MOD-5436/5437
Thank you for purchasing the MODWAY FULL/QUEEN BED！
Before you start, here are some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximately as sembly time: 45 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Component:
2
1
Headboard
3
Side Rail
5
Single Slat
7
Center Rail
Customer Service 908-368-1025︱www.modwayfurniture.com
FULL/QUEEN BED
5
4
7
8
x1
x2
x8
x1
Hardware:
A
B
C
D
E
F
G
H
6
3
4
5
4
5
4
8
8
2
Footboard
4
Double Slat
6
Low Post
8
Support Leg
Short Bolt M6x20mm
Medium Bolt M6x35mm
Long Bolt M6x50mm
Nut M6
Arc Washer
Rubber Insert
Allen Wrench
Open Wrench
1
3
8
x1
x4
x2
x4
Page 1 of 4
x28
x4
x4
x8
x4
x16
x1
x1
6
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for modway MOD-5436
Summary of Contents for modway MOD-5436
- Page 1 MOD-5436/5437 FULL/QUEEN BED Thank you for purchasing the MODWAY FULL/QUEEN BED！ Before you start, here are some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. 2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 MOD-5436/5437 FULL/QUEEN BED STEP 1: Take off the protective plastic caps from the bottom of Headboard (1) Insert Low Post (6) into Headboard (1) as shown. Attach by using Arc Washer (E) and Short Bolt (A) from the holes on the back of Low Post (6) and Headboard (1).
- Page 3 MOD-5436/5437 FULL/QUEEN BED STEP 3: and place them as shown. Double Slats (4) ake out all to the Center Rail (7) by using Bolts (C) and Nuts (D). Double Slats (4) Attach Please pay attention to the holes ’ direction on the Double Sltas (4).
- Page 4 MOD-5436/5437 FULL/QUEEN BED STEP 5: Insert Bolts (A) into the bottom holes on the assembled Headboard (1&6) & Footboard (2) by hand. Leaving 0.3~0.4inch space of the thread of Bolts (A) as shown. Insert the notch of assembled Side Rails(3&4&5) into the space left on the Bolts (A).
