M M ounting the Switch on a Wall
The module ships with one (1) velcro strip.
the switch to the wall
Do not attach rubber feet to the switch when mounting the switch to the
wall with velcro.
Figure 2-1 illustrates two recommended orientations for wall mounting the
switch. This figure also shows where to the position velcro on the switch.
To attach velcro do the following:
1. Place the switch on a flat surface with the Cabletron logo on the left
and the 100Base-FX ports on the right.
2. Attach the velcro to the center of the switch using the
supplied 2 x 4 inch strip of velcro.
3. Position the switch on a wall surface that can safely support the
switch.
9033029
.
Figure 2-1. Mounting the Switch on a Wall
velcro strip
The is used to attach
Installation 9
