Shini MHD U Series Manual

Smart modular dehumidifying dryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Smart Modular
Dehumidifying Dryer
Date: Dec. 2016
Version: Ver.A(English)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MHD U Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shini MHD U Series

Summary of Contents for Shini MHD U Series

  • Page 1 Smart Modular Dehumidifying Dryer Date: Dec. 2016 Version: Ver.A(English)

  • Page 3: Table Of Contents

    Contents General Description ..................7 1.1 Coding Principle ..................8 1.2 Feature ....................9 1.3 Machine Specifications ................. 10 1.3.1 Outline Drawing ................10 1.3.2 Specification List ................11 1.4 Safety Regulations ................14 1.4.1 Safety Signs and Labels .............. 14 1.4.2 Signs and Labels .................
  • Page 4 4.2.6 Tendency Chart ................38 4.2.7 Alarm ................... 39 4.3 Control Panel ..................41 4.4 Panel Operation ..................41 4.5 Temperature Setting ................41 4.6 Lock Setup .................... 41 4.7 PID Setting .................... 42 4.8 Communication Setting ................. 43 4.9 Wrong Codes Remark ................45 Trouble-shooting ..................
  • Page 5 Table 1-4: Drying Capacity ................12 Table 4-2: Adjustment of Proportion (P) ............36 Table 4-3: Adjustment of Integral Time (I) ............36 Table 4-4: Adjustment of Different Time (I) ............36 Table 4-5: System Slarm Information ............... 40 Picture index Picture 1-1: Outline Drawing ................
  • Page 6 6(55)

  • Page 7: General Description

    1. General Description Please read through this operation manual before using the machine to prevent damages of the machine or personal injuries. Smart modular dehumidifying dryer adopts modular structure, detachable floor stand for instant movement and installation. It can collocate with one dehumifier to several hopper dryers in processing.

  • Page 8: Coding Principle

    1.1 Coding Principle SSMD-U is composed by MHD-U and SD-H-SM. Notes: P=For polished hopper inside Notes* SM4= Max. optional with 4 MHD-U SM8= Max. optional with 8 MHD-U SM12= Max. optional with 12 MHD-U 8(55)

  • Page 9: Feature

    Chapter 6, which contains service instructions intended for service engineers. Other chapters contain instructions for the daily operator. Any modifications of the machine must be approved by SHINI in order to avoid personal injury and damage to machine. We shall not be liable for any damage caused by unauthorized change of the machine.

  • Page 10: Machine Specifications

    1.3 Machine Specifications 1.3.1 Outline Drawing MHD-U MHD-U-M SD-H-SM Picture 1-1: Outline Drawing 10(55)

  • Page 11: Specification List

    1.3.2 Specification List Table 1-1: Specification List of MHD-U Insulated Drying Discharge Air Inlet Air Outlet Hopper Dimension Weight Model Heater Port Height Pipe Dia. Pipe Dia. Capacity （HxWxD） (kg) (kW) (mm)H1 (inch) (inch) （L） MHD-20U(-M) 1253 x 550 x 801 MHD-40U(-M) 1348 x 550 x 801 MHD-80U(-M)
  • Page 12 Table 1-3: Combinations of MHD-U and SD-H-SM Max. Process Hopper Dimension Model Flow -20U -40U -80U -120U -160U -230U -300U -450U -600U (H × W × D) Capacity (m³/hr) 1360 × 530 × √ √ -120H-SM* 1560 × 660 √ √...
  • Page 13 0.31 0.65 0.02 0.02 SAN(AS) 0.32 0.05 0.02 Notes: 1)Use separated drying hopper. 2) Moisture content lower than 0.005% after drying when in 20℃ ambient temperature and 65% relative humidity. 3) Specific model selection, please consult with Shini members. 13(55)

  • Page 14: Safety Regulations

    1.4 Safety Regulations Note! Electrical installation of the machine should be done by qualified electricians. Before connect through power supply, make sure that power switch specifications and security ratings are suitable and reliable, and also the main switch is turned to OFF.

  • Page 15: Signs And Labels

    1.4.2 Signs and Labels Push switch of shut-off plate: I: Pull O: Push Water outlet: drainage outlet. Water inlet: inlet for replenishing water and cooling water. 1.4.3 Transportation and Storage of the Machine Transportation 1) SSMD-U series smart modular dryers are separately packed in SD-H-SM and MHD-U by crates or plywood cases with wooden pallet at the bottom, suitable for quick positioning by fork lift.

  • Page 16: Safety Regulations For The Blowers

    Working environment Indoors in a dry environment with max. temperature +45℃ and humidity no more than 80%. Do not use the machine 1) If it is with a damaged cord. 2) On a wet floor or when it is exposed to rain to avoid electrical shock. 3) If it has been dropped or damaged until it is checked or fixed by a qualified serviceman.
  • Page 17 This machine is well designed with air filters, so please clean up the filter with any foreign particles (recommended to clean up this filter weekly). 4) Clean the blowers both internal and external parts (especially for the fan cooling path), and remove surface dust if necessary. If more dusts are accumulated, it will cause deficiency for ventilation, temperature rising, vacuum power reduced, vibration increased and so it will cause machine broke down.

  • Page 18: Exemption Clause

    The following statements clarify the responsibilities and regulations born by any buyer or user who purchases products and accessories from Shini (including employees and agents). Shini is exempted from liability for any costs, fees, claims and losses caused by reasons below: 1) Any careless or man-made installations, operation and maintenances upon machines without referring to the Manual prior to machine using.

  • Page 19: Structure Characteristics And Working Principle

    2. Structure Characteristics and Working Principle 2.1 Relative Humidity and Dew-point Relative humidity: Relative air humidity means real vapor content to saturated vapor at the same temperature in percentage. Dew point: it means that temperature when the saturation vapor begins to dew. When the relative humidity is 100%, the ambient temperature is the dew point temperature.

  • Page 20: Accessory Option

    heating to plastic drying temperature, the air was blown into the drying hopper which forms the hermetic circulation to dry the materials. 2.3 Accessory Option 2.3.1 Material Suction Box European style in appearance design, work with dryer that has a floor stand and vacuum loader, suitable for material sunction and discharging.
  • Page 21 2. Portable Digital and Real-time Curve Display supports Display English\Chinese\Japanese\Korean version. -50..+50℃ td Range Pressure -0.1..1.5MPa td Temperature -30..+50℃ Dew point ±2℃ td@-50℃ td Pressure ±0.005MPa Temperature ±0.3℃ Accuracy temp.:23℃±3℃ Condition Humidity:<90% no condensation Other Units g/m3,mg/m3,ppmv,g/kg 4G, data can be exported Memory space Data by memory card...

  • Page 22: Installation And Debugging

    3. Installation and Debugging Read this chapter carefully before installation. Install the machine by following steps. Power supply of the machine should be handled by qualified electricians! Notes! Keep the machine 2m from the combustible distance. 3.1 Machine Installation A. Smart modular dehumidifying dryer consists of two parts, including MHD-U modular hopper dryer and SD-H-SM smart modular dehumidifier.

  • Page 23: Power Connectors

    C. Cable connection: when packaging MHD-230U and above models, it should separate the hopper and floor stand. During connection, airflow detecting signal, airflow adjusting signal and temperature control signal require metal connectors. See below wiring diagram (1) MHD-U and SD-H-SM are jointed by 2 groups of cables, and among which one group is hopper’s data cable jointed by 10PIN heavy-duty connector separately, and the other group is communication cable connected by 4PIN heavy-duty connector.

  • Page 24: Application

    7) Specific power supply specifications please refer to the schematic model. 3.3 Application Picture 3-3: Smart Modular Dehumidifier Installation Diagarm 24(55)

  • Page 25: Operation

    The panel mainly includes four menus, which are dehumidifying process, drying process, alarming information and parameter setting. The panel steps are as following: Notes: the gray indicated steps require correct username and password; Common load: username: shini password: 3588 Picture 4-1: System Operation Diagram 25(55)

  • Page 26: Panel Description

    Please refer to the following initial menu. Press “English” or “Chinese” to select a language. Then enter drying process menu. 4.2.2 Password When entering the “parameter setting” or “recipe setting” screen, it should input the correct “username” and “password”. Input Password Default username and password； shini 3588 ( common use) 26(55)

  • Page 27: Dehumidifying Process Menu

    4.2.3 Dehumidifying process menu Dehumidifying process menu as shown below: When it doesn’t start dewpoint monitor in parameter setting, this area is concealed. A. System power on/off System power on： Touch panel switch to ON state, the system starts operation. System power off：...

  • Page 28: Drying Process Menu

    4.2.4 Drying process menu 1. Touch the hopper on panel, entering the setting of material type and output: A. According to “material”, use the corresponding parameters in “material recipe” automatically. Such as: drying temp., drying time, material “max. output capacity” and “ airflow”. B.
  • Page 29 C. Customer according to material actual dosage in production for “output” input. Machine according to airflow in “material recipe”, figures out and takes the required airflow automatically. (Notes: under the same output condition, by changing of “airflow” changes the output airflow.) Formula: drying airflow (m^3/h) = output capacity (kg/h) * airflow (m^3/kg) E.g.
  • Page 30 B. Save recipe After the edit of recipe parameter or add the new recipe, click save recipe button. Confrim the name, system will save the edited recipe values forever. C. Download recipe Select one recipe and click download-recipe button, then it can download the selected recipe into PLC.
  • Page 31 Notes: Material recipe parameter will directly influence the drying effect, please take material supplier provided parameter as standard. Attached: Material Performance Table. Table 4-1: Material Performance Drying Bulk Moisture Moisture Drying Time Airflow Material Temp. Density Content before Content after (hr) (Nm3/kg.hr) (kg/L)

  • Page 32: Parameter Menu

    0.02 1.8~2.4 110~125 0.04 1.8~2.1 140~150 0.02 0.02 1.5~1.8 120~170 0.65 0.02 1.8~2.0 80~90 0.02 2.5~2.8 0.02 1.7~2.1 0.05 1.7~2.1 0.05 1.7~2.1 0.02 4.2.5 Parameter Menu 1. Time Setting A. weekly timing 32(55)
  • Page 33 Start: set “set-up time” and “shut-down time” separately, then click “weekly timing switch” to “ON” state, it starts timing function. “dehumidifying process menu” as below picture: Under main power ON state, the machine will auto set up and shut down within the set time.
  • Page 34 2. User management A. Click <new user > to create new user Note: 1) different groups represent different privileges. Group (9) is administrator privilege; Group (1) is common privilege. 2) Log-off time (minute): when the no-operation screen exceeds the set time, log off the loading. 34(55)
  • Page 35 B. Click the user, it can change the username and password. Notes：system has set three default users: Admin/Shiniwx/shini 3. Parameter Setting A. Paramete Setting 1 Hopper 1/2/3 capacity: according to actual hopper capacity; (Default value has been set in factory) As above picture, when it only starts hopper 1/2, and the ON/OFF at the back of hopper 3 and 4 should be turned off.
  • Page 36 Notes: Regeneration temp. PID value determines the effect of regenerative temperature control, please be careful to set the value. When adjusting the proportion (P): Table 4-2: Adjustment of Proportion (P) When adjusting integral time (I) Table 4-3: Adjustment of Integral Time (I) When adjusting differential time (D) Table 4-4: Adjustment of Different Time (I) 36(55)
  • Page 37 B. Parameter setting 2 Notes: Airflow PID value determines the effect of airflow adjustment, please be careful to set the value! 4. Airflow Adjustment Notes: It is set before machine delivery, unprofessional adjustment is forbidden! 37(55)

  • Page 38: Tendency Chart

    4.2.6 Tendency Chart 1. Dehumidifying temperature tendency Record the “regeneration temp.” “dew-point temp.” “return temp.” variation in the last 1 hour. 2. Drying temperature tendency chart Record the “hopper 1 temp.” “hopper 2 temp.” “hopper 3 temp.” variation in the last 1 hour.

  • Page 39: Alarm

    4.2.7 Alarm 39(55)
  • Page 40 Table 4-5: System Slarm Information Faults Results Possible Reasons Trouble-shooting System can’t start, Low voltage, phase shortage, Randomly exchange Wrong phase buzzer sounds, alarm wrong phase one of two power cables. flickers Motor stucked or damaged. Check and replace the motor. System stops, buzzer Belt broken Check and replace.

  • Page 41: Control Panel

    4.3 Control Panel 4.4 Panel Operation 1) Turn on main power switch of control box. 2) Press “RUN/STOP” key, it starts drying process, indicator turns green; 3) Press “RUN/STOP” key again, it stops drying process, indicator turns yellow 4.5 Temperature Setting 1) The setup number will flicker after pressing "...

  • Page 42: Pid Setting

    3) Press “ ” key, the set value flickers, press key to select “YES”(lock temperature setting) and “NO” (don’t lock). 4) Press “ ” key to confirm the input value. 5) Press “menu ” key to return operation menu. Notes: When “LOCK” is set as “YES, temperature setting value will be locked which not accessible to change.

  • Page 43: Communication Setting

    3) Press “ ” key to confirm the input value. 4) Press “page up ” key again and again, it displays “I” (integral time ) and “D” (differential time) setting accordingly. 5) Repeat above step2 and step 3, input and confirm related parameters. 6) Press “...
  • Page 44 2) Press “page up ” key to enter “ID” (communication address) setting; Notes: The communication address of every controller in the same system must be the only one, no repeat use. In principle: communication address of hopper 1 is 1, communication address of hopper 1 is 2, and so on.) 3) Press “...

  • Page 45: Wrong Codes Remark

    4.9 Wrong Codes Remark Wrong Codes Remark Thermocouple break alarm Over-temp alarm Overload alarm EGO Over-temp heater cable cut off 45(55)

  • Page 46: Trouble-Shooting

    5. Trouble-shooting Troubles Possible Reasons Solutions Blower direction is 1. Randomly exchange any of the two 1. Blower connection reversed. reversed as the arrow. blower cables. 1. Motor failure 1. Check and replace. Blower doesn’t work. 2. Solenoid switch contact break. 2.

  • Page 47: Maintenance And Repair

    6. Maintenance and Repair MHD-20U~600U 47(55)
  • Page 48 SD-120H~700H-SM Attention ! 1) Turn off the main switch and control switch and unplug the cord from power supply before service and maintenance. 2) Be sure not to modify electrical wiring or reassemble the electrical components inside of the control box. 3) Always refer to the electrical diagram of this manual to check and maintain the electrical wiring problems.

  • Page 49: Honeycomb-Rotor

    6.1 Honeycomb-rotor 6.1.1 What is “honeycomb-rotor”? The main body of the honeycomb-rotor is a honeycomb, made by ceramic fibre and organic additives, sintered under high temperature with molecular sieve and silica gel, to be strongly bonded together and form a solid and hard surface. Not like common molecular sieve, which will produce dusts and fines to pollute raw materials when aging or become saturated requiring regular replacement, honeycomb-rotor offer unlimited long life and can be cleaned when it is polluted.
  • Page 50 2) Install the gearmotor (the 4 screws as “5” in picture) and transmission gear (Fig. 4). Install and fix the main support screws (Fig. 3). Picture 6-3: Honeycomb-rotor Installation 2 3) Fit the transmission belt in proper position (Fig. 6). Picture 6-4: Honeycomb-rotor Installation 3 4) Install the honeycomb-rotor (Fig.
  • Page 51 Honeycomb Rotor Cleaning Steps: 1) Use a vacuum-cleaner with brush to suck up the dust on rotor surface. 2) Blow off the dust in the rotor channels with compressed air. 3) If there is dirt sticking to the channel walls inside the rotor, cleaning steps as follows: a.

  • Page 52: Ego

    6.2 EGO Attention! The EGO value has been setting before out factory, Don't modify it. Default Value Drying 200℃ Regenerating 200℃ Picture 6-6: EGO 6.3 Filter Please periodically clean the dust on the air filters, once per week. Cleaning steps： 1) Take out the air filter carefully.

  • Page 53: Operation And Debugging Of Air-Door Actuator

    Cooler Clean Steps: 1) Disassemble the cooler's pipe and screw, and remove the cooler out of the chiller. 2) Release the fixed screw on the upper and lower cover of cooler and disassemble the cover. 3) Use brush, compressed air or low pressure water to clean the dust and sundries on the cooler fan and copper pipe.

  • Page 54: Maintenance Schedule

    6.6 Maintenance Schedule 6.6.1 Machine Information Model Manufacture date Voltage Ф Frequency Power 6.6.2 Check After Installation Check that pipe connections are firmed locked by clips. Check the drying hopper cleaning door is sealed. Check that the piping system is correct. Check if the honeycomb-rotor is damaged or not.

  • Page 55: Monthly Checking

    Check and clean air filter. Check the function of solenoid valve. Check motor overload relay and anti-phase function. Check whether air pipe is shed, leaked and loose. 6.6.5 Monthly Checking Check whether the pipe heater is normal. Check the working condition of electrical components. Check if the transmission belt is loose or not.

This manual is also suitable for:

Sd h-sm seriesMhd-20uMhd-40uMhd-80uMhd-120uMhd-160u ... Show all
