  • Page 1 DIGITAL MultiSwitch 700 DLM6C-AA Overview and Setup Guide...
  • Page 3 DIGITAL MultiSwitch 700 DLM6C-AA Overview and Setup Guide Part Number: 9032610 September1998 This guide describes how to install and configure the DIGITAL MultiSwitch 700 DLM6C-AA chassis. Revision/Update Information: This is a new document.

  • Page 4: United States Government Restricted Rights

    Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR...
  • Page 5 FCC Notice — Class A Computing Device: This equipment generates, uses, and may emit radio frequency energy. The equipment has been type tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC rules, which are designed to provide reasonable protection against such radio frequency interference.
  • Page 6 CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT IMPORTANT: Before utilizing this product, carefully read this License Agreement. This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package.

  • Page 7: Declaration Of Conformity

    DECLARATION OF CONFORMITY Application of Council Directive(s): Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer Mr.

  • Page 11: Table Of Contents

    3.2.2 Installing the Cable Management Bar... 3-3 3.2.3 Rack Mounting the DLM6C-AA... 3-4 3.2.4 Attaching the ESD Wrist Strap... 3-5 3.2.5 Installing a Power Supply Module... 3-6 3.2.6 Installing DLM6C-AA Interface Modules ... 3-9 DLM6C-AA Overview and Setup Guide CONTENTS...
  • Page 12 Contents Powering Up a DLM6C-AA with an AC Power Supply...3-11 Powering Up a DLM6C-AA with a DC Power Supply...3-11 3.4.1 Connecting an HA205-MD to 48/60 Vdc Source...3-13 Removing and Reinstalling the Fan Tray ...3-14 3.5.1 Removing the Fan Tray...3-14 3.5.2 Reinstalling the Fan Tray ...3-15...

  • Page 13: Preface

    Welcome to the DIGITAL . This guide explains how to set up and configure the DLM6C-AA Guide chassis. USING THIS GUIDE Read through this guide completely to familiarize yourself with its contents and to gain an understanding of the features and capabilities of the DLM6C-AA chassis.

  • Page 14: Document Conventions

    Other manuals have been developed for the interface modules that can be installed in the DLM6C-AA chassis. These manuals explain how to install the modules into the DLM6C-AA chassis, how to attach cable segments to the modules, and how to configure the modules using Local Management after installation is complete.

  • Page 15: Correspondence

    Network load and frame size at the time of trouble (if known) • The device history (i.e., have you returned the device before, is this a recurring problem, etc.) DLM6C-AA Overview and Setup Guide Documentation Project Manager doc_quality@lkg.mts.dec.com http://www.networks.digital.com http://www.networks.europe.digital.com http://www.networks.digital.com.au...

  • Page 17: Safety

    VORSICHT DANGER AVISO CAUTION ACHTUNG ATTENTION PRECAUCIÓN DLM6C-AA Overview and Setup Guide SAFETY Warns against an action that could result in equipment damage, personal injury, or death. Warnt den Benutzer vor Aktionen, die das Gerät beschädigen, Personen verletzen oder sogar zum Tot führen könnten.

  • Page 18: Safety Requirements

    If theDLM6C-AA is to be placed on a shelving unit, the shelf must be able to support 75 pounds. If the DLM6C-AA is to be rack mounted, care must be taken to ensure that the rack used will support the unit and that the rack remains stable with the DLM6C-AA installed.
  • Page 19 Prévoir deux personnes pour insérer le châssis. Si el DLM6C-AA se va a colocar en una unidad de estantes, el estante deberá ser capaz de aguantar 34 kg. Si el DLM6C-AA se va a...
  • Page 20 N'utilisez que des conducteurs en cuivre type 10 AWG. Vérifiez qu'un appareil de déconnexion adapté et facilement accessible soit installé sur la câblage. L'installation doit être faite conformément aux réglements en vigueur dans le pays concerné. DLM6C-AA Overview and Setup Guide...
  • Page 21 AVISO WARNING VORSICHT DANGER AVISO DLM6C-AA Overview and Setup Guide Safety Requirements Para reducir el riesgo de descarga eléctrica o peligros relacionados con la energía: Asegúrese de que la protección contra sobretensión del circuito de derivación sea como mínimo de 25 A.
  • Page 22 « backplane ». Para evitar dañar los conectores del plano posterior en el paso siguiente, verifique que el módulo se deslice derecho y se adapte correctamente a los conectores del plano posterior. DLM6C-AA Overview and Setup Guide...
  • Page 23 Si vous ne tenez pas compte de ces conseils, vous risquez d'endommager cet équipement. DLM6C-AA y el hub o módulo de host es sensible a la descarga estática. Utilice una banda antiestática para la muñeca y observe todas las precauciones sobre estática durante este procedimiento.
  • Page 25 OVERVIEW The DIGITAL DLM6C-AA chassis design provides five 2.4-inch slots that can contain a variety of interface modules. The chassis supports redundant power supplies, LANVIEW diagnostic LEDs, and is 19-inch rack mountable. All chassis components (power supplies, fan tray, and modules) are installed from the front of the chassis for ease of maintenance.

  • Page 26: Chapter 1 Introduction

    In addition, two power supply modules are capable of load sharing 50% (+/- 5%) of the total load presented by the DLM6C-AA. If one of the power supply modules fails, the other power supply module supplies the entire load of the chassis without interruption to network traffic.
  • Page 27 The DLM6C-AA Cooling System The DLM6C-AA features a removable fan tray that is accessible from the front of the unit. This unit is hot swappable, which allows it to be replaced without powering down the chassis. The fan tray has one LANVIEW LED located on the front of the unit.

  • Page 29: Chapter 2 Installation Requirements And Specifications

    3 inches of clearance above the unit and 2 inches of clearance on either side of the unit. • If the DLM6C-AA is to be placed on a shelving unit, the shelf must be able to support 75 pounds of static weight. •...

  • Page 30: Configuration Guidelines

    (AWG) solid copper conducter with #6 ring terminals. CONFIGURATION GUIDELINES The DLM6C-AA has 5 slots that accept interface modules. The slots are numbered 1 to 5 beginning from the left. There are two additional slots located on the far right of the chassis that are reserved for power supply modules.

  • Page 31: Physical Specifications

    2.3.1 Physical Specifications The physical specifications for the DLM6C-AA chassis, H3105-AA fan tray, and the HA205-MD and HA205-AA power supply modules are as follows: DLM6C-AA Chassis Dimensions: Weight (with factory installed fan tray): HA205-MD Power Supply Dimensions: Weight: HA205-AA Power Supply...

  • Page 32: Power Supply Requirements

    Input Frequency: Input: (Voltage/Current): LEDs The following sections describe the functions and definitions of the LEDs for the DLM6C-AA power supply modules and fan tray unit. Both power supplies available for the DLM6C-AA chassis have the same LEDs. 2.4.1 Power Supply LEDs There are two LEDs on the power supply.
  • Page 33 Green REDUNDANCY Green Amber PWR LED Figure 2-1 Power Supply LEDs DLM6C-AA Overview and Setup Guide Operating Specifications Status All outputs and input of the power supply are within regulation. Any output or input of the specific power supply is out of regulation.

  • Page 34: Fan Tray Led

    Refer to Table 2-2 Fan Tray LED States and Their Definitions LED Color Green When the DLM6C-AA is first powered up, the fan tray LED will display red briefly, until the fans are operating at the proper speed. LKG-10798-98F...

  • Page 35: Chapter 3 Dlm6C-Aa Setup

    This chapter contains instructions on setting up the DIGITAL DLM6C-AA chassis. A Phillips screwdriver is needed to install the unit in a 19-inch equipment rack, to install the cable management bar, to secure the power supply module, and to remove and reinstall the fan tray.

  • Page 36: Setting Up The Dlm6C-Aa

    DLM6C-AA. 3.2.1 Installation Order Once a suitable site has been chosen, the DLM6C-AA can be installed. The chassis can be freestanding or rack mounted. It is recommended that the DLM6C-AA installation proceed in this order: Install the cable management bar.

  • Page 37: Installing The Cable Management Bar

    3-1. Line up the two holes on each side of the cable management bar with the two holes located underneath the DLM6C-AA, near the front of the chassis. Using a Phillips screwdriver securely fasten the 4 screws. Front Panel of Chassis...

  • Page 38: Rack Mounting The Dlm6C-Aa

    3.2.3 Rack Mounting the DLM6C-AA The DLM6C-AA can be mounted in a standard 19-inch equipment rack. If the rack is not secured to the floor, it is recommended that the chassis be installed in the bottom half of the rack. This prevents the rack from being top heavy.

  • Page 39: Attaching The Esd Wrist Strap

    Setting Up the DLM6C-AA 3.2.4 Attaching the ESD Wrist Strap The ESD wrist strap must be attached before handling the DLM6C-AA power supplies, fan tray, or modules. In addition, observe all precautions when handling these modules to prevent damage from ESD.

  • Page 40: Installing A Power Supply Module

    Chapter 3: DLM6C-AA Setup 3.2.5 Installing a Power Supply Module You must install at least one power supply in the DLM6C-AA chassis. One power supply provides sufficient power for most module configurations but a second power supply can be installed to provide a redundant, load-sharing power source.
  • Page 41 With the power supply inserted into the slotted paths, carefully slide the module forward until it is connected to the backplane with the front panel flush with the face of the DLM6C-AA. Do not force the module into place. If significant resistance is encountered before the front panel is flush, remove and reinsert the power supply.
  • Page 42 After installation of the power supply modules is completed, the DLM6C-AA is ready to be powered up; however, DIGITAL recommends that installation of all modules for the DLM6C-AA be completed before powerup. Refer to the following sections to complete the installation.

  • Page 43: Installing Dlm6C-Aa Interface Modules

    3.2.6 Installing DLM6C-AA Interface Modules The DLM6C-AA interface modules can be installed in any of the 5 slots that are available. To install a module, proceed as follows: Remove the blank panel covering the slot in which the interface module will be installed. All other slots must remain covered to ensure proper airflow and cooling.

  • Page 44: Dlm6C-Aa Overview And Setup Guide

    Chapter 3: DLM6C-AA Setup Metal Back-Panel 3-10 Slot Number Backplane Connector MultiSwitch 700 Ethernet DLE22-MA Circuit Card Card Guides Figure 3-5 Installing a Module DLM6C-AA Overview and Setup Guide Plastic Locking Tab DLM6C-AA HA205-AA HA205-AA H3105-AA Plastic Locking Tab LKG-10803-98F...

  • Page 45: Powering Up A Dlm6C-Aa With An Ac Power Supply

    48 or 60 Vdc (48/60 Vdc) power sources. The HA205-MD is installed and functions the same as the ac power supply for the DLM6C-AA. The dc power supply has an on/off switch and an input power strip, and is rated at 510 watts. The on/off power switches and...
  • Page 46 DISCONNECT DEVICE THAT IS SUITABLY APPROVED AND RATED, IS INCORPORATED IN THE FIELD WIRING. TO BE INSTALLED IN A RESTRICTED ACCESS AREA IN ACCORDANCE WITH THE NEC OR THE AUTHORITY HAVING JURISDICTION. 3-12 ON/OFF LKG-10804-98F DLM6C-AA Overview and Setup Guide...

  • Page 47: Connecting An Ha205-Md To 48/60 Vdc Source

    Powering Up a DLM6C-AA with a DC Power Supply DC Power Supply Requirement for Each Supply Each dc power supply input requires either a 48 Vdc or 60 Vdc power source, rated at a minimum of 17 Amps. Installation Requirement Each dc power supply input requires either a 48 Vdc or 60 Vdc power source supplied by three 10 AWG copper wires.

  • Page 48: Removing And Reinstalling The Fan Tray

    DLM6C-AA, contact your DIGITAL representative for assistance. REMOVING AND REINSTALLING THE FAN TRAY The DLM6C-AA is equipped at the factory with a removable fan tray that allows for easy periodic cleaning and/or replacement if a problem occurs with fan operation. A flat blade screwdriver is needed to remove and reinstall the fan tray.

  • Page 49: Reinstalling The Fan Tray

    Reinstalling the Fan Tray To reinstall the fan tray, refer to Locate the ESD wrist strap shipped with the DLM6C-AA. Attach the ESD wrist strap to your wrist and plug the cable from the ESD wrist strap into the ESD grounding receptacle at the upper right corner of the DLM6C-AA.
  • Page 50 Once the tray is in place, tighten the slotted screws with a screwdriver to secure the tray to the DLM6C-AA. When the DLM6C-AA is ready to be powered on, observe the LED on the front of the fan tray. This LED should be red for a moment after the power switch is turned on, and then change to green to indicate that all fans are operating properly.
  • Page 51 Removing and Reinstalling the Fan Tray MultiSwitch 700 DLM6C-AA H3105-AA Slot Guides Slotted Screws (2) LKG-10807-98F Figure 3-9 Reinstalling the Fan Tray DLM6C-AA Overview and Setup Guide 3-17...
  • Page 54 9032610 Printed in U.S.A.
