- Page 1 INSTRUCTION Industrial Sewing Machines HDX1101 HDX1102 First published : October 2003 No. 030183...
- Page 2 INTRODUCTION Thank you for your purchasing Kansai Special's HDX Series. Read and study this instruction manual carefully before beginning any of the procedures and save it for later use. This instruction manual describes adjustments and maintenance procedures on this machine.
-
Page 3: Table Of Contents
CONTENTS 1. NEEDLES & THREADING THE MACHINE 1-1 Needles ·································································································· 1 1-2 Replacing the needle ············································································· 1 1-3 Threading the machine ········································································ 1 2. MACHINE SPEED 2-1 Machine speed & direction in which the machine pulley runs ·········· 2 2-2 Motor & belt ·························································································· 2 3. -
Page 4: Needles & Threading The Machine
【1】NEEDLES & THREADING THE MACHINE 1-1 Needles Needle of Schmetz or Organ. Select the proper needle for the fabric and thread. < Needles and needle size > HDX1101･････DR2 Nm200，#25 ■ HDX1102･････UY143GS Nm200，#25 ■ 1-2 Replacing the needle When replace the needle, check the needle carefully to see that the scarf is turned to the rear of the machine (see the illustration). -
Page 5: Machine Speed
【2】MACHINE SPEED 2-1 Machine speed & direction in which the machine pulley runs Refer to the table below for maximum and standard speeds of the Series. To extend machine life, run the machine approximately 15-20% below the maximum speed for the first 200 hours of operation (approx. -
Page 6: Lubrication
【3】LUBRICATION 3-1 Oil Use Kansai Special’s genuine oil. (Part No. 28-611) 3-2 Oiling ■ T o fill the machine with oil Remove oil plug A from the oil hole. Fill the machine with oil until the oil level is at the top line (see H in the illustration) on oil gauge C. -
Page 7: Sewing Machine Installation
【4】SEWING MACHINE INSTALLATION 4-1 Cutting the machine table... -
Page 8: Installing The Machine
4-2 Installing the machine Install the brackets on the underside of the table board (see the illustration below). Fit the rubber cushions onto the brackets. Mount the machine head on the rubber cushions. 【5】TIMING OF THE LOOPER TO THE NEEDLES 5-1 Angle and height for installing the looper To obtain the proper angle and height, insert the looper fully into looper holder A... -
Page 9: Looper Left-To-Right Movement
5-2 Looper left-to-right movement When the point of the looper moves from the right/left to the left/right, distance A from the top of the needle's eye to the point of the looper at the left side of the needle should be equal (see the illustration on the right). -
Page 10: Needle/Looper Front-To-Back Relationship
5-5 Needle/looper front-to-back relationship When the looper passes on the back side of the needle, the clearance between the needle and the looper should be 0.05~0.1mm. Adjustment is made by loosening screw A. To increase the clearance, turn the looper avoid eccentric toward the back side of the machine. -
Page 11: Adjusting The Feed Dog & Stitch Length
【7】ADJUSTING THE FEED DOG & STITCH LENGTH 7-1 Feed dog height & tilt ■ H eight adjustment The feed dog is at the top of its stroke, the feed dog teeth should be 2.9mm above the top surface of the needle plate. -
Page 12: Position Of The Presser Foot & Foot Lift
8-2 Position of the presser foot & foot lift Fit the presser foot onto the presser bar so that the needle can drop correctly to the center of the presser foot needle drop hole. ■Position of the presser foot Loosen screw A. Adjust by moving the presser foot left or right while checking to make sure the needle drops correctly to the center of the presser foot needle drop hole. -
Page 13: The Position Of Take-Up Thread Eyelet
9-2 The position of take-up thread eyelet Refer to the below illustration for threading by threading in direction of D to G of thread eyelet hole, the amount of under thread are decreased. 【10】CLEANING THE MACHINE At the end of each day, remove the presser foot and the needle plate and then clean the slots of the needle plate and the area around the feed dogs.
