Summary of Contents for Rockwell Automation Allen-Bradley 1606-XLB60BH
- Page 1 DC Power Supply - 12V, 5 A, 60 W, Single-phase Input Catalog Number 1606-XLB60BH Reference Manual Original Instructions...
- Page 2 If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
-
Page 3: Table Of Contents
Additional Resources ..........23 Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... - Page 4 Notes: Rockwell Automation Publication 1606-RM117A-EN-P - July 2020...
-
Page 5: Terminology And Abbreviations
The 1606-XLB60BH is part of a series of compact, industrial grade DIN rail power supplies that focuses on the essential features that are needed in present day industrial applications. The excellent cost/performance ratio does not compromise quality or reliability. Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 6: Specifications
36 x 90 x 91 mm Size (W x H x D) Without DIN rail (1.42 x 3.54 x 3.58 in.) Weight 225 g (0.5 lb) — Catalog Numbers Catalog Number Description 1606-XLB60BH Power supply Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 7: Ac Input
Figure 5 - Power Factor Versus Output Load at 12V Output Voltage Input Current, typ Power Factor, typ 1.25 A a) 100V AC b) 120V AC c) 230V AC 0.75 a: 100V AC b: 120V AC c: 230V AC 0.25 Output Current Output Current Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 8: Input Inrush Current
Figure 7 - First Inrush Peak at 120V AC and 25 °C (77 °F) Ambient Figure 8 - Typical Turn-on Behavior at 230V AC and 25 °C (77 °F) Ambient Figure 9 - First Inrush Peak at 230V AC and 25 °C (77 °F) Ambient Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 9: Output
Figure 11 - Intermittent Current at Short Circuit, Typ Output Voltage Adju stment ra nge Output Current Normal Normal Short -circuit operation operation A: continuous current B: intermittent current Output Current 170 ms 170 ms 170 ms Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 10: Hold-Up Time
Zero Transition Input Voltage - 5% a) 12V 2.5 A typ Output b) 12V 2.5 A min Voltage c) 12V 5.0 A typ d) 12V 5.0 A min Hold-up Time 230V AC Input Voltage Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 11: Efficiency And Power Losses
Figure 17 - Losses Versus Input Voltage at 12V, 5 A, Typ Efficiency Power Losses 10 W 90.5 90.0 89.5 89.0 88.5 88.0 225 260V AC 225 260V AC Input Voltage Input Voltage Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 12: Functional Diagram
- Negative (return) output DC OK status indicator (green) The status indicator is on when the output voltage is above 9V. Output voltage adjustment potentiometer Input terminals L: Phase (Line) input N: Neutral conductor input Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 13: Connection Terminals
At 12V, 2.5 A and 40 °C (104 °F) Lifetime expectancy 252 khr 292 khr 335 khr At 12V, 5 A and 25 °C (77 °F) 680 khr 704 khr 724 khr At 12V, 2.5 A and 25 °C (77 °F) Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 14: Mean Time Between Failure
The device is used on AC 100V mains with more than 3.6 A load. • The application is sensitive to short output voltage dips during mains interruptions, even with a length shorter than 20 ms. Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... - Page 15 Fulfilled, tested with non-pulsing constant current loads. Switching frequency information is provided in the following table. Type of Switching Value Notes Frequency Main converter 40…140 kHz Dependent on input voltage and output load Rockwell Automation Publication 1606-RM117A-EN-P - July 2020...
-
Page 16: Environment
A... Tamb < 60 °C B... Tamb < 50 °C A...continuous C... Tamb < 45 °C B... short term (300 s max) Altitude 2000 4000 5000 m +70 °C 54 kPa Ambient Temperature (1) Atmospheric pressure Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 17: Safety And Protection Features
Test or Setting Time Type test 60 s 3000V AC Routine test 2500V AC Field test 2000V AC Cutoff current setting for field test — > 2 mA Figure 22 - Dielectric Strength Input Output Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 18: Approvals And Fulfilled Standards
Administrative Measures for the Restriction of the Use of RoHS (China RoHS 2) Hazardous Substances in Electrical and Electronic Products 25 years EAC Certificate EAC EurAsian Conformity - Registration Russia, Kazakhstan, and Belarus Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 19: Physical Dimensions And Weight
(0 in.) to 15 mm (0.59 in.). Penetration protection Small parts like screws and nuts with a diameter larger than 4.2 mm (0.165 in.). Figure 23 - Front View Figure 24 - Side View All dim ensions in mm Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 20: Series Operation
Such a phase-to-phase connection is allowed as long as the supplying voltage is +10% below 240V Ensure that the wire, which is connected to the N-terminal, is appropriately fused. Figure 26 - Operation on Two Phases Power Supply Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... -
Page 21: Use In A Tightly Sealed Enclosure
Parallel Use to Increase Output Power Do not parallel devices for higher output currents. Parallel Use for 1+1 Redundancy This device is not recommended to build redundant systems since there is no monitoring (DC OK signal) included. Rockwell Automation Publication 1606-RM117A-EN-P - July 2020... - Page 22 Notes: Rockwell Automation Publication 1606-RM117A-EN-P - July 2020...
-
Page 23: Additional Resources
DC Power Supply - 12V, 5 A, 60 W, Single-phase Input Reference Manual Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Provides guidance on how to conduct security assessments, implement Rockwell System Security Design Guidelines Reference Manual,... - Page 24 At the end of life, this equipment should be collected separately from any unsorted municipal waste. Rockwell Automation maintains current product environmental information on its website at rok.auto/pec. Allen-Bradley, expanding human possibility, FactoryTalk, and Rockwell Automation are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
