER-ON schedule: Press [ ] or [ ] button to set the hour and minute for the display to turn on. POWER-OFF schedule: Press [ ] or [ ] button to set the hour and minute for the display to turn off.

  • Page 35: Configuration2 Menu

    OSD MENU 4.2.6 CONFIGURATION2 menu CONFIGURATION2 LANGUAGE OSD TURN OFF OSD H POSITION OSD V POSITION INFORMATION OSD 3 SEC. MONITOR INFORMATION MONITOR ID IR CONTROL TILING POWER ON DELAY CLOSED CAPTION CONFIGURATION2 RESET :SEL :NEXT :RETURN :EXIT MENU EXIT MENU Item Description...
  • Page 36 OSD MENU Item Description TILING With this function you can create a single large-screen matrix (video wall) that consists of up to 25 sets of this display (up to 5-set each at the vertical and horizontal side). This function requires a daisy-chain connection.
  • Page 37 OSD MENU Item Description POWER ON Select the delayed time until the power-on mode is activated after the power DELAY is turned on manually or automatically. This setting is useful in hiding start- up messages and powering on the connected devices at different timings. The options are: {OFF}, {2 SEC.}, {4 SEC.}, {6 SEC.}, {8 SEC.}, {10 SEC.}, {20 SEC.}, {30 SEC.}, {40 SEC.}, {50 SEC.}.

  • Page 38: Configuration3 Menu

    OSD MENU 4.2.7 CONFIGURATION3 menu CONFIGURATION3 POWER SAVE HEAT STATUS SCREEN SAVER SIDE BORDER COLOR CONFIGURATION3 RESET :SEL :NEXT :RETURN :EXIT MENU EXIT MENU Item Description POWER SAVE Set the display to reduce the power automatically. POWER SAVE VIDEO :SEL +-:ADJ :RETURN :EXIT MENU...
  • Page 39 OSD MENU Item Description SCREEN SAVER NOTES: • The default { AUTO} option will start running the cooling fan if the temperature of 65°C (152°F) is reached, and will keep running for 30 minutes after cooling down to the temperature of 62°C (144°F). •...
  • Page 40 OSD MENU Item Description TERMINAL Select the mode to display the HDMI or DVI signal according to their signal SETTING format depending on their source device. • DVI MODE}: Used for DVI-D signal. • Select { DVI-PC} when the source device is a PC. DVI-HD} when the source device is a video device.
  • Page 41 OSD MENU Item Description LAN SETTING Assign {IP ADDRESS}, {SUBNET MASK}, and {DEFAULT GATEWAY} for the display. LAN SETTING DHCP CLIENT IP ADDRESS SUBNET MASK DEFAULT GATEWAY :SEL +-:ADJ :RETURN :EXIT MENU EXIT MENU • DHCP - Choose to enable or disable the DHCP function. If enabled, the display will be assigned IP address, Subnet mask and Default gateway automatically.

  • Page 42: Chapter 5: Input Mode

    CHAPTER 5: INPUT MODE CHAPTER 5: INPUT MODE VGA Resolution Active Resolution Standard Refresh Aspect Pixel Rate Stand for Mode Resolution H Pixels V Lines Rate Ratio 25.175 60 Hz Video Graphic 72 Hz 72 Hz 31.5 MHz Array 75 Hz 75 Hz 31.5 MHz Wide Video...
  • Page 43 INPUT MODE • Check your PC instruction book for information about connecting your PC to a display. • If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5KHz (horizontal). In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power is turned off (or if the PC is disconnected).

  • Page 44: Chapter 6: Cleaning And Troubleshooting

    CHAPTER 6: CLEANING AND TROUBLESHOOTING CHAPTER 6: CLEANING AND TROUBLESHOOTING Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.

  • Page 45: Troubleshooting

    CLEANING AND TROUBLESHOOTING Troubleshooting Symptom Possible Cause Remedy No picture is displayed The power cord is Plug in the power cord. disconnected. Make sure the power switch The main power switch on is switched on. the back of the display is not Connect a signal connection switched on.
  • Page 46 CLEANING AND TROUBLESHOOTING Can see picture but no sound Improperly connected source Make sure that both video signal cable. inputs and sound inputs are is heard correctly connected. Volume is turned all the way down. Press [ VOL UP] or [VOL DOWN] button to hear 3.

  • Page 47: Chapter 7: Technical Specifications

    CHAPTER 7: TECHNICAL SPECIFICATIONS CHAPTER 7: TECHNICAL SPECIFICATIONS Display Specifications Display PS-46 PS-55 Screen Size (Active Area) 46” LCD 55” LCD Aspect ratio 16:9 Number of pixels 1920 (H) x 1080 (V) Pixel pitch 0.53 mm 0.63 mm Displayable colors 1073.7M colors Brightness (typical) 700 cd/m2...
  • Page 48 TECHNICAL SPECIFICATIONS General PS-46 PS-55 Power Supply AC 100 ~ 240V, 50 ~ 60Hz AC 100 ~ 240V, 50 ~ 60Hz Power Consumption (Max) 250W 310W Power Consumption (typ.) 170W 245W Power Consumption (Standby & Off) <0.5W (RS232 in active) <0.5W (RS232 in active) Dimensions (With Stand) [W x H x D] 1052.7 x 662.7 x 400 mm...
