FTM-3200DR/DE
Operating Manual
VHF DIGITAL/ANALOG TRANSCEIVER
C4FM/FM
VOL
SQL
TXPO
REV
D/A
M H z
V / M
D W
M W
SETUP
DIAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTM-3200DR and is the answer not in the manual?

Questions and answers

Summary of Contents for Yaesu FTM-3200DR

  • Page 1 FTM-3200DR/DE Operating Manual VHF DIGITAL/ANALOG TRANSCEIVER C4FM/FM DIAL M H z V / M TXPO SETUP...
  • Page 2: Table Of Contents

    Contents Safety Precautions ( Be Sure to Read ) ....3 Operation ............. 30 FTM-3200DR/DE Quick Reference Guide ..... 5 Split Tone Operation ..........30 Introduction ............. 6 DTMF Operation ..........30 Features of this radio ..........6 Memory Operation ..........31 Accessories &...
  • Page 3: Safety Precautions ( Be Sure To Read )

    Be sure to read these important precautions, and use this product safely. Yaesu is not liable for any failures or problems caused by the use or misuse of this product by the purchaser or any third party. Also, Yaesu is not liable for damages caused through the use of this product by the purchaser or any third party, except in cases where ordered to pay damages under the laws.
  • Page 4 ( inverters etc. ) fitted in the car. Do not open the case of the product except when replac- ing the fuse and when installing items sold separately. This may result in injury, electric shock and equip- ment failure. FTM-3200DR/DE Operating Manual...
  • Page 5: Ftm-3200Dr/De Quick Reference Guide

    FTM-3200DR/DE Quick Reference Guide VOL Knob Frequency DIAL Knob   Adjusts the audio Selects the operating Frequency. volume level. DIAL M H z V / M TXPO SETUP Power Switch  Press and hold for one second. Transmission Switch ...
  • Page 6: Introduction

    S-Meter, thus reduc- ing guesswork in setting the squelch threshold. Congratulations on your purchase of the FTM-3200DR/DE! Whether this is your first rig, or if Yaesu equipment is already the backbone of your station, the Yaesu organization is committed to ensuring your enjoyment of this high-performance transceiver.
  • Page 7: Accessories & Options

     Safety Guide  Warranty Card  Optional Accessories MH-42C6J Microphone  MH-48A6JA DTMF Microphone  MLS-100 High-Power External Speaker  FP-1023 AC Power Supply (USA market only)  FP-1030A AC Power Supply (USA/EXP market only)  FTM-3200DR/DE Operating Manual...
  • Page 8: Installation

    Installation Connecting the Microphone Connect the supplied MH-48A6JA microphone to the FTM-3200DR/DE. Plug the microphone connector into the MIC jack on the front panel until it clicks. Note: When disconnecting the microphone, pull the cable while pressing the connector latch.
  • Page 9: Mobile Installation

    Installation Mobile Installation The FTM-3200DR/DE must only be installed in vehicles having a 13.8 Volt negative ground electrical system. Mount the transceiver where the display, controls, and micro- phone are easily accessible, using the supplied mounting bracket. The transceiver may be installed in almost any location, but should not be positioned near a heating vent nor anywhere where it might interfere with driving (either visually or mechanically).
  • Page 10: Power Connection

    Warning! Never apply AC power to the power cable of the FTM-3200DR/DE, nor DC voltage greater than 15.8 Volts. When replacing the fuse, only use a 25-A (20-A, European version) fuse. Failure to observe these safety precautions will void the Limited Warranty on this product.
  • Page 11: Base Station Installation

    Installation Base Station Installation The FTM-3200DR/DE is ideal for base station use as well as in mobile installations. The FTM-3200DR/DE is specifically designed to integrate into your station easily, using the following information as a reference. AC Power Supplies Operation of the FTM-3200DR/DE from an AC line requires a power source capable of providing at least 20 Amps continuously at 13.8 Volts DC.
  • Page 12: Front Panel Controls & Switches

    • Allows setting the operating band frequency. Turning clockwise increases the frequency, whereas turning counterclockwise de- creases the frequency. • Allows selecting the desired items for setup, memory registration, group monitoring operation, etc. MIC Jack  Connect the provided microphone cable. FTM-3200DR/DE Operating Manual...
  • Page 13 Press and hold the key in for over one second to activate the Dual Watch feature. Note: For details, refer to the Advanced Manual (download from the Yaesu website). [ D/A ( GM )] key ...
  • Page 14: Microphone Switches

    In the EXP/European version, pressing this button activates T.CALL (1750 Hz) for repeater access. You can reprogram the [ P3 ] and [ P4 ] buttons for other functions, if desired. Note: For details, refer to the Advanced Manual (download from the Yaesu website). MIC ...
  • Page 15: Rear Panel

    DATA Jack  Use this jack when updating the firmware. When a new firmware update for the FTM- 3200DR/DE is available, go to the YAESU website to download the programming data and update the FTM-3200DR/DE to its newest state. Cooling Fan ...
  • Page 16: Basic Operation

    This feature al- lows setting the squelch so that only signals exceeding a certain S-meter level will open the squelch. For de- tails, refer to the Advanced Manual (download from the Yaesu website). FTM-3200DR/DE Operating Manual...
  • Page 17: Frequency Navigation

    To enter 146.000 MHz, press [ 1 ] à [ 4 ] à [ 6 ] à [ # ] Channel Step Selection The frequency tuning step of the DIAL and the microphone [ UP ] / [ DWN ] keys can be changed. Note: See Setup Menu Item “STEP 40” on 45 FTM-3200DR/DE Operating Manual...
  • Page 18: Selecting The Communication Mode

    Basic Operation Selecting the communication mode The FTM-3200DR/DE transceiver is equipped with the AMS (Automatic Mode Select) function which automatically selects from two modes of transmission corresponding to the signal being received. The transmit mode is selected according to the received signal so that C4FM digital sig- nals, and analog signals are received and transmitted automatically.
  • Page 19: Setting The Transmission Mode When Using The Ams Function

    Blinks: 0.5 sec on, 0.5 sec off AUTO (“ ” blinks: 0.5 sec of, 0.5 sec off) Automatically selects one of the two communication modes according to the received signal. D: DN mode F: FM mode Blinks: 0.5 sec on, 0.5 sec off FTM-3200DR/DE Operating Manual...
  • Page 20: Transmission

    Note: Keep the microphone about 5 cm away from your mouth. The sensitivity (gain) of the microphone can be adjusted. For details, refer to the Advanced Manual (download from the Yaesu website). 3. Release PTT. The transmit mode/status indicator turns off and the transceiver returns to the receive mode.
  • Page 21: Adjusting The Transmit Power

    To cancel key-lock, press the [ Power ( Lock )] M H z V / M TXPO SETUP key again. To select which keys are locked, use the Setup Menu Item “LOCK 22” see 44 for de- tails. FTM-3200DR/DE Operating Manual...
  • Page 22: Advanced Operation

    DG-ID are in the communication range. The FTM-3200DR/DE may register transmit and receive DG-ID numbers in the DG-ID memories (up to 10 pairs), and then use the [P1] / [P2] keys on the microphone to easily recall a Group ID.
  • Page 23: Recall And Use The Dg-Id Number Registered In The Dg-Id Memory

    • When using the DG-ID memory, the tag of the DG-ID memory being used is displayed every 5 seconds. DG-ID Number display • If the DG-ID memory is “00”, DG-ID memory tag is not displayed. FTM-3200DR/DE Operating Manual...
  • Page 24: Restore The Dg-Id Number To "00" For Both Transmit And Receive Without Using The Dg-Id Memory

    If the DG-ID memory is “00”, DG-ID memory tag is not displayed every 5 seconds. z If the receive DG-ID number is set to other than “00”, note that you cannot receive signals other than the same DG-ID number. FTM-3200DR/DE Operating Manual...
  • Page 25: Digital Personal Id (Dp-Id) Feature

    When a signal from the already registered transceiver is received, the display of DP-ID list does not change. z When registering a transceiver already registered with a different call sign, the call sign registered in the DP-ID list is changed to registrar the new call sign. FTM-3200DR/DE Operating Manual...
  • Page 26: Deleting The Registered Dp-Id

    DP-ID list screen. • To return to normal operation without deleting the DP-ID, press the [D/A(GM)] key. • If deleting several DP-IDs, repeat steps 4 to 6. 7. Press and hold the [MHz(SETUP)] key to return to normal operation. FTM-3200DR/DE Operating Manual...
  • Page 27: Repeater Operation

    Advanced Operation Repeater Operation The FTM-3200DR/DE includes the ARS (Automatic Repeater Shift) function, which per- mits communication through repeaters automatically, by simply setting the receiver to the repeater frequency. 1. Tune to the repeater frequency. 2. Press the PTT to transmit.
  • Page 28: Weather Broadcast Reception

    Advanced Operation Weather Broadcast Reception The FTM-3200DR/DE includes a unique feature which allows reception of weather broad- casts in the 160 MHz frequency range. Ten standard Weather Broadcast channels are preloaded into a special memory bank. To listen to a Weather Broadcast Channel (Example: When “WX” is assigned to [ P4 ] ): 1.
  • Page 29: Ctcss Operation

    Note: For details, refer to the Advanced Manual (download from the Yaesu website). DCS Operation This radio is equipped with a DCS (Digital Coded Squelch) function that allows audio to be heard only when signals containing the corresponding DCS code are received.
  • Page 30: Dcs Search

    Note: For details, refer to the Advanced Manual (download from the Yaesu website). Split Tone Operation The FTM-3200DR/DE can be operated in a “Split Tone” configuration that enables opera- tion on repeaters using a mix of both CTCSS and DCS control via the Setup menu.
  • Page 31: Memory Operation

    Memory Operation The FTM-3200DR/DE provides a wide variety of memory system resources. These in- clude:  199 “basic” memory channels, numbered “1” through “199”.  A “Home” channel, providing storage and quick recall of one prime frequency.  10 sets of band-edge memories, also known as “Programmable Memory Scan” chan- nels, labeled “L0/U0”...
  • Page 32: Memory Recall

    Moving Memory Data to the VFO Data stored on memory channels can easily be moved to the VFO. Note: For details, refer to the Advanced Manual (download from the Yaesu website). Memory Only Mode Once memory channel programming has been completed, you may place the radio in a “Memory Only”...
  • Page 33: Masking Memories

    2. Press and hold the [ V/M ( MW )] key for one second, and then press the [ REV ( DW )] key. The overwrite confirmation screen appears. 3. Press the [ REV ( DW )] key. The home channel frequency is overwritten. FTM-3200DR/DE Operating Manual...
  • Page 34: Scanning

    Scan Resume Options Select which of the three resume scan modes is to be performed after the scanning stops. Note: For details, refer to the Advanced Manual (download from the Yaesu website). Memory Skip Scanning Memory channels which you do not want to receive can be skipped during scanning.
  • Page 35: Gm Function

     Turn the DIAL knob to select a station and display its communication range in- formation. 3. Press and hold the [ D/A ( GM )] key for one second to disable the GM function and re- turn to the frequency screen. FTM-3200DR/DE Operating Manual...
  • Page 36: Reset Procedure/Clone

    Clone The FTM-3200DR/DE includes a convenient “Clone” feature, which allows the memory and configuration data from one transceiver to be transferred to another FTM-3200DR/ This can be particularly useful when configuring a number of transceivers for a public service operation.
  • Page 37: Connecting The Wires-X Feature

    WIRES is an Internet communication system which expands the range of amateur radio communication. You may employ Internet communications by connecting from your transceiver to a WIRES-X local node station. * FTM-3200DR/DE does not accommodate the transmission/reception of messages, images, audio messages, or location information. Connecting to a WIRES-X digital node (Recommended) * Ascertain the DSQ code or the DG-ID setting of the WIRES-X node station.
  • Page 38  Registered node ID or room ID screen (the C1-C5 screen) Rotate the DIAL knob to select a previ- ously registered node/room (maximum 5 nodes/rooms) on the C1-C5 screen and, then press the [#] key or the PTT switch to connect to the node/room. FTM-3200DR/DE Operating Manual...
  • Page 39 Press and hold the [1] to [5] key The connected node or room ID is registered to the memory of the number (Cn screen) when it is pressed and held (In case the memory is already written, the registration is overwritten). FTM-3200DR/DE Operating Manual...
  • Page 40: Disconnecting From The Node Or Room

    WIRES-X mode. Note: About WIRES-X open node stations A listing of the WIRES-X open node stations, with their location, operation mode, etc. is posted on the Yaesu WIRES-X website. https://www.yaesu.com/jp/en/wires-x/index.php Disconnecting from the node or room 1. While pressing the PTT switch, then enter the “#99999” (DTMF disconnect command) keys.
  • Page 41: Miscellaneous Settings

    Miscellaneous Settings Programming the Key Assignments Default FTM-3200DR/DE key functions have been assigned to the Microphone’s [ P3 ] / [ P4 ] keys at the factory. The user may change these key function assignments, if quick access to another function is desired.
  • Page 42: Displaying The Supply Voltage

    Note: See Setup Menu Item “TEMP 41” on 45. Band Edge Beeper The FTM-3200DR/DE will automatically “beep” when the receiver’s band edge is encoun- tered during scanning (either in standard VFO scanning or during PMS operation). You may additionally enable this feature (band edge beeper) when the frequency reaches the band edge while selecting the VFO frequency manually, using the DIAL knob.
  • Page 43: Setup (Menu) Mode

    Setup (Menu) Mode The FTM-3200DR/DE Setup (Menu) mode, already described in parts of many previous chapters, is easy to activate and setup. The Menus may be used to configure many of transceiver parameters, some of which have not been detailed previously. Use the following procedure to activate the Setup (Menu) mode: 1.
  • Page 44 33: RPT ARS ON / OFF Shift feature. 34: RPT FREQ Sets the magnitude of the Repeater Shift. 0.00 - 150.00 (MHz) 0.60 MHz 35: RPT SFT Sets the Repeater Shift direction. -RPT / +RPT / SIMPLEX SIMPLEX FTM-3200DR/DE Operating Manual...
  • Page 45 50: W-DGID Setting of the WIRES-X DGID AUTO/DGID01-99 AUTO 51: MY CALL Sets your station call sign - - - - - - - - - - : Depends on the transceiver version.  FTM-3200DR/DE Operating Manual...
  • Page 46: Maintenance

    USA version: 25 Amp EXP/European version: 20 Amp 2. Open the fuse holder as shown in the dia- gram on the right. 3. Remove the blown fuse. 4. Attach the new fuse. 5. Close the fuse holder. FTM-3200DR/DE Operating Manual...
  • Page 47: Specifications

    Sensitivity (for Digital): 0.22 μV (BER 1%) Selectivity (–6/–60dB): 12 kHz/28 kHz Maximum AF Output: 3 W @ 13.8 V, 10% THD Rated values are at normal temperature and pressure. Ratings and specifications are subject to change without notice. FTM-3200DR/DE Operating Manual...
  • Page 48 An amateur band radio doesn’t require Certification/Verification for the transmitter under Part 97 z Changes or modifications to this device that are not expressly approved by YAESU MUSEN could void the user’s authorization to operate this device. z This device complies with part 15 of the FCC Rules. Operation is subject to the following two con- ditions: ( 1 ) This device may not cause harmful interference, and ( 2 ) this device must accept any interference including received, interference that may cause undesired operation.
  • Page 49: Eu Declaration Of Conformity

    Telephone: (714) 827-7600 EU Declaration of Conformity We, Yaesu Musen Co. Ltd of Tokyo, Japan, hereby declare that this radio equipment FTM-3200DE is in full compliance with EU Radio Equipment Directive 2014/53/EU. The full text of the Declaration of Conformity for this product is available to view at http://www.yaesu.com/jp/red ATTENTION –...
