Made in Vietnam
Model No: 355 - 111/112
Distributed in the U.S.A by:
RH Baby&Child
2900 N MACARTHUR DRIVE
TRACY, CA 95376
www.rhbabyandchild.com
Distributed in Canada by:
RH Canada, Inc.
1500-1055 West Georgia Street
Vancouver, British Columbia
V6E4N7
W A RN I N G : Re ad a ll
I nstr u ct io ns be for e as s e mb l ing
thi s pro duct .
KEEP IN S TRU CT I O NS F O R
FUTUR E U SE .
1. Read all instructions before assembly crib. Keep instructions for future use.
2. Never use plastic shipping bags or other plastic film as mattress covers because they can cause suffocation.
3. Infants can suffocate in gaps between crib sides and a mattress that is too small.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You can also order parts by writing to
the address above. Include the product model number, color, and a brief description of the part. Or call 1-800-762-1751.
CARE AND CLEANING
DO NOT scratch or chip the finish. DO NOT use abrasive chemicals for cleaning. If the crib is to be stored, store in a cool,
dry place and carefully package all original hardware to protect from loss.
TOOLS AND INSTALLATION
Tools needed: Key Wrench (included).
Two people are recommended for assembly.
When inserting bolts, turn clockwise until tight. Then loosen 1/2-3/4 of a turn. After bed is completely assembled,
return to each bolt and tighten.
COLE H OU S E C RIB
TODDLER KIT (SOLD SEPARATELY)
Page 1 of 12
Advertisement
Related Manuals for RH Baby&child 355-111
Summary of Contents for RH Baby&child 355-111
- Page 1 COLE H OU S E C RIB Made in Vietnam Model No: 355 - 111/112 Distributed in the U.S.A by: RH Baby&Child 2900 N MACARTHUR DRIVE TRACY, CA 95376 www.rhbabyandchild.com Distributed in Canada by: RH Canada, Inc. 1500-1055 West Georgia Street Vancouver, British Columbia V6E4N7 W A RN I N G : Re ad a ll...
-
Page 2: Fall Hazard
C OLE H OU S E C RIB WAR NING : Inf a n t s c a n s u f f o c a te o n s o f t bed d in g. Ne ve r add a pil lo w or co mf or ter . N ev e r pla ce a dd i ti o n al p a d di n g u n d er a n i n f ant. - Page 3 COLE H OU S E C RIB ANY M ATT R E SS U SE D I N T H IS C R IB MU S T B E AT L EAST 2 7 1 / 4 CAUT ION: INCHE S BY 5 1 5 / 8 I NCH ES WIT H A T H IC K N E SS N OT E XC E ED I N G 6 INCHES .
- Page 4 C OLE H OUS E C RIB WAR NING : ENTR APME NT/ST RA NGULATION H AZ ARD In fan ts h ave d ied i n toddler beds f ro m en trapme nt and s trangulation. Fa ilure to fol low these warni ngs an d th e ass emb ly ins truc tions cou ld resul t i n s erious injury or deat h .
-
Page 5: Parts Included
C OLE H OU S E C RIB PA RTS IN CLUD ED: S ID E F RA M E S TA T I O N ARY SI DE RAI L S MA T T RE SS SU P P O RT C E N TE R ST RE TC H ER HAR DWAR E IN CLUDE D : ITEM... - Page 6 COLE H OUS E C RIB ASSEMBLY INSTRUCTIONS Note: - Bed must be assembled by at least two people. - Please read instructions carefully before assembling bed. - Use the above parts and fittings list to identify each component. - Keep all packing materials until assembly is complete to avoid loss of smaller parts.
- Page 7 C OLE H OUS E C RIB STEP 3 : Insert L Pin (6) into empty openings the bottom of the Mattress Support (C), and into the holes on the Side Frame (A). Tighten with Insert Head (5) and Allen Key (7). STEP 4 : Position the Stationary Side rail (B) between the Side Frame (A) and align...
- Page 8 COLE H OUS E CR IB STEP 5: Attach the Stationary Side Rail (B) to the Side Frame (A) with Long Bolt (1), Spring Washer (3), and tighten using Allen Key (7). STEP 6 : Attach the Center Stretcher (D) on the top of the Side Frame (A) with Short Bolt (2), Spring Washer (3), Flat Washer (4), and tighten using Allen Key (7).
- Page 9 C OLE H OUS E C RIB PA RTS I N C LU D E D : E [1] TO DDL E R RA IL HAR DWA RE IN CLUD ED : ITEM DESCRIPTION QTY. Long Bolts 5/16”x 2-1/4” 4 pcs. Small Bolts 5/16”...
- Page 10 C OLE H OU S E C RIB STEP 7: Remove Stationary Side Rail (B) from the crib by carefully unscrew and remove the 4 long bolts with spring washer on Left/Right sides of the Stationary Side Rail (B) using Allen Key (11). STE P 8 : If mattress support is not in the lowest position, loosen all tightened bolts from side frames.
- Page 11 C OLE H OUS E C RIB STEP 9 : Position the Toddler Rail (E) between the Side Frame (A) and align the holes. STEP 10 : Attach the Toddler Rail (E) to the crib by securing with Long Bolts (8), Spring Washers (10), and tighten with Allen Key (11).
- Page 12 C OLE H OUS E C RIB STE P 1 1: When converting the crib to toddler bed, the Small Bolt (9), and Spring Washer (10) should be inserted in the upper holes of the Side Frame (A) and tighten with the Allen Key (11). W A R N I N G : After crib is completely assembled, return to each bolt and tighten to...
