- Page 1 v1.0 ASSEMBLY GUIDE Baker Co ee Table...
- Page 2 Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Leg Base x 2 Table Top x 1 Middle Rail x 1 Leg x 2...
- Page 3 Insert two dowels into the diagonal holes on the Step 1 mounting plate (3). Repeat this for the second mounting plate. A x 2 Align a leg with the leg base and the mounting Step 2 plate (2). Attach the parts together. Secure the base with long bolts using the Allen key and the...
- Page 4 Screw a steel dowel into the side hole on the Step 3 leg base using a screwdriver. Ensure that the holes are facing the bottom as shown in the diagram. Repeat this for the other leg base. Insert wooden dowels into the holes on each end of the middle rail (5).
- Page 5 Align one of the formed leg structures to the Step 4 underside of the table top so that the holes overlap. Secure them with M6 short bolts using the Allen key (E). D x 8 E x 1...
- Page 6 Attach the middle rail to the leg that was xed Step 5 in the previous step. Make sure the holes on the rail are facing the bottom as shown in below diagram. Attach the second leg to the rail and make sure that the holes on the mounting plate are aligned with the holes on the table top.
- Page 7 Secure the middle rail with grub screws using a Step 6 screwdriver. C x 2...
- Page 8 Place the table upright on a level surface. Step 7 Enjoy your new co ee table!
