QUICK START GUIDE
VT-TNR414(2)
VT-TNR1616P
VT-TNR3216PF
FEATURES:
• 4, 8, 16, 32, 64, and 128 Channel Stand-alone Real-time IP Network
Video Recorders
• Full 8 Megapixel Real-time recording & playback
• 4K HDMI & VGA Video Outputs
• H.265 / H.264 Video Compression
• Plug and Play & Auto configuration for many leading ONVIF compliant IP Camera models
• Internal PoE Switch (VT-TNR414P(2), VT-TNR818P(2), VT-TNR1616P, VT-TNR1646PF and VT-TNR3216PF)
• 1 Gigabit LAN / Dual 1 Gigabit LAN (VT-TNR6480E1, VT-TNV128E)
• Pentaplex: Live Display / Record / Playback / Backup / Remote Access
• Supports SATA2/SATA3 HDD
• Applications for iOS® & Android®
• Fully Programmable Intelligent Analytics including Face Detection (VT-TNR818PF, VT-TNR1616F,
VT-TNR1646PF, VT-TNR3216PF), Fisheye DeWarping (All except VT-TNR414(2) and VT-TNR818(2)), Object
Removal/Museum Search, Line Crossing, and Area Intrusion Detection
• Remote Viewing over the Internet via Web Browser or LAN
• Mac OS® Client & CMS Central Management Software Included
• Supports both Dynamic and Static IP Addresses
• Web-based remote configuration
PLEASE NOTE:
Scan the QR Code for the Complete User Guide. Visit:
http://www.vitekcctv.com/Downloads for additional
Software, Tools, and Updates.
Transcendent Series Line-Up of 8 MegaPixel
H.265 Real Time Network Video Recorders with
VT-TNR818(2)
VT-TNR1616F
VT-TNR6480E1
VT-TNR Series
4K HDMI Output
VT-TNR818PF
VT-TNR1646PF
VT-TNV128E
Advertisement
Related Manuals for Vitek Transcedent VT-TNR Series
Summary of Contents for Vitek Transcedent VT-TNR Series
- Page 1 VT-TNR Series Transcendent Series Line-Up of 8 MegaPixel H.265 Real Time Network Video Recorders with 4K HDMI Output QUICK START GUIDE VT-TNR414(2) VT-TNR818(2) VT-TNR818PF VT-TNR1616F VT-TNR1646PF VT-TNR1616P VT-TNR3216PF VT-TNR6480E1 VT-TNV128E FEATURES: • 4, 8, 16, 32, 64, and 128 Channel Stand-alone Real-time IP Network Video Recorders •...
- Page 2 4CH NVR 720P/960P/1080P/3MP/4MP/5MP/8MP 120fps VT-TNR414(2) 40Mbps 1TB, (1hdd, 1-10TB), 4K Output, HDMI, VGA, PTZ, 4 PoE Ports 8CH NVR 720P/960P/1080P/3MP/4MP/5MP/8MP VT-TNR818(2) 240fps 64Mbps 1TB, (1hdd, 1-10TB), 4K Output, HDMI, VGA, PTZ, 8 PoE Ports 8CH NVR 720P/960P/1080P/3MP/4MP/5MP/8MP 240fps VT-TNR818PF 64Mbps 1TB, (1hdd max, 1-10TB), w/Face Detection License, De-Warping, 4K Output, HDMI, VGA, PTZ, 8 PoE Ports 16CH NVR 720P/960P/1080P/3MP/4MP/5MP/8MP...
-
Page 3: Setup And Configuration
The contents of this manual are subject to change without notice. ● To prevent electric shocks and risk of fire hazards, only use the power source that Vitek provided with your NVR. 2. Check Package Contents Please confirm that the device and all accessories are included in the package. - Page 4 VT-TNR1646PF Rear Connections VT-TNR3216PF Read Connections VT-TNR6480E1 Rear Connections VT-TNV128E Rear Connections...
- Page 5 4. System Startup ● Please make sure all the connections are done properly before you power on the unit. Proper startup and shutdown are crucial to expending the life of your device ● Startup: ① Connect the output display device to the VGA/HDMI interface of the NVR. ②...
- Page 6 Date and Time Configuration: ● The date and time of the system needs to be set up if you use the wizard for the first time. Refer to the following figure. Set the time zone, system time, date format and time format. The DST will be enabled by default if the time zone selected includes DST.
- Page 7 QRCode: ● You can scan the QRCode through the mobile client which is installed on a mobile phone or Tablet to log into the mobile client instantly. Serial Number SERIAL # Add Camera: ● Click “Refresh” to refresh the list of online IP cameras which are in the same local network with NVR and then click to add the searched camera.
- Page 8 ● Click to edit the found IP camera as shown on the below left. Input the new IP address, subnet mask, gateway, username and the password of the camera. Click “OK” to save the settings. ### --- ### --- ### ●...
- Page 9 Disk Settings: ● You can view the disk number, disk capacity of the NVR and serial number, R&W status of the disk. Click “Format- ting” to format the disk. Click “Next” to continue...
- Page 10 Record Settings: ● Two record modes are available: Auto and Manual. ● Auto: Select one auto mode in the interface as shown below and then click “OK” button to save the settings.
- Page 11 NOTES...
-
Page 12: Limited Product Warranty
(3) years, or as otherwise stated above, from the date of purchase by the end user. This warranty is nontransferable and extends only to the original buyer or end user customer of a VITEK Authorized Reseller. The product must have been used only for its intended purpose, and not been subjected to damage by misuse, willful or accidental damage, caused by excessive voltage or lightning.
