- Page 1 ASSEMBLY GUIDE Bristol Entertainment Unit...
- Page 2 Components Upon unpacking your entertainment unit from it’s delivery box, you should have the separate pieces shown below. Follow the steps on the next pages to assemble your entertainment unit. Side Rail x 2 Carcass x 1 Leg x 2 Connecting Rail x 2 Hardware A x 8...
- Page 3 Insert dowels into the outer holes of the legs Step 1 (2). It is optional to use the glue over the dowels. Insert cam screws into the inner holes of the legs and x them using a screwdriver. Insert cam locks into the outer holes of the side rails (3), making sure the mouth is facing the screw hole.
- Page 4 Insert dowels into the inner holes on the Step 2 bottom of the carcass (1). It is optional to use the glue over the dowels. Insert cam screws into the outer holes on the bottom and x them using a screwdriver.
- Page 5 Align the connecting rails with the inner faces of Step 3 the leg structure. Fit a washer to a bolt screw into the corresponding holes to secure the rails to the carcass. Secure the connecting rails to the leg structure using long screws (F). F x 16 G x 10 H x 10...
- Page 6 With another person, lift the entertainment unit o Step 4 the ground and place it upright on a level surface. Enjoy your new entertainment unit!
