- Page 1 866.332.2403 (TOLL FREE); 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE SUNSET PATIO PAVILION...
- Page 2 P| 1 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 3 P| 2 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 4 P| 3 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 5 Step 2: Use 5/16´´ X 4´´ Lag Bolts (B) and 3” Deck Screws (C) to attach the Single Supports-A (2) to the Central Supports (4). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3” Deck Screws 5/16´´ X 4´´ Lag Bolts P| 4 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 6 Step 4: Use 3/8´´ X 8´´ bolts (D) to attach the Single Supports-A (2) to the post (1). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 8´´Bolts P| 5 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 7 Step 6: Use 3/8” x 7” Bolts (E) to attach the In-Between Blocking (5) to the Supports. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 7´´ Bolts P| 6 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 8 Step 8: Attach the In-Between covers (6) to the Supports with 3” Deck Screws (C). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3” Deck Screws P| 7 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 9 Step 10: Use 3/8” x 2” lag bolts (F) to attach the L-Plaques (11) to the posts (1), and to the supports. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8” x 2” Lag Bolts P| 8 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 10 Step 12: Use 2” Deck Screws (H) to attach the Roof Boards (8) to the Supports. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 2” Deck Screws P| 9 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 11 Step 13: Finally, attach the boots (9) to the posts with 3´´ Deck Screws (C). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3´´ Deck Screws P| 10 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
- Page 12 This completes the Pergola assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 11 THE SUNSET PATIO PAVILION www.ForeverRedwood.com...
