KR AMER ELECTRON ICS LT D.

USER MANUAL

MODEL:
PT-101H4
HDMI Repeater and Format
Converter
P/N: 2900-000707 Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-101H4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer PT-101H4

  • Page 1: User Manual

    KR AMER ELECTRON ICS LT D. USER MANUAL MODEL: PT-101H4 HDMI Repeater and Format Converter P/N: 2900-000707 Rev 2...
  • Page 3: Table Of Contents

    Defining the PT-101H4 HDMI Repeater and Format Converter     Connecting the PT-101H4     Technical Specifications Figures   Figure 1: PT-101H4 HDMI Repeater and Format Converter   Figure 2: Connecting the PT-101H4 HDMI Repeater and Format Converter PT-101H4 – Contents...
  • Page 4: Introduction

    Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront the video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we have redesigned and upgraded...
  • Page 5: Getting Started

    (often associated with low quality cables) • Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer PT-101H4 away from moisture, excessive sunlight and dust PT-101H4 - Getting Started...
  • Page 6: Overview

    HDMI ensures an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-to-analog conversions. It delivers the maximum high-definition image and sound quality in use today. Note that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.
  • Page 7: About Hdcp

    HDCP-enabled devices to eliminate the reproduction of copyrighted material. To protect copyright holders (such as movie studios) from having their programs copied and shared, the HDCP standard provides for the secure and encrypted transmission of digital signals. PT-101H4 - Overview...
  • Page 8: Defining Edid

    The Extended Display Identification Data (EDID) is a data-structure provided by a display, to describe its capabilities to a graphics card (that is connected to the display’s source). The EDID enables the PT-101H4 to “know” what kind of monitor is connected to the output. The EDID includes the manufacturer’s name, the product type, the timing data supported by the display, the display size, luminance data and (for digital displays only) the pixel mapping data.
  • Page 9: Defining The Pt-101H4 Hdmi Repeater And Format Converter

    OUTPUT HDMI Connector Connect to the HDMI acceptor S/PDIF RCA Connector Connect to the digital audio acceptor 5V DC Power Connector Connect to the power adapter, center pin positive PT-101H4 - Defining the PT-101H4 HDMI Repeater and Format Converter...
  • Page 10: Connecting The Pt-101H4

    For Ethernet connectivity, an HDMI 1.4 version output cable must be used. For best performance, use Kramer cables. 3. Connect the OUTPUT HDMI connector on the rear of the PT-101H4 to the HDMI acceptor (for example, an HDMI display). 4. Connect the S/PDIF RCA connector on the rear of the PT-101H4 to the digital audio acceptor (for example, a home theater system).
  • Page 11: Technical Specifications

    10% to 90%, RHL non-condensing DIMENSIONS: 6.2cm x 5cm x 2.4cm (2.44" x 1.97" x 0.94"), W, D, H WEIGHT: 0.3kg. (0.67lbs) approx. ACCESSORIES: Power supply OPTIONS: RK-4PT 19" rack adapter Specifications are subject to change without notice at http://www.kramerelectronics.com PT-101H4 - Technical Specifications...
  • Page 12 1. Any product which is not distributed by us or which is not purchased from an authorized Kramer dealer. If you are uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site www.kramerelectronics.com.
  • Page 13 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
