- Page 1 ASSEMBLY GUIDE Baker Entertainment Unit...
- Page 2 Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Body x 1 What you need...
- Page 3 Drawer Adjustment 1. Door Adjustment Drawer door could be adjusted vertically by ±2.5mm. Turn the knob under- neath the drawer to adjust the vertical position so that there are equal gaps above and below the front panel. +2.5 -2.5...
- Page 4 2. Drawer Uninstallation To take the drawer out, open it, pull the lock button underneath the drawer base panel [1]. Gently lift the front part of the drawer so that the brackets at the front of the runners separate from the holes on the side panels of the drawer [2].
- Page 5 3. Drawer Installation To put the drawer back in, place the drawer upon the runners and t the brackets at the back of the runners into the holes of the drawer [1]. Gently put down the front part of the drawer so that the brackets at the front of the run- ners t into the holes on the side panels of the drawer [2].
