Page 1: User Manual
USER MANUAL MODEL: PT-101H2 HDMI Repeater P/N: 2900-300564 Rev 1 www.kramerAV.com... -
Page 3: Table Of Contents
Getting Started Achieving the Best Performance Safety Instructions Recycling Kramer Products Overview Defining the PT-101H2 HDMI Repeater Connecting the PT-101H2 Technical Specifications Figures Figure 1: PT-101H2 Front and Rear Panel Figure 2: Connecting the PT-101H2 HDMI Repeater PT-101H2 – Contents... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 5: Getting Started
Avoid interference from neighbouring electrical appliances that may adversely influence signal quality Position your PT-101H2 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 6: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Range extension up to 10m (33ft) for 4K @60Hz 4:4:4 Ultra HDTV resolution, (5m on the input to the PT-101H2 and 5m on the output) Range extension up to 20m (66ft) for 4K @30Hz (15m on the input to the PT-101H2 and 5m on the output) ... -
Page 8: Defining The Pt-101H2 Hdmi Repeater
Defining the PT-101H2 HDMI Repeater Figure 1 defines the front and rear panels of the PT-101H2 HDMI Repeater. Figure 1: PT-101H2 Front and Rear Panel Feature Function OUTPUT HDMI Connector Connect to a 4K HDMI acceptor, (for example, a smart ON LED Lights blue when power is connected. -
Page 9: Connecting The Pt-101H2
PT-101H2. After connecting your PT-101H2, connect its power and then switch on the power to each device. To connect the PT-101H2 as illustrated in the example in Figure 2: 1. Connect an HDMI source (for example, a 4K graphics source - PC) to the INPUT HDMI connector. -
Page 10: Technical Specifications
Complies with appropriate requirements of RoHs and WEEE REGULATORY COMPLIANCE: INCLUDED Power supply 5.2V DC 2A ACCESSORIES: RK-4PT 19” rack adapter OPTIONS: WARRANTY: 7 years parts and labor Specifications are subject to change without notice at http://www.kramerelectronics.com PT-101H2 - Technical Specifications... - Page 12 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
