Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to
read through this manual completely and store it in a safe location.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The contents of this document and the specifications of this product are subject to change without notice.
• This document and the product have been prepared and tested as much as possible. If you find any misprints
or errors, please inform us.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur
through use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur
with respect to any article made using this product.
R1-201223
FA02295

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TB-30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland TB-30

Summary of Contents for Roland TB-30

  • Page 1 • Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through use of this product, regardless of any failure to perform on the part of this product.
  • Page 2 Company names and product names are trademarks or registered trademarks of their respective holders. http://www.rolanddg.com/ Copyright © 2020 Roland DG Corporation...

  • Page 3: Table Of Contents

    Contents Contents ......................1 Introduction ......................2 Notes to Follow ....................2 How to Load Media ...................3 1. Load the paper tube................... 3 2. Pass the media through the printer............5 3. Secure the media on the paper tube (core)..........7 4.

  • Page 4: Introduction

    Introduction Notes to Follow The TB-30 is a device used to print on thin film material or other such roll media consisting of material that lacks firmness. It is not designed for printing on sheet media. Before printing on sheet media, remove the TB-30.

  • Page 5: How To Load Media

    How to Load Media Load the roll media correctly. CAUTION Otherwise the media may fall and cause injury. The roll media weighs about 25 kg (55 lb.). To avoid injury, handle the roll CAUTION media with care. Never load media that weighs more than 25 kg (55 lb.). CAUTION The machine may fail to withstand the weight and tip over or cause the media to fall.
  • Page 6 How to Load Media Install the paper tube to the end cap and fix the arm. Fit the paper tube securely onto the (right) stand leg side end cap. Push the arm side end cap against the paper tube and fit it securely. Fix the arm in place with the arm retaining screw.

  • Page 7: Pass The Media Through The Printer

    How to Load Media Pass the media through the printer. Check that the printer's loading lever is in the up position. Switch on the printer's sub power. Check that the following menu items on the printer have been set to "DISABLE." •...
  • Page 8 How to Load Media Raise the floating roller (weight roller) toward you. Pass the media between the floating roller and the tension roller. Floating roller Media Tension roller Lower the floating roller toward the back of the machine. Lower the (front) loading lever. Loading lever (front) Close the front cover.

  • Page 9: Secure The Media On The Paper Tube (Core)

    How to Load Media Check the loading status of the media. • The media is loaded straight. • All areas of the media are taut. If the media has slack or is bent, raise the loading lever and load once again. IM P O R TAN T Avoid pulling back the media as much as possible because doing so may wrinkle the media.
  • Page 10 How to Load Media Attach the center and both ends of the media to the paper tube (core) using adhesive tape (three locations in total). While pulling the media so that it does not sag, secure the center of the media. While pulling the media from the center toward the outer edges, and fix the left and right edges.
  • Page 11 How to Load Media [ENTER]. Press The media is fed out and the screen shown in the figure appears. TILT DANCER ROLLER TO FRONT Lower the dancer roller toward the front. Check that all areas of the media are taut. [ENTER].

  • Page 12: Take Up The Media

    How to Load Media Take up the media. Set the AUTO switch on the take-up unit. Take-up with outward curl Take-up with inward curl P o in t When no media is loaded, lower the dancer roller all the way to the back. Select the mode to match the media to be used.
  • Page 13 How to Load Media [ENTER]. Press The screen shown in the figure appears. W736mm 　　 M E M O When take-up starts, take care that the leading edge of the media does not get folded or bent. Open the front cover. Use screws (in two locations) to fix the front UV shield in place.

  • Page 14: Configure The Printing Settings

    How to Load Media Configure the printing settings. TUC-4 setting • TUC-4 mode: TENSION VersaWorks setting • Page Space: 120 mm (4.72 in.) * The recommended setting value varies depending on the print quality settings. LEC2-330 settings • Take-up method: TU3 •...
  • Page 15 How to Load Media Press [ ▲ ] or [ ▼ ] to select a value. Set the suction force to match the media. M E M O Thin film material and similar media: 30% (recommended) Press [ENTER]. Press [MENU] to go back to the original screen. This completes the setup of the media.
