- Page 1 User Manual 1/2.8" HD Camera, Day&Night, 2592x1944, 2.5mm, 12VDC MEM-44F0025M0A MEM-44F0025MPA...
- Page 2 CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN CAUTION RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT REMOVE COVER(OR BACK). CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK NO USER-SERVICEABLE PARTS INSIDE.
-
Page 3: Table Of Contents
Contents Contents Precautions Safety Instructions General Features Menu Set Up Set Up Menu ▶ Menu Set Up ▶ Lens ▶ ▶ Exposure ▶ Backlight ▶ Day&Night ▶ White Bal ▶ ▶ Image ▶ System ▶ Exit ▶ Trouble Shooting - 3 -... -
Page 4: Precautions
Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly. -
Page 5: Safety Instructions
Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use a UL approved regulated 24 volt AC or 12 volt DC power supply ◑... -
Page 6: General Features
General Features Transfer Video Interface ● The combination of a 4Mega CMOS image sensor and HD-Analog DSP provides an excellent resolution of HD-Analog picture. ● Smart DNR prevents the image blurring of moving object and activates only if moving objects are appearing on the scene. -
Page 7: Menu Setup
How to Set Up the camera menu MENU SETUP 1.LENS DC, MANUAL LENGTH 0 ~ 6 default : 0 2.ALC RETURN / EXIT - SAVE, CANCEL BRIGHTNESS 0~20 default : 10 INDOOR, OUTDOOR, DEBLUR AUTO MODE RETURN / EXIT - SAVE, CANCEL SHUTTER 1/25, 1/50, 1/100, 1/200, 1/400, 1/800, 1/1600, 1/3200, 1/6400, 1/12800, 1/25600 50Hz... - Page 8 AUTO, AUTOext, PRESET C-TEMP 3000K, 5000K, 8000K 6. WHITE BAL R-GAIN 0~20 default : 10 MANUAL B-GAIN 0~20 default : 10 RETURN / EXIT - SAVE, CANCEL 7. DNR OFF/LOW/MIDDLE/HIGH 0~10 default : 5 SHARPNESS 0~20 default : 12 COLOR GAIN 0.45, 0.55, 0.65, 0.75 GAMMA ON, OFF...
- Page 9 LANGUAGE ENG, CHN, CHN(S), JPN, KOR CAM TITLE RIGHT UP, LEFT DOWN U,D - CHAR SELECT / L,R - POSITION / ENTER - RETURN ON-PUSHING RESET RETURN / EXIT - SAVE, CANCEL 10. EXIT - 9 -...
-
Page 10: Menu Set Up
Menu Set Up Menu setting can be selected by the button inside the camera. 1. Press the set button. * The Set Up menu will be displayed on the monitor. MENU 1.MOTORIZED 2.EXPOSURE AUTO 3.BACKLIGHT 4.DAY&NIGHT EXTERN 5.WHITE BAL AUTO 6.DNR MIDDLE 7.IMAGE... -
Page 11: Lens
1. LENS 1. Move the triangular indicator to LENS using the Up and Down buttons on the Set Up menu screen. 2. Select the desired LENS type by pressing the SET button. MENU 1.LENS 2.ALC 3.EXPOSURE AUTO 4.BACKLIGHT 5.DAY&NIGHT AUTO 6.WHITE BAL AUTO 7.DNR... - Page 12 MENU 1.LENS 2.ALC 3.EXPOSURE AUTO 4.BACKLIGHT 5.DAY&NIGHT AUTO 6.WHITE BAL AUTO 7.DNR MIDDLE 8.IMAGE 9.SYSTEM 10.EXIT 2. Select the desired shutter mode by pressing the Left or Right button. 2. EXPOSURE BRIGHTNESS 10 IIIIIIIIIIIIIIIIIII| SHUTTER AUTO SENS-UP IIIIIIIIIIIIIIIIIII| RETURN ◆ BRIGHTNESS : The brightness can be adjusted. The brightness control range is 1~20. ◆...
-
Page 13: Backlight
4. BACKLIGHT On this menu, backlight image can be compensated by users selecting one of modes. (HLC, BLC, WDR) 1. Move the triangular indicator to BACKLIGHT on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1.LENS 2.ALC... -
Page 14: Day&Night
◆ WDR : The WDR (Wide Dynamic Range) function works to correct excessive light within the frame to produce a usable image. When the image has simultaneous bright and dark areas, it makes both areas distinct. If you select WDR, a submenu appears where you can make finer adjustments. WDR MODE FRAME ROI MODE... - Page 15 MENU 1.LENS 2.ALC 3.EXPOSURE AUTO 4.BACKLIGHT 5.DAY&NIGHT AUTO 6.WHITE BAL AUTO 7.DNR MIDDLE 8.IMAGE 9.SYSTEM 10.EXIT ◆ AUTO : Automatically, It shifts into the color mode in the bright environment and the B/W mode in the low light condition. It can adjust the delay time, starting brightness and end brightness according to the ambient conditions by pressing the Set button.
-
Page 16: White Bal
6. WHITE BAL Use this function when the color adjustment of a screen is needed. 1. Move the triangular indicator to WHITE BAL on the SETUP menu screen using the Up and Down button. 2. Select the desired mode by using the left or Right button. MENU 1.LENS 2.ALC... -
Page 17: Image
MENU 1.LENS 2.ALC 3.EXPOSURE AUTO 4.BACKLIGHT 5.DAY&NIGHT AUTO 6.WHITE BAL AUTO 7.DNR MIDDLE 8.IMAGE 9.SYSTEM 10.EXIT 8. IMAGE When selecting, the following submenu will appear. MENU 1.LENS 2.ALC 3.EXPOSURE AUTO 4.BACKLIGHT 5.DAY&NIGHT AUTO 6.WHITE BAL AUTO 7.DNR MIDDLE 8.IMAGE 9.SYSTEM 10.EXIT Here you can optimise the image quality by adjusting different options. - Page 18 ◆ GAMMA [0.45 ~ 0.75] : Changes the gamma curve of the camera. ◆ MIRROR [ON, OFF] : Mirrors the image horizontally on the screen. ◆ FLIP [ON, OFF] : Flips the image vertically on the screen. ◆ D-ZOOM: You can use the digital zoom with x1~x16 magnifications. ◆...
-
Page 19: System
Y LEVEL [0~20] : Define the brightness of the mask color. CB LEVEL [0~20] : Define the blue amount of the mask color. CR LEVEL [0~20] : Define the red amount of the mask color. TRANS [0~3] : Applies a tone from the window to act on the selected area. 9. -
Page 20: Exit
◆ IMAGE RANGE : Adjust the rate of YC signal to 100%(FULL), 75%(COMP) or 100%~75%(USER). ◆ LANGUAGE : ENG, CHN, CHN(S), JPN, KOR ◆ CAM TITLE : It can be adjusted when you get into the Cam Title menu. This function is to display the letters of the camera on the monitor. -
Page 21: Trouble Shooting
Trouble Shooting PROBLEM POSSIBLE CAUSE Nothing appears on ☞Check the power cable, power supply output and video the screen. connection between the camera and monitor. ☞Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞Adjust the monitor controls, as required. - Page 25 VIDEOR E. Hartig GmbH Exclusive distribution through special- ised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
