C2N-AMP-4X100 and C2NI-AMP-4X100
4-Room Audio System
The Crestron®
C2N-AMP-4X100
cost-effective multiroom audio systems designed for small to
moderate-sized houses, condominiums, and businesses. Its integrated
multichannel power amplifier provides ample power for up to four rooms,
which can be expanded with additional C2N-AMP-4X100 units.
The C2N-AMP-4X100 and C2NI-AMP-4X100 are functionally identical.
For simplicity within this guide, the term "C2N-AMP-4X100 " is used
except where noted.
In the Box
1
C2N(I)-AMP-4X100 4-Room Audio System
Additional Items
6
Connector, 4-Pin (2003576)
4
Connector, 4-Pin, Right-Angle (2003584)
1
Label, Custom, Identification (4509950)
1
Label, Filler Strip, Cardstock, 3.9 in. x 0.4 in. (4509951)
C2N-AMP-4X100 Only
1
Power Cord, 6 ft 7 in. (2 m) (2001134)
C2NI-AMP-4X100 Only
1
Power Cord (varies by country)
and
C2NI-AMP-4X100
are versatile and
Install
Refer to the
Safety Instructions
The C2N-AMP-4X100 is designed for placement on a table.
Place on a Table
Place the C2N-AMP-4X100 on a table or stack on top of another device.
Quick Start
(Doc. 6607) prior to installation.
1
