- Page 1 User Manual 1/2.9” HD Dome, Fixed, Day&Night, 1920x1080, 2.8- 12mm, Infrared, 12VDC, IP66 MEP-63M2812M0A...
- Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OTHER OPENINGS EQUIPMENT. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE.
- Page 3 FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC INFORMATION: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
-
Page 5: Table Of Contents
Table of Contents 1 Introduction ........................6 1.1 Features..........................6 2 Installation and Configuration ..................7 2.1 Package Contents ......................7 2.2 Installing the Camera ....................... 7 2.3 Setting the Camera ......................8 2.4 Connections ........................9 2.5 OSD Menu Structure ...................... 10 3 OSD Menu ........................ -
Page 6: Introduction
1 Introduction 1.1 Features • 1/2.9” SONY Exmor CMOS image sensor • 2.8 ~ 12mm motorized varifocal lens • True D/N (Auto, Day, Night) • 28ea IR LEDs • Auto exposure control (1/50,000 ~ x30 second) • White balance control (AWB, ATW, AWC, Indoor, Outdoor, Manual) •... -
Page 7: Installation And Configuration
2 Installation and Configuration 2.1 Package Contents The package contains the following. • Camera • Instruction Manual (This Document) • Template Sheet • Accessory Kit 2.2 Installing the Camera The camera is for use in surface or pendent mounting applications, and the mounting member must be capable of supporting loads of up to 4.5 kg. -
Page 8: Setting The Camera
2.3 Setting the Camera NOTE: Open the cover and change the video output setting. The cover should be closed after video output setting. You can set video signal with S1. Position Left Center Right Video Signal AHD Output HD-TVI Output CVBS Output... -
Page 9: Connections
2.4 Connections Connector Description DC jack 12VDC BNC jack VIDEO OUTPUT The camera must be installed by qualified service personnel in accordance with all local and federal electrical and building codes. • Connecting Video Output connector Connect the video output (BNC) connector to the video input. •... -
Page 10: Osd Menu Structure
2.5 OSD Menu Structure MAIN MENU LENS LENS EXPOSURE BACKLIGHT EXPOSURE BACKLIGHT SHUTTER DC WHITE BAL MANUAL DAY&NIGHT SENS-UP HSBLC IMAGE BRIGHTNESS FUNCTION D-WDR SYSTEM DEFOG RETURN EXIT WHITE BAL DAY&NIGHT IMAGE FUNCTION SHARPNESS AUTO MOTION COLOR D-EFFECT PRIVACY AWCSET B&W... -
Page 11: Osd Menu
3 OSD Menu 3.1 Lens MAIN MENU OUTDOOR MODE DC LENS MODE LENS MIN SHU. 1/25(30) DC EXPOSURE MODE MAX SHU. 1/2000 OUTDOOR 8 BACKLIGHT IRIS SPEED RETURN RET WHITE BAL RETURN RET DAY&NIGHT AUTO IMAGE FUNCTION ... -
Page 13: Backlight
3.3 Backlight MAIN MENU HLBLC LENS DC EXPOSURE LEVEL MIDDLE SELECT AREA1 BACKLIGHT AREA DISPLAY ON WHITE BAL DEFAULT BLACK MASK 20 DAY&NIGHT RETURN LEVEL AUTO RET IMAGE MODE NIGHT FUNCTION DEFAULT SYSTEM RETURN RET... -
Page 14: Day & Night
3.5 Day & Night MAIN MENU D&N AUTO LENS DC 205 EXPOSURE BURST DN (CDS) 3 BACKLIGHT DN (DELAY) IR SMART ON 165 WHITE BAL RETURN ND (CDS) RET 3 DAY&NIGHT AUTO ND (DELAY) IMAGE RETURN RET... -
Page 15: Function
3.7 Function FUNCTION 2DNR MIDDLE 3DNR MIDDLE MOTION RETURN RET PRIVACY DEFECT DET MOTION ALARM RETURN RET SELECT AREA1 VIEW TYPE DISPLAY OSD VIEW ON 64 3 SENSITIVITY TIME COLOR GREEN RETURN RET TRANS. 1.00 ALARM ... - Page 16 PRIVACY: Off, On Select: Area1, Area2, Area3, Area4 Display: Off, Mosaic, Inversion, Color: Use up, down, right, left buttons to adjust both position and size of area. Color: User, White, Black, Red, Blue, Yellow, Green, Cyan Transparency: 0.25, 0.50, 0.75, 1.00 Default: Default privacy settings.
-
Page 17: System
3.8 System MAIN MENU CAMERA TITLE SYSTEM LENS 0 1 2 3 4 5 6 7 8 9 DC EXPOSURE CAM TITLE A B C D E F G H I J K BACKLIGHT MONITOR LCD L M N O P Q R S T U V W X Y Z ... -
Page 18: Exit
3.9 AF MAIN MENU LENS DC EXPOSURE AF MODE SEMI BACKLIGHT ONE SHOT AF WHITE BAL TDN AF DAY&NIGHT AUTO LENS INIT IMAGE RETURN RET FUNCTION SYSTEM AF EXIT SAVE&END AF MODE: SEMI, AUTO, MANUAL ONE SHOT AF: Will focus the camera. -
Page 19: Appendix
4 Appendix 4.1 Specification Model MEP-63M2812M0A IMAGE Motorized Varifocal Lens 2.8mm ~ 12mm, F1.4, DC IRIS Angle of View 100° (H) ~ 35° (H) Type 1/2.9" SONY Exmor CMOS sensor Image Sensor Pixels 1984 (H) x 1105 (V) Color : 1.0 Lux @ F1.4, 50IRE Min. -
Page 20: Dimension
4.2 Dimension... - Page 21 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
