Model BRDROS
How to install, operate
and maintain your
Reverse Osmosis Drinking
Water Filtration System
PRODUCT AND WARRANTY
REGISTRATION
Register your product
online to validate and
extend your warranty.
See warranty page for
details.
warranty.ecopurehome.com/brita
If you have any questions or concerns when
installing, operating or maintaining your water
filtration system, call our toll free number:
1-800-218-6172
www.ecopurehome.com/brita
or visit
When you call, please be prepared to provide
the model number and date code of your
product, found on the rating decal on back.
System tested and certified by NSF International
against NSF/ANSI Standards 58 and 42 for the
reduction of claims as specified in the
performance data on page 24.
System tested and certified by IAPMO R&T
against NSF/ANSI Standards 42, 53, 58, 401
and 473 for the reduction of claims as specified
in the performance data on pages 24-26.
Manufactured by
Water Channel Partners
1890 Woodlane Drive
Woodbury, MN 55125
7379599 (Rev. B 5/26/20)
Advertisement
Table of Contents
Related Manuals for Brita TOTAL 360 BRDROS
Summary of Contents for Brita TOTAL 360 BRDROS
- Page 1 REGISTRATION Register your product online to validate and extend your warranty. See warranty page for details. warranty.ecopurehome.com/brita If you have any questions or concerns when installing, operating or maintaining your water filtration system, call our toll free number: 1-800-218-6172 www.ecopurehome.com/brita...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page Specifications & Dimensions ..............3 Inspect Shipment . -
Page 3: Specifications & Dimensions
FIG. 1 9” dia. 11-1/2” 3-1/2” 9" dia. 11-1/2" 3-1/2" Questions? Call Toll Free 1-800-218-6172 www.ecopurehome.com/brita or visit When you call, please be prepared to provide the model, date code and serial number, found on the rating decal on back. -
Page 4: Inspect Shipment
Inspect Shipment Your Reverse Osmosis Drinking Water Filtration System Keep the small parts in the parts bag until you are is shipped complete in one carton. Remove all items ready to install them. from your shipping carton. NOTE: Codes in the state of Massachusetts require Check all items against the packing list below. -
Page 5: Plan Your Installation
Plan Your Installation Read through the entire manual before beginning Drain Adaptor your installation. Follow all steps exactly. Reading for Reverse this manual will also help you get all the benefits Osmosis Waste Water from your system. Your Reverse Osmosis Drinking Water Filtration System can be installed under a sink or in a remote location. -
Page 6: Overview & Site Preparation
10 grains per gallon, with no iron. Questions? Call Toll Free 1-800-218-6172 www.ecopurehome.com/brita or visit When you call, please be prepared to provide the model, date code and serial number, found on the rating decal on back. -
Page 7: Installation Instructions
Step A - Install Cold Water Supply Fitting CHOOSE TYPE OF WATER FITTING TO INSTALL Check and comply with local plumbing codes as you plan, then install a cold water supply fitting. Refer to the Specifications page for supply water requirements. The fitting must provide a leak-tight connection to the RO 1/4"... -
Page 8: Step B - Install Reverse Osmosis Drain
Step B - Install RO Drain Under Sink Under the Sink Installation INTRODUCTION A suitable drain point is needed for the drain water from Double Basin Sink Single Basin the Reverse Osmosis filter. You have two options: Sink • Install the Drain Adaptor included with your unit As shown in Figures 8-10, the drain adaptor is installed onto your sink’s drain pipe above the P-trap. - Page 9 Step B - Install RO Drain in Remote Location Outside Faucet (Hard Water) Outside Faucet BLUE Tubing (Hard Water) to Reverse Osmosis Faucet Soft, Cold Water Soft Water - Soft, Hot GREEN Tubing Water to Reverse Shutoff Osmosis System Valve Reverse Osmosis Remote Installation System...
-
Page 10: Step C - Install Storage Tank
Step C - Install Storage Tank INSTALL STORAGE TANK Tubing Connector Tank Tubing Insert 1. Apply Teflon tape (2 wraps clockwise) to the Nipple ® threads on the nipple at the top of the tank. See Fig Tubing Nut Teflon tape ®... -
Page 11: Step D - Install Reverse Osmosis Faucet
Step D: Install RO Faucet (cont.) INSTALL REVERSE OSMOSIS FAUCET 1. Locate and organize your RO faucet install parts. Refer to Fig. 14. 2. Snap the o-ring into the groove on the bottom of the base and slide the base onto the faucet stud. See Fig. 14. NOTE: If you routed the red drain tubing directly to a remote drain point (see page 9), disregard steps 3 &... -
Page 12: Step E - Connect Tubes
Step E - Connect Tubes HOW TO CUT AND CONNECT THE TUBES Push-in Fitting Tube Your Reverse Osmosis system includes push-in fittings for quick tubing connection. Review the following instructions before connecting the tubes in the next step. Failure to follow these instructions may lead to future leaks. - Page 13 Step E - Connect Tubes (cont.) NOTE: Codes in the state of Massachusetts require installation by a licensed plumber and do not permit the use of saddle valves. If you live in the state of Massachusetts, review plumbing code 248-CMR of the Commonwealth of Massachusetts before proceeding with the installation.
-
Page 14: Step F - Sanitize, Pressure Test & Purge System
(contains no filtration media) RO sanitization cartridge (contains no RO membrane) Syringe, 1 oz. Complete instructions Uses standard 5.25% household bleach (not Postfilter included) to completely sanitize the Reverse Sanitization Osmosis system. Cartridge www.ecopurehome.com/brita To order, go to 1-800-218-6172 or call toll free... - Page 15 Step F - Sanitize, Test and Purge System (cont.) PRESSURE TEST THE SYSTEM Reverse Osmosis NOTE: Complete the sanitizing procedures on the Kitchen Faucet Faucet preceding page before pressure testing. To pressure test the system, complete the following steps. 1. Open the water supply valve to the Reverse Osmosis system.
-
Page 16: How Your Reverse Osmosis System Works
Reverse Osmosis faucet. When the tank is empty of water, the pressure at the air valve is 5 - 7 psi. Questions? Call Toll Free 1-800-218-6172 www.ecopurehome.com/brita or visit When you call, please be prepared to provide the model, date code and serial number,... - Page 17 7. Processed water leaves the storage tank and flows to the postfilter, where it is filtered to ensure fresh taste. 8. Water flows to the Reverse Osmosis faucet. Questions? Call Toll Free 1-800-218-6172 www.ecopurehome.com/brita or visit When you call, please be prepared to provide the model, date code and serial number,...
-
Page 18: Maintenance
PREFILTER / POSTFILTER MAINTENANCE Register for reminders to change filters NOTE: It is recommended to replace the prefilter at www.ecopurehome.com/brita and postfilter cartridges at least every 6 months of product water use. Replace more often if they begin to plug with sediment. - Page 19 Maintenance DRAIN FLOW CONTROL The flow control is required for proper operation of the Reverse Osmosis system. See Fig. 26. The flow con- Flow Control trol, located inside the push-in elbow fitting on the Insert drain port of the Reverse Osmosis filter assembly, keeps water flowing through the membrane at the Push-in required rate.
-
Page 20: Troubleshooting
Remove tube from connection. Remove problem area by cutting tube to shorter length. Reinsert in connection. See pages 12 & 13. If removing the drain line, leave in place the fitting that it connects to. See page 19. Need help troubleshooting? Call Toll Free 1-800-218-6172 or visit www.ecopurehome.com/brita... -
Page 21: Warranty
● The owner replaces both the pre and post filters every six (6) months and saves their receipts, for proof of purchase of the Brita BRDROF filter cartridge set, in case a warranty claim is made. Purchase of no more than two (2) BRDROF filter sets in a 12 month period may be applied toward compliance with this warranty. -
Page 22: Exploded View & Parts List
Exploded View 1/4” red tubing... - Page 23 Screw (6 req.) á Please purchase replacement cartridges from the e-commerce retailer where you bought your reverse osmosis system or Ù www.ecopurehome.com/brita. Not illustrated. Not included. Tubing lengths for remote installations, direct replacement for colored lengths of tubing. NOTE: Codes in the state of Massachusetts require installation by a licensed plumber and do not permit the use of saddle valves.
-
Page 24: Performance Data
Performance Data PERFORMANCE CLAIMS FOR DRINKING WATER SYSTEM Replacement Operating Operating Temp - Recovery Efficiency Daily Production Model Elements Pressure Range erature Range Rating Rating Rate (DPR) BRDROF & 40 -100 PSI 40 - 100 °F 14.76 gal./day BRDROS 21.18% 10.63% BRDROM (275 - 689 kPa) - Page 25 Performance Data Influent Challenge Maximum Permissible Overall % NSF/ANSI Standard 401 Results Concentration Concentration Reduction Atenolol 200 ng/L ±20% 60 ng/L 99.5% Pass Bisphenol A 2,000 ng/L ±20% 300 ng/L 98.2% Pass Carbamazepine 1,400 ng/L ±20% 200 ng/L 97.1% Pass DEET 1,400 ng/L ±20% 200 ng/L...
- Page 26 Performance Data VOCs (by surrogate testing using Maximum Permissible Effluent/ Effluent/ Percent chloroform) Concentration Unfiltered Filtered Reduction Haloketones (HK) 1,1-dichloro-2-propanone 7.2 μg/L 0.1 μg/L 1,1,1-trichloro-2-propanone 8.2 μg/L 0.3 μg/L Heptachlor 0.4 μg/L 25 μg/L 0.01 μg/L >99% Heptachlor Epoxide 0.2 μg/L 10.7 μg/L 0.2 μg/L Hexachlorobutadiene...
- Page 27 All sales in Iowa require the following signature before consummation of sale. These signatures must be retained by seller/renter for 2 years minimum. Buyer/Renter __________________________________________________________ Date _________________ Seller ________________________________________________________________ Date _________________ Seller’s Address _______________________________________________________________________________ Seller’s Phone No. _____________________________________________________________________________ Product: Brita Reverse Osmosis Drinking Water Filtration System - Model BRDROS...
