- Page 2 Copyright © 2018 - All content of this document, particularly texts, photo- graphs and graphics, is protected by copyright. The copyright owner is, if not explicitly marked otherwise, the company Georg Krämer GmbH & Co. KG, Neuhauser- weg 14, A-4061 Pasching. All rights reserved, including the rights for repro- duction, publication, editing and translation of both the whole document as well as of any parts thereof.
-
Page 3: Table Of Contents
Contents ■ Contents Intended use ················································································· For your safety ············································································ Components ················································································· Control panel overview ································································· Functions 7-19 ················································································ How the control panel works ··················································· Standby mode ·········································································· Activation card ······································································ Raising & lowering the tub ····················································· Opening & Closing the drain ···················································... -
Page 4: Intended Use
Intended use / For your safety ■ Intended use Bathing system for bathing patients with restricted mobility in care institutes and hospital wards. It is operated by healthcare professionals. The possible height adjustment provides an ergo- nomic working environment for the personnel and helps keeping their spines healthy. -
Page 5: Components
Components ■ Components Disinfection Fill in spout Overflow Shower Hydromassage jets Control panel Drain Shampoo & Bath additive dispenser 10. Grab handle... - Page 6 Components Flowmeter with con- centration table care disinfection liquids Hydromassage jet USB port ...
-
Page 7: Control Panel Overview
Control panel overview ■ Control panel overview 36 37 38 39 21. Button Intensity + 1. Symbol Missing power supply 2. Symbol Tub fill temperature 22. Button Intensity - 3. Symbol Shower temperature 23. Button Underwater light 4. Display Tub fill & Shower temp. 24. -
Page 8: Functions
Functions ■ Functions How the control panel works Generally we can say that a lit button signals the availability of the corresponding function (with the exception of Sound & Vision - for details see the corresponding chapter). When you press the button you activate its function and the light starts flashing. -
Page 9: Raising & Lowering The Tub
Functions Raising & Lowering the tub The “UP” and “DOWN” buttons are used to raise or lower the tub. The movement continues until the button is released again. In the upper and lower end positions the tub stops automatically. In the event of power failure the bathtub can only be lowered, which is pow- ered by the emergency battery. -
Page 10: Setting The Temperature
Functions Setting the temperature The tub fill and the shower temperature depend on an adjustable setpoint value. When the tub fill or shower are active, the setpoint value is shown in the display “DESIRED TEMPERATURE” and the buttons “TEMPERATURE +” and “TEMPERATURE -”... -
Page 11: Shower
Functions Shower The shower can be operated at any time (except during certain parts of the disinfection procedure). To do this, simply pick up the white hand shower from its holder. The device recognizes this state automatically and activates the shower function. This is in- dicated by flashing of the symbol “SHOWER TEMPERATURE”. -
Page 12: Shampoo & Bath Additive
Functions Shampoo & Bath additive Both of these products, if installed, can be added once the water level measures about 8 cm or more. Once the device recognizes enough water in the tub, the buttons “SHAMPOO” and “BATH ADDITIVE” are enabled and illuminated. -
Page 13: Selecting The Massage Jets
Functions Selecting the massage jets This picture shows a top view of the tub body. Each button (“JET M1-M5”) stands for a massage jet (in case that the hydromassage function is installed). The but- tons are enabled and illuminated only once the hydro- massage has been activated. -
Page 14: Sound & Vision
Functions Sound & Vision The optional feature “Sound & Vision” can playback mu sic files which are stored on a USB stick on speakers build into the tub body. Furthermore, by means of LEDs on different sides it can suffuse the water with light in various colours. -
Page 15: Ultrasound
Functions Ultrasound The ultrasound cleaning treatment, if installed, is available only when the tub is filled with water at least up to the middle level. In this case, the button is enabled and illuminated. By pressing the button the ultrasound cleaning treatment is started. It stays ac- tive until the set time has expired (see “Duration setting for ultrasound”). -
Page 16: Duration Setting For Ultrasound
Functions Duration setting for ultrasound Initially the duration is set to 5 minutes (see “Time display”). It can be changed in either direction. To increase or decrease the value press either “TIME +” or “TIME -”. When the maximum or minimum values are reached, then the corresponding button will be dis- abled. - Page 17 Functions What effect does ultrasound have regarding body cleaning? Because of the ultrasound millions of tiny gas bubbles are created in the water which collapse again very quickly (cavitation). At the surface of the patient’s body the energy, which is released when the gas bub- bles collapse, abrades dirt and loose skin particles in a gentle manner.
- Page 18 Functions May the ultrasound cleaning function be applied to people with pacemakers? We have no information about any disruption of a pace- maker’s functionality because of ultrasound or an ul trasound transducer. May the ultrasound cleaning function be applied to persons with implants or other metal objects in or on their body? Implants or other metal objects are no problem.
-
Page 19: Disinfection
Functions Disinfection Flowmeter The flowmeter is used to adjust the mixture ratio be- tween water and disinfectant. It is located at the back of the console. It can only be calibrated during a disinfection cycle while the disinfectant solution is flowing. The table next to it should help you to find the right value. -
Page 20: Compulsory Disinfection
Functions Note: During whole disinfection procedure most other functions are disabled, especially the tub fill. If the disinfectant runs out while spraying, the whole procedure must be restarted after replacing its con- tainer. Since the procedure cannot simply be aborted and the tub fill being disabled, therefore - once the disinfection procedure has been started - you cannot fill the tub again without enough disinfectant. -
Page 21: The Bathing Cycle
The bathing cycle ■ The bathing cycle Insert the drain plug into the drain. Close it. Adjust the tub shorter according to the body length of the pa- tient and put the pillow into the right position. (When using a stretcher lifter then this point does not apply.) ... -
Page 22: Troubleshooting
Troubleshooting ■ Troubleshooting Tub fill doesn’t work even though the function is active and the light is flashing. Check all the sieves and valves for dirt. If the problem still ex- ists, then the electronic has to be checked. Contact your GK rep- resentative. -
Page 23: Maintenance / Service
Maintenance / Service ■ Maintenance Clean the bathtub after each bath (see chapter “Care & Clean ing”). Regularly (at your own discretion) monitor the fill level of the disinfectant container (if installed). Regularly (at your own discretion) monitor the fill level of the shampoo and bath additive containers (if installed). -
Page 24: Care & Cleaning
Care & Cleaning ■ Care & Cleaning Always clean the plastic parts wet or damp but never dry. Any product used to clean or disinfect your GK bath must be free from any abrasive, alcohol & corrosive ingredients. Never use any kind of customary glass cleansers, solvents (e.g. -
Page 25: Standards & Regulations
Care & Cleaning / Standards & Regulations From time to time the hydromassage jet covers should be removed and be cleaned together with the inlet and outlet aper- tures separately. unscrew covers counter-clockwise direction off of the surface (see pictures). clean the covers, the inlet aperture and the outlet aperture thoroughly with a suit-... -
Page 26: Technical Data
Technical data ■ Technical data - Bathtub GK Magic 3000: Voltage: AC 230 V / AC 115 V Frequency: 50 Hz / 60 Hz Power consumption: 800 VA Fuses: 10 A time-delay 12.5 A time-delay ... -
Page 27: Identification Plate
Identification plate / Transport, Storage, Recycling ■ Identification plate Identification plate This plate give you some information's about Product, instance type, production date, serial number,… ■ Transport, Storage, Recycling Operating conditions Max ambient temperature: 40 °C Max relative humidity: 80 % not condensed at 20 °C Atmospheric pressure range: 500 hPa to 1060 hPa Transport and Storage... - Page 28 Georg Krämer Ges.m.b.H. & Co. KG A-4061 Pasching Neuhauserweg 14 Tel. +43 / (0) 7229 / 64450 Fax +43 / (0) 7229 / 70664 service@gk-medizinmechanik.at www.gk-medizinmechanik.at...
