Step 1: Check what's in the box
PT-101H2 4K HDMI 2.0 Repeater
1 Power supply (5V DC)
Step 2: Get to know your PT-101H2
#
Feature
1
OUTPUT HDMI Connector
2
ON LED
3
INPUT HDMI Connector
4
5V DC Connector
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Step 3: Mount PT-101H2
Install
PT-101H2
using one of the following methods:
•
Attach the rubber feet and place the unit on a flat surface.
•
Fasten a bracket (included) on each side of the unit and attach it to a flat surface
(see www.kramerav.com/downloads/PT-101H2).
•
Mount the unit in a rack using the recommended rack adapter (see www.kramerav.com/product/PT-101H2).
• Ensure that the environment (e.g., maximum ambient temperature & air flow) is compatible for the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be used for avoiding overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
PT-101H2 Quick Start
PT-101H2 Quick Start Guide
This guide helps you install and use your
Go to
www.kramerav.com/downloads/PT-101H2
upgrades are available.
Function
Connect to a 4K HDMI acceptor, (for example, a smart TV)
Lights blue when power is connected.
Lights red when only the HDMI input signal is present.
Lights purple when the power and HDMI signal are connected
Connect to a 4K HDMI source, (for example, a PC)
Connect to the supplied power adapter
PT-101H2
for the first time.
to download the latest user manual and check if firmware
1 Bracket set
4 Rubber feet
P/N: 2 9 0 0 - 3 0 1 2 7 7 QS
1 Quick start guide
Rev: 2
