- Page 1 ASSEMBLY GUIDE Junior Kids Wardrobe...
-
Page 2: Table Of Contents
Components Before you get started, check you have all of the pieces below. If anything’s missing, please visit www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it out right away. Top Panel x 1 Back Panel x 1 Shelf x 1 Right Side x 1... -
Page 3: A X 6
Align a leg to the underside of the base corner. Insert Step 1 a short screw into a hole and tighten with the screwdriver. Repeat for all four legs. With a help of the partner lift the storage o the ground, turn it upright and place on a at surface D x 24 Place the base on it’s legs. - Page 4 Place the top panel on it’s back. Using a screwdriver Step 3 insert cam screws into the side holes. A x 6 Place the side wall on it’s back. Using a screwdriver Step 4 insert cam screws into the smaller holes of the shelf support.
-
Page 5: B X 4
Align the side walls with the shelf so that the cam Step 5 screws t into side holes of the shelf. Insert cam locks into the top holes of the shelf and tighten using a screwdriver. B x 4... - Page 6 Align the side walls with the base and top panel so Step 6 that the cam screws t into side holes. Insert cam locks into the side holes of the walls and tighten using a screwdriver. B x 12...
-
Page 7: C X 32
Align the back side to the formed wardrobe body and Step 7 secure it with small screws using a screwdriver. C x 32... -
Page 8: D X 6
Fit the hang rail inside of the wardrobe. Step 8 Align the hinges to the side walls and secure them with two long screws using a screwdriver. Align the doors to the hinges and connect them. D x 6 E x 12... - Page 9 Adjust the door hinges as shown, using a screwdriver. Step 9...
- Page 10 Fix a mounting plate (aa) to the back of the unit Step 10 using at head screws (cc). By using appropriate fastener based upon wall com- position, x another mounting plate (aa) to the wall. Connect two plates with the nylon srap (bb). Tighten the strap so that the unit is xed in the place.
- Page 11 Enjoy your new wardrobe! Step 11...
