STEP 3:
Single SlT a ts (5)
Take out
Single Slats (5)
Insert one end of
Side Rail (3) as shown. Attach assembled
Tighten Short Bolts (A)
Repeat above for the other Side Rail (3).
Ax16
STEP : 4
Insert Bolts (A) into the bottom holes on the assembled Headboard (1 ) & Footboard (2) by hand.
Leaving 0.3~0.4inch space of the thread of Bolts (A) as show
Insert the notch of assembled Side Rails (3) into the space left on the Bolts (A).
Screw Bolts (A) into the top holes on the assembled Headboard (1 ) & Footboard (2) as shown.
Tighten Bolts (A) with Allen Wrench (G) after all assembled.
Fully tighten Bolts ( A& C
C
Service
FULL/QUEEN BED
and place them as shown.
RU u bber Insets (F),
into
Double Slats (4)
Allen Wrench (G). Do not fully tighten
with
3
7
4
6
Gx1
) at this step.
G
Assembly is complete. Your bed is ready to be enjoyed now!
