Maple Systems HMC7030A-L Quick Start Manual page 2

Getting Started:
Perform the following steps to configure and use the HMC7000
Series unit:
1. Install MAPWare-7000 software.
2. Create your project.
3. Connect a programming cable (USB preferred).
4. Save your project.
5. Download project to HMC7000 (note: you must
select the Download Firmware option for the initial
download).
6. The HMC7000 unit is ready to use in the system.
PLC Connecting Cables:
Contact Maple Systems to order any PLC Communications
Cables or to download a cable pinout diagram.
Configuration:
Use MAPware-7000 to assign input (X and XW), output (Y and
YW), and configuration (M and MW) memory addresses to the
built-in I/O modules.
Function Register
X0-X11 Inputs X00000-011 (XW0000)
Y0-Y7 Outputs Y00000-007 (YW0000)
High Speed HSC Channel HSC Channel
Counter 1 2
Option
HSC Input X1(terminal) X2(terminal)
X00001 (reg) X00002 (reg)
HSC Reset X4(terminal) X5(terminal)
Input X00004 (reg) X00005 (reg)
HSC Output Y0(terminal) Y1(terminal)
Flag Y00000 (reg) Y00001 (reg)
HSC MW0010 MW0020
Configuration
Register
HSC Counter MW0011 MW0021
Register MW0012 MW0022
(Current
Value)
HSC Preset MW0013 MW0023
Register MW0014 MW0024
HSC Enable Bit M00240 M00400
HSC Reset Bit M00241 M00401
Reference the table below when configuring each HSC
Configuration Register (MW0010 and MW0020):
Bits Function
15-4 Not used
3 0 : Falling Edge
1 : Rising Edge
2, 1, 0 Module Operating Mode :
000 : Normal Operation
010 : Up Counter HSC
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: maple@maplesystems.com • www.maplesystems.com
Doc. No. 1011-7030AL
To implement High Speed Counter Operation:
1. Connect a device to X1 (Channel 1) or X2 (Channel 2)
that will provide the high speed pulses to the
expansion module.
2. Configure for HSC mode using the configuration
register MW0010 (Channel 1) or MW0020 (Channel
2).
3. Write the HSC preset count value in MW0013
(Channel 1) or MW0023 (Channel 2).
4. Enable the HSC by setting the HSC Enable Bit
M00240 (Channel 1) or M00400 (Channel 2).
5. HSC increments (starting from 0) the current value
register in MW0011 (Channel 1) or MW0021
(Channel 2) until the preset value is reached. Then
HSC sets Y0 (Channel 1) or Y1 (Channel 2).
6. Enable the HSC Reset Bit by setting M00241
(Channel 1) or M00401 (Channel 2). Or by setting
Reset Pin X4 (Channel 1) or Reset Pin X5 (Channel
2). This will cause the HSC current value to reset
back to 0 and the output Y0 (Channel 1) or output
Y1 (Channel 2) will reset (clear) to 0.
Access
7. To start the process again, simply reset (clear) the
Rd Only
HSC Reset Bit and set the HSC Enable Bit. Note: if
the HSC Enable Bit is still ON, you must reset (clear)
Rd/Write
this bit, and then set it again.
Additional Resources:
Detailed instructions on the operation and installation of the
HMC7000 Series are available in the HMC7000 Programming
Rd Only
Manual that is included with the MAPware-7000 configuration
software. MAPware-7000 also includes help files which
Rd Only
provide detailed information on using the configuration
software.
Rd/Write
Class I Division 2 Wiring Considerations:
Rd/Write
Hazardous Location
Class I Division 2
Rd/Write
Groups A, B, C, and D
HMC7030
USB Port
Rd/Write
JP9
V =3.3 VDC
max
Rd/Write
I =150 mA
max
Rd/Write
L =0
i
C =9pF
i
Capacitance and inductance of field wiring from intrinsically
safe equipment to the associated apparatus must be included
in the system calculations as shown in Table 1. Cable
capacitance, C , plus intrinsically safe equipment capacitance,
cable
C , must be less than the marked capacitance, C
i
on any associated apparatus used. The same applies for
inductance (L , L and L
cable i
cable capacitance and inductance per foot are not known, the
following values shall be used: C
Page 2 of 2
Non-Hazardous
Location
Associated Apparatus
USB Port
V <3.3 VDC
oc
I <2.2 mA
sc
L >L + L
a i cable
C >C + C
a i cable
(or C ), shown
a o
or L , respectively). Where the
a o
= 60 pF/ft, L = 0.2 μH/ft.
cable cable
Model: HMC7030A-L
TABLE 1:
I.S. Equipment Associated Apparatus
V (or U ) > V or V (or U
max i oc t
I (or I ) > I or I (or I
max i sc t
C + C < C (or Co)
i cable a
L + L < L (or L )
i cable a o
Wiring method must be in accordance with ANSI/NFPA70
Associated apparatus may be in a Division 2 or Zone 2 location
if so approved.
Associated apparatus must be installed in accordance with its
manufacturer's control drawing and National Electrical Code
for installation in the United States and Canadian Electrical
Code for installation in Canada.
WARNING: DO NOT REMOVE OR REPLACE WHILE CIRCUIT
IS LIVE UNLESS THE AREA IS KNOWN TO BE FREE OF
IGNITIBLE CONCENTRATIONS OF FLAMMABLE SUBSTANCES.
This equipment is suitable for use in Class I, Division 2, Groups
A, B, C and D or non-hazardous locations only.
WARNING – EXPLOSION HAZARD – Do not disconnect
equipment unless power has been removed or the area is
known to be non-hazardous.
WARNING – EXPLOSION HAZARD - Substitution of
components may impair suitability for Class I, Division 2.
WARNING - CAUTION, Battery May Explode If Mistreated.
Do Not Recharge, Disassemble Or Dispose Of In Fire.
WARNING - Replace Battery with type CR1225FH-LF,
manufactured by Renata SA, only. Use of Another Battery May
Present A Risk Of Fire Or Explosion. See Owner's Manual for
Safety Instructions.
It is recommended that the user periodically inspect the sealed
devices used, check for any degradation of properties, and
replace as necessary.
For Technical Support:
Please contact Maple Systems if you have any questions
regarding this product. We ask that you provide us with the
unit serial number and firmware revision number written on
the product label of the unit. If applicable, please provide us
with the type of PLC used in your application.
Maple Systems Inc.
808 134 St. SW, STE 120
th
Everett, WA 98204
Tel: 425-745-3229
Fax: 425-745-3429
Email: support@maplesystems.com
Website: www.maplesystems.com
Rev. 04, 03/13/18
)
