- Page 1 SSL-MINI-B BICOLOR MINI SOFT STRIP LED USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING GENARAY The Genaray SSL-MINI-B is a strip LED with a unique form factor that provides even illumination along its entire length. It excels as a light for closeups and portraits, and it’s an excellent choice for hair or accent lighting too.
- Page 3 · Do not attempt to disassemble or repair · All images are for illustrative purposes the equipment—doing so will void only. the warranty, and Genaray will not be responsible for any damage. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
- Page 4 Ratchet handle Mounting pins AC adapter and power cord PRODUCT OVERVIEW Locking knob Lollipop Two-way 5/8 in. mount mounting receiver AC power Carry case cable SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
- Page 5 Barndoors Battery compartments Battery release buttons Value dial screen BACK FRONT Power switch CCT (color temp.) Dimmer button Power input Diffuser Lollipop mount Channel button cable SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
- Page 6 3. Make sure the lollipop mount is flush with the mounting plate, and rotate the lollipop mount a quarter-turn clockwise until it clicks in place. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
- Page 7 fixture is secure. To prevent the light stand from tipping Tip: over, place a counterweight like a sandbag over one or two legs of your light stand. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
- Page 8 The light on the location without electrical outlets. power adapter will glow green to indicate it’s receiving power. NP-F 7.4 V batteries are recommended, however the SSL-MINI-B will work with most NP-F batteries. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
- Page 9 Color Temperature The SSL-MINI-B has a color temperature range of 3000 to 5600 K. Press the CCT button and turn the value dial to adjust color temperature in 50 K increments. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
-
Page 10: Wireless Operation
Important! Do not operate the light SSL-RC remote (sold separately). while the barndoors are closed. The Genaray SSL-RC remote can control multiple SSL-MINI-B lights as well as other lights in the SSL series. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL... - Page 11 On the SSL-MINI-B, press the Channel button and select a channel with the value dial. Make sure the SSL-MINI-B and the SSL-RC remote are set to the same channel. SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL...
-
Page 12: Product Specifications
Weight (light fixture only): 3.2 (1.45 kg) 98 (3200 K) TLCI: 97 (5600 K) 98 (4400 K) 98 (3200 K) Dimming: 0% to 100% in 1% increments Display: LCD Housing Material: Metal SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL... -
Page 13: Remote Operation
Mounting Power Consumption: 36 W Fixture Mount: 5/8 in. receiver Power Pass-Through: No Remote Operation Remote Control Type: 2.4 GHz Number of Channels: 4 Wireless Range : 100 ft. (30 m) SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL... -
Page 14: Fcc Disclaimer
SSL-MINI-B Bicolor Mini Soft Strip LED - USER MANUAL... - Page 15 ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of...
