Manufacturer Part Number Qty Reference Designators
TLV3012AIDCKR 2 U9, U10
ADS9110IRGER 1 U11
BR24G32FVT-3AGE2 1 U14
C2012X7S1A226M125AC 0 C20
GRM21BR71A106KE51L 0 C23
ZRB18AD71A106KE01L 0 C24
GRM188R71E105KA12D 0 C36
FID1, FID2, FID3, FID4, FID5,
N/A 0
FID6
71430-0013 0 J8
R3, R4, R7, R9, R13, R14,
ERJ-2GE0R00X 0
R52
ERJ-2RKF1002X 0 R28
RC0603FR-071RL 0 R33
SBAU249 – October 2015
Submit Documentation Feedback
Table 6. ADS9110EVM Bill of Materials (continued)
Manufacturer Description
Texas Instruments Nanopower, 1.8V, Comparator with Voltage Reference, DCK0006A
Texas Instruments 18-Bit, 2-MSPS, 20-mW, SAR ADC with Enhanced Serial Interface, RGE0024H
Rohm I2C BUS EEPROM (2-Wire), TSSOP-B8
TDK CAP, CERM, 22 µF, 10 V, +/- 20%, X7S, 0805
Murata CAP, CERM, 10 µF, 10 V, +/- 10%, X7R, 0805
Murata CAP, CERM, 10 µF, 10 V, +/- 10%, X7T, 0603
Murata CAP, CERM, 1 µF, 25 V, +/- 10%, X7R, 0603
Fiducial mark. There is nothing to buy or mount.
N/A
Molex Receptacle, SCSI, VHDCI, 68 pin, R/A, TH
RES, 0, 5%, 0.063 W, 0402
Panasonic
Panasonic RES, 10.0 k, 1%, 0.1 W, 0402
Yageo America RES, 1.00, 1%, 0.1 W, 0603
