Welcome To The Smartstack 100 Els100-16Tx; Getting Help - Cabletron Systems SmartSTACK 100 ELS100-16TX Getting Started

Welcome to the SmartSTACK 100
ELS100-16TX
This Getting Started Guide will tell you what you need to get your
SmartSTACK100 ELS100-16TX up and running, out of the box. By
using the factory-set default configuration, you can quickly
integrate the ELS100-16TX into your network. This guide will
provide you with what you need to know to:
• set up and power up the SmartSTACK 100 ELS100-16TX
• connect devices to the SmartSTACK 100 ELS100-16TX
• connect the SmartSTACK 100 ELS100-16TX to the network
• connect the Local Console Manager to a terminal
• install a Ethernet Port Interface Module (EPIM)
• troubleshoot the SmartSTACK 100 ELS100-16TX
The SmartSTACK 100 ELS100-16TX is an intelligent Ethernet-to-
Ethernet desktop switch that lets you to link multiple Local Area
Networks (LANs) together. The SmartSTACK 100 ELS100-16TX
has sixteen 100 Mbps Ethernet ports, and two slots for optional
EPIMs (Ethernet Port Interface Module).

Getting Help

If you need additional support related to the SmartSTACK 100
ELS100-16TX, contact the Cabletron Systems Global Call Center:
By phone (603) 332-9400
By Internet mail support@ctron.com
By FTP ctron.com (134.141.197.25)
Login anonymous
Password your email address
BBS: (603) 335-3358
Modem setting: 8N1: 8 data bits, No parity, 1 stop bit
WWW: www.ctron.com
Com Port
Port Status LEDs
PORT STATUS MODE
STATUS
TX ACT
PWR
CPU
RESET
RX COL
ELS100-16TX COM
Status Button
Reset Switch
– 1 –
LEDs
1X 3X 5X 7X 9X 11X 13X 15X
1 3 5 7 9 11 13 15
LINK
STATUS
FDX MON
LINK
STATUS
100 USR
2 4 6 8 10 12 14 16 2X 4X 6X 8x 10X 12X 14X 16X
100BASE-T Ports
EPIM100
EPIM100
EPIMs
