Brand name:
Product Name:
Model no.:
FCC ID:
IC ID:
Crystal:
Work frequency:
Federal Communications Commission (FCC) Statement
Copyright © 2011, International Technologies & Systems Corp. All rights reserved.
USER MANUAL
Xpress CM100
ID TECH
Xpress CM100
IDCA-1261
WQJ-IDCA-12X1-2
9847A-12X12
27.12MHz (RF chip), 8MHz (MCU)
13.56MHz
Advertisement
Related Manuals for IDTECH Xpress CM100
Summary of Contents for IDTECH Xpress CM100
- Page 1 USER MANUAL Xpress CM100 Brand name: ID TECH Product Name: Xpress CM100 Model no.: IDCA-1261 FCC ID: WQJ-IDCA-12X1-2 IC ID: 9847A-12X12 Crystal: 27.12MHz (RF chip), 8MHz (MCU) Work frequency: 13.56MHz...
- Page 2 IDTECH Xpress CM100 User Manual 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the ...
- Page 3 IDTECH Xpress CM100 User Manual Canada, Industry Canada (IC) Canada, Industrie Canada (IC) This Class B digital apparatus complies with Canadian ICES-003 Cet appareil numérique de classe B est conforme à la norme NMB‐003. This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et ...
- Page 4 IDTECH Xpress CM100 User Manual LIMITED WARRANTY ID TECH warrants to the original purchaser for a period of 24 months from the date of invoice that this product is in good working order and free from defects in material and workmanship under normal use and service.
-
Page 5: Table Of Contents
IDTECH Xpress CM100 User Manual TABLE OF CONTENTS Introduction ......................6 Features & benefits ....................6 Product Configurations ................... 7 Terms, Standards & Related Documents ..............7 Installation ......................8 Operation ........................ 9 Maintenance......................10 Appendix A Specifications ..................11... -
Page 6: Introduction
1. Introduction Xpress CM100 reader is a contactless smart card reader. Its primary use is in reading contactless cards for POS payment where contactless cards are used for credit and debit transactions. The ID TECH Contactless Reader supports retail applications for quick, convenient purchases where customer queuing must be minimized. -
Page 7: Product Configurations
The Xpress product has two configurations. Configuration Model Number Description RS232 IDCA-1221 Xpress CM100 reader with RS232 interface cable/connector & power supply Xpress CM100 reader with USB cable/connector IDCA-1261 4. Terms, Standards & Related Documents ANSI American National Standard Institute... -
Page 8: Installation
Functional Portion Version 2.12 5. Installation The Xpress CM100 reader should be installed in a suitable location where the unit’s environmental specifications are not exceeded. Metal plane, high heat, extreme cold, and liquids must be avoided for reliable operation. Avoid locations with direct sunlight as the UV radiation will shorten the life of the plastics and may cause color fading. -
Page 9: Operation
POS application. Responses are results from commands and can include data. No commands or operations infringe on security requirements. The full command and response protocol operations are provided in a separate document “Xpress CM100 reader API Manual”. Power-Up Sequence Each time power is applied to the Xpress, the unit performs a Power-Up sequence that Copyright ©... -
Page 10: Maintenance
7. Maintenance There are no serviceable components in the Xpress CM100 reader. Maintenance is limited to periodic cleaning of the unit to remove oils and dirt. To clean the unit, use a soft cloth moistened with warm water and a small amount of mild detergent. -
Page 11: Appendix A Specifications
IDTECH Xpress CM100 User Manual Appendix A Specifications Power Requirements Power is supplied to the unit in the following manner: RS232C interface - A/C power adapter, 5VDC +/- 10% USB interface – Hub supplied power is less than 350mA...
