- Page 1 ASSEMBLY GUIDE Baker Extendable Dining Table...
- Page 2 Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Table top x 1 Rail x 1 Leg x 2 Leg Base x 2...
- Page 3 Insert two dowels into the diagonal holes of the Step 1 leg (2). Repeat this for the second leg. A x 4 Align a leg with the leg base (3). Fit the parts Step 2 together and secure them with long bolts using the small Allen key (F).
- Page 4 Screw a steel dowel into the embedded nut Step 3 which is in the slot of the leg base. Ensure that the hole is oriented as below diagram indicates. Repeat this for the other base. Screw two steel dowels into the embedded nuts on top of the leg.
- Page 5 Fit the formed leg structure to the rail with the Step 4 steel dowels inserted into the holes on the side. Make sure the holes on the rail are facing down. Secure them with grub screws using the big Allen key (E). C x 2 E x 1...
- Page 6 Place the table top on a level surface with Step 5 bottom facing up and turn the runner lock on. Align formed leg structure with the table top and secure it with grub screws using the big Allen key (E). Insert a short bolt into the side hole and secure it using the small Allen key (F).
- Page 7 To extend the table, take the extension leaf out of Step 6 the storage bag (6). Unlock the runner locks and metal locks under the Step 7 table top and slide two parts apart.
- Page 8 Insert the extension leaf into the formed space. Step 8 Make sure the dowels are aligned correctly. Slide the extension leaf towards one half of the table top. Slide the remaining half of the table top towards the extension leaf and x all the locks back.
- Page 9 Reverse the process above to switch the table to the Step 9 compact form. Place the extension leaf back into the storage bag Step 10 and close it.
- Page 10 Place the bag upon the rails of the table top and Step 11 close it. Switch the locks back on.
- Page 11 Enjoy your new dining table! Step 12...
