Recommended Spare Parts - Hypertherm HyPerformance Plasma HPR400 Instruction Manual

Parts List

Recommended spare parts

Power supply
Part
Number
129633
129792
127039
027079
003149
229213
003232*
003228**
109004
229238
008551
141030
041802
108028
108075
108709
228171
228230
141027
* 200/208, 220 and 240 volt power supplies
** 380, 400, 440, 480 and 600 volt power supplies
cooler
Part
Number
041897
008756
027634
027664
027926
229235
006113
229229
141033
Ignition console
Part
Number
041817
129854
6-22
Description
Green power lamp assembly
Chopper assembly
6" fan: 230 CFM, 115 VAC 50-60 HZ
10" fan: 450-550 CFM, 120 VAC 50-60 HZ
Relay: Pilot arc, 120 VAC
PCB: I/O
Contactor
Contactor
Current sensor: Hall 100 amp, 4 volt
Start circuit assembly
Fuse: 7.5 amp, 600 volt
PCB: Control
PCB: Power distribution
Fuse: 3 amp, 250 volt
Fuse: 6.3 amp, 250 volt (slow-blow)
Fuse: 10 amp, 250 volt
Kit: Pump with clamp
Kit: Motor with clamp
PCB: Pump motor drive
Description
PCB: Console power distribution
Fuse: 5 amp, 250 volt (slow-blow)
Filter housing (on the rear panel of the cooler)
Filter element
Filter housing (under the coolant tank)
Flow sensor
Check valve: 3/8" FPT
Solenoid valve
PCB: Cooler sensor
Description
HFHV Ignition PCB
Transformer
Designator
CH1, CH2, CH3, CH4
CR1
CON1
CON1
CS1, CS2, CS3, CS4
PCB1
F1, F2
PCB3
PCB2
F5, F6, F7
F1, F2, F3
F4
PCB7
Designator
F1
FS1
Designator
T1
HPR400XD Auto Gas – 806160
qty.
1
1
1
1
1
1
1
1
1
1
2
1
1
3
3
1
1
1
1
qty.
1
1
1
1
1
1
1
1
1
qty.
1
1
