Frost Fighter IDH200QR OIL Installation - Operation/Maintenance Instructions And Parts List

Frost Fighter IDH200QR OIL Installation - Operation/Maintenance Instructions And Parts List

Indirect fired space heaters

Advertisement

Quick Links

FROST
FROST
FROST
INDIRECT FIRED SPACE HEATERS
MODEL IDH200QR OIL
MODEL IDH200QR LP/NG
Installation - Operation/Maintenance
Instructions and Parts List
READ INSTRUCTIONS PRIOR TO STARTING HEATERS
FROST FIGHTER INC.
100-1500 NOTRE DAME AVE
WINNIPEG, MANITOBA
CANADA R3E 0P9
TEL : (204) 775-8252
FAX: (204) 783-6794
WWW.FROST-FIGHTER.COM
TOLL FREE 1-888-792-0374
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IDH200QR OIL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Frost Fighter IDH200QR OIL

  • Page 1 FROST FROST FROST INDIRECT FIRED SPACE HEATERS MODEL IDH200QR OIL MODEL IDH200QR LP/NG Installation - Operation/Maintenance Instructions and Parts List READ INSTRUCTIONS PRIOR TO STARTING HEATERS FROST FIGHTER INC. 100-1500 NOTRE DAME AVE WINNIPEG, MANITOBA CANADA R3E 0P9 TEL : (204) 775-8252 FAX: (204) 783-6794 WWW.FROST-FIGHTER.COM...
  • Page 2 6. The heat exchanger shows no signs of an implosion or explosion. No representative of Frost Fighter Inc., nor any of its distributors or dealers, is authorized to assume for Frost Fighter Inc. any other obligations or liability in connection with this product, nor alter the terms of the warranty in any way.
  • Page 3: Specifications

    SPECIFICATIONS MAXIMUM PUMP FUEL ELECT. HEATED APPROVAL AGENCY INPUT NOZZLE PRESSURE TANK SUPPLY WEIGHT MODEL SIZE CAPACITY (CFM) (APPROX) IDH200QR 170,000 1.0 X 60'B 18 USGAL 115v 15 A 1500 209 LBS BTU/HR 72 LITERS 95 KG MAXIMUM MANIFOLD MINIMUM ELECT.
  • Page 4 Dimensions of IDF350-II and of the IDF500 Heaters FROST FROST Heater Only With Packaging MODEL WEIGHT (LBS) WEIGHT (LBS) 83" 27" 38" 52 1/2" 51" 76 1/2" IDF350 83" IDF500 51" 76 1/2" 38" 27" 52 1/2" Heater Only With Packaging MODEL WEIGHT (LBS) WEIGHT (LBS)
  • Page 5 INSTALLATION- OPERATION MAINTENANCE INSTRUCTIONS FOR LP/NG READ INSTRUCTIONS PRIOR TO OPERATING HEATER GENERAL HAZARD WARNING FAILURE TO COMPLY WITH PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR ELECTRICAL SHOCK.
  • Page 6 GENERAL NOTES: 1. The heater is designed and approved for use as a construction heater under ANSI Z83.7 with the applicable requirements of UL 795 and under CGA 2.14 with applicable requirements of CAN/CSA 3.2. The intended use is for 5 the temporary heating of building or structures under construction, alteration or repair.
  • Page 7: Installation Clearances

    INSTALLATION INSTRUCTIONS FOR OIL 1. The recommendations of local authorities having jurisdiction must be followed. For recommended Installation practices refer to C.S.A. Standard B139 (CANADA) or NFPA 54 (US) 2. When firing the unit in an enclosed area 3 square feet must be provided to allow the free entry of the air required for operation.
  • Page 8 OPERATING INSTRUCTIONS TO START HEAT WITH GENISYS OIL CONTROL Ensure unit is on flat, level ground before starting, canopy and fan guards must be closed. Flip switch to “OFF” position Check fuel level ( 2-4 gallons to start) Plug in supply cord to 115 volt outlet. Flip switch to “MANUAL”...
  • Page 9 IDH OIL MAINTENANCE INSTRUCTIONS !WARNING!: Heaters should be fully serviced annually to ensure proper performance. Maintenance should be performed by trained personnel only. Incorrect maintenance may result in improper operation and serious injury. HIGH LIMIT SWITCH The limit switch should be checked every heating season to ensure the burner will shutdown if temperature exceeds 220 F.
  • Page 10: Cleaning Procedure

    UNIT MODEL SHUTTER BAND BURNER MODEL IDH200QR OIL IDH200LPNGQR ***Note: The above settings are approximations based upon clean equipment in proper working order. Combustion air adjustments will vary with location, altitude and type of fuel used. Due to the increased density of #2 oil at colder temperatures, kerosene fuel must be used or the oil nozzle change as follows at temperatures below 8'F/-10'C.
  • Page 11 IDH 350QR, IDH-II350QR & IDH500QR WIRING DIAGRAM MALE PLUG (115V/1 /60Hz) Ø GREEN WHITE GROUND POWER ON BLACK WHITE FAN MOTOR THERMOSTAT BLUE THERMOSTAT RECEPTICLE THERMOSTAT BLACK WHITE BLACK CAPACITOR(S) MANUAL GREEN WHITE GROUND 15AMP BURNER IGNITION CONTROL OR BREAKER HIGH LIMIT SWITCH BLACK...
  • Page 12 TEMPERATURE FEELER ADJUSTMENT : (Attached to fan switch) ALWAYS MAKE SURE THAT THE TEMPERATURE FEELER IS TOUCHING THE HEAT EXCHANGER!! The temperature feeler provides air flow over the fan switch, which regulates the cycling of the fan. The temperature feeler can be adjusted for different outside temperatures, by rotating the location of the temperature feeler holes.
  • Page 13 ELECTRODE SETTINGS FOR IDF350-II & IDF500 MODELS SLIDE PLATE SETTINGS FOR IDF350-II & IDF500 MODELS IDF350-II IDF500...
  • Page 14 Check/Adjust ‘Z’ Dimension - V1 Heads 2. Use the following procedure to adjust the “Z” dimension, if it is not correct: Turn off power to the burner. Disconnect the oil connector tube from the nozzle line. See fi gure above. Loosen the splined nut from the nozzle line. Loosen the hex head screw securing the head adjusting plate to the burner housing.
  • Page 15 IDH200LPNG QR OPERATING INSTRUCTIONS...
  • Page 16 IDH200LPNG QR OPERATING INSTRUCTIONS...
  • Page 17 IDH200 QR LPNG TROUBLE SHOOTING GUIDE...
  • Page 18 IDH200 QR LPNG TROUBLE SHOOTING GUIDE...
  • Page 23 IDH OIL TROUBLE SHOOTING GUIDE ALWAYS DOUBLE CHECK FOR SUFFICIENT POWER , GAUGE OF CORD (SEE TOP OF PAGE #5) AND PROPER FUEL SUPPLY. POWER AND FUEL SUPPLY MUST BE SHUT OFF/DISCONNECTED BEFORE REMOVING OR REPLACING ANY COMPONENTS ON THE HEATER. 1.
  • Page 24 IDH TROUBLE SHOOTING GUIDE d. Wires between cad cell and primary control should be checked to see that they are not pinched or crimped.. e. Prime fuel pump by loosening bleeder screw till steady stream of fuel comes out to ensure no air or bubbles in fuel line..
  • Page 25 Sequence of Operation for Genisys Controller Burner States Standby: The burner is idle, waiting for a call for heat. Valve-On Delay: The igniter and motor are on while the control delays turning on the oil solenoid valve for 45 seconds.. Trial For Ignition: The oil solenoid valve is energized.
  • Page 26 IDH200QR GAS BURNER PARTS Item Part # Description Item Part # Description BG 21002 Cg4 HEAD/SHROUD ASSY B20140 1/7 HP BURNER MOTOR BG 21003 AIR TUBE ASSY FOR IDH200 BG 21011 GENISYS PRIMARY (GAS) BG 21004 COVER PLATE BG 21012 IGNITOR AND GASKET BG 21005 GAS TRANSFORMER IDH...
  • Page 27 LIMITS, FAN SWITCHES AND TEMPERATURE FEELERS ADJUSTABLE FAN SWITCH 90-130’F ( 48111B) ALL MODELS OHV HIGH LIMIT C9648 HIGH LIMIT L220 - 40F (48110A) FEELER ALL MODELS (48171) Indoor and outdoor settings of fan switch Indoors & if surrounding air is warm i.e. -5C/23F-Fan switch should be set to 115’ or higher so as to shut down unit when heat exchanger is properly cooled, also keeps fan motor from excessive running on when discharging cooler air.

This manual is also suitable for:

Idh200qr lpIdh200qr ng
