Page 3
3. Remove the four (4) screws that secure B1 to the Control Box. Keep the screws for installing the replacement PC-104 stack (141023). 4. Remove the old PC-104 stack (041664) and cables. Remove the compact flash card from the old PC-104 stack, carefully package it, and ship it back to Hypertherm for a return credit. Field Service Bulletin...
Page 4
HD4070 PC-104 UPGRADE Figure 1 – Breakout board Figure 1.1 – Floppy disk drive B1, J25 Figure 1.2 – Power cable Field Service Bulletin...
Page 5
HD4070 PC-104 UPGRADE Install the new PC-104 stack and cable (141023) 1. Place the new PC-104 stack (141023) into the Control Box, and orient it so that the CPU heatsink on B1 is on the same side as the DC Power Supplies (See figure 2).
Page 6
HD4070 PC-104 UPGRADE 4. Reinstall the PC-104 ribbon cable connectors to the breakout board and the floppy drive in the following order (see Figure 1 and Figure 4). a. J5 on the Breakout Board (Analog/Digital I/O ribbon cable to B6, J1) b.
