Density and Performance
The N-Series provides high performance and high density:
Platinum DFE
Performance (Mpps)
Capacity
10/100 Base-TX Ports
100 Base-FX Ports
10/100/1000 Base-TX Ports
10/100/1000 Base-TX Ports with PoE
1000 Base-X Ports
10G Base-X Ports
Performance/Capacity
Switching Fabric Bandwidth
18 Gbps per DFE
Switching Throughput
13.5 Mpps (Measured in 64-byte packets)
Routing Throughput
13.5 Mpps (Measured in 64-byte packets)

Standards and Protocols

Switching/VLAN Services
• Generic VLAN Registration Protocol (GVRP)
• 802.3u Fast Ethernet
• 802.3ab Gigabit Ethernet (Copper)
• 802.3z Gigabit Ethernet (Fiber)
• 802.3ae 10 Gigabit Ethernet (Fiber)
• 802.1Q VLANs
• 802.1D MAC Bridges
• 802.1w Rapid-reconvergence of Spanning Tree
• 802.1s Multiple Spanning Tree
• 802.3ad Link Aggregation
• 802.3ae Gigabit Ethernet
• 802.3x Flow Control
• IP Multicast (IGMP Support v1, v2, per-VLAN Querier Offload)
• Jumbo Packet with MTU Discovery Support for Gigabit
• Link Flap Detection
• Dynamic Egress (Automated VLAN Port Configuration)
IP Routing
• RFC 1812 General Routing
• RFC 792 ICMP
• RFC 1256 ICMP Router Discovery Protocol
• RFC 826 ARP
• RFC 1027 Proxy ARP
• Static Routes
• RFC 1058 RIPv1
• RFC 1723 RIPv2 with Equal Cost Multipath Load Balancing
• RFC 1812 RIP Requirements
• RFC 1519 CIDR
N1 N3
13.5 Mpp 40.5 Mpps
18 Gbps 54 Gbps
72 216
54 162
72 216
48 144
24 72
4 12
Address Table Size
65,536 MAC Addresses
VLANs Supported
4094
Transmit Queues
4/12
N5
67.5 Mpps
90 Gbps
360
270
360
360
120
20
Classification Rules
57,344/chassis
Memory
Main Memory: 256 MB
Flash Memory: 32 MB
• RFC 2338 Virtual Router Redundancy Protocol (VRRP)
• Standard ACLs
• DHCP Server RFC 1541/ Relay RFC 2131
Extended IP Routing
Software upgrade package N-EOS-L3, licensed on a per-chassis basis.
• RFC 1583/RFC 2328 OSPFv2
• RFC 1587 OSPFv2 NSSA
• RFC 1745 OSPF Interactions
• RFC 1746 OSPF Interactions
• RFC 1765 OSPF Database Overflow
• RFC 2154 OSPF with Digital Signatures (Password & MD5)
• OSPF with Multipath Support
• OSPF Passive Interfaces
• RFC 2391 Load Sharing Using Network Address Translation
• Extended ACLs
• Policy-based Routing
• RFC 1112 IGMP
• RFC 2236 IGMPv2
• DVMRP v3-10
• RFC 2361 Protocol Independent Multicast - Sparse Mode
Network Security and Policy Management
• 802.1X Port-based Authentication
• Web-based Authentication
• MAC-based Authentication
• Convergence Endpoint Discovery with Dynamic Policy Mapping
(Siemens HFA, Cisco VoIP, H.323 and SIP)
• Multiple Authentication Types per Port Simultaneously
N7
94.5 Mpps
126 Gbps
504
378
504
336
168
28
