9E423-24 Module Specific Information
Full Duplex Configuration Screen
The 9E423-24 Full Duplex Configuration Screen displays the port number, operation
mode, link status, and port status of the module's 24 ports (12 ports at a time).
Module Name: 9E423-24
Slot Number: 12
PORT#
10
11
12
SAVE
4
MMAC-Plus
Full Duplex Configuration
OPERATION MODE
1 STANDARD ENET
2 STANDARD ENET
3 STANDARD ENET
4 STANDARD ENET
5 STANDARD ENET
6 STANDARD ENET
7 STANDARD ENET
8 STANDARD ENET
9 STANDARD ENET
STANDARD ENET
STANDARD ENET
STANDARD ENET
[ 13-24 ]
Figure 1. 9E423-24 Full Duplex Configuration Screen
Local Management
Firmware Revision: 01.XX.08
BOOTPROM Revision: 01.00.01
LINK STATUS
No Link
No Link
No Link
No Link
No Link
No Link
No Link
No Link
No Link
No Link
No Link
No Link
SET ALL PORTS: FULL
PORT STATUS
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
ENABLED
EXIT RETURN
