- Page 2 Congratulations on your decision to purchase a GK Bathtub. You have acquired an Austrian quality prod- uct which will considerably ease the strain involved in patient care. Due to their advanced ergonomic design, GK Bathtubs are simple and straightforward to use. In spite of that, we would ask you to study the instructions carefully before operating the bathtub.
-
Page 3: Table Of Contents
Contents ■ Contents For your safety ··········································································· Preparation for bathing ······························································· Components ················································································ Control panel overview ································································· Functions 9-15 ················································································ How the control panel works ··················································· Activation card ····································································· Standby mode ·········································································· Raising & Lowering the tub ···················································· Tilting the tub ····································································... -
Page 4: For Your Safety
For your safty ■ For your safety Make certain that this bathing system is operated only by trained personnel. Always check the water temperature before the client enters the bathtub or when the shower spray is applied to the client. ... -
Page 5: Preparation For Bathing
Preperations for bathing ■ Preparations for bathing If the drain knob isn’t in the drain system put it back now. Put the pillow to the right position. Select a pleasant fill temperature. Fill the tub in the foot area and help the client to enter the tub. -
Page 6: Components
Components... - Page 7 Components ■ Components Automatic door Control panel Mixer Fill in spout with dispenser Hydro-massage jet Drain Overflow Handgrip LED Lights...
- Page 8 Components Locking button locking device Emergency button Lockable door solutions USB port D i s i n f e c t i o n with flowmeter...
-
Page 9: Control Panel Overview
Control panel overview ■ Control panel overview Display Tub fill- & shower temp. Button Door open Button Door close Button Tub recline backward Button Tub recline forward Button Up Button Down Button Intensity/Volume + Button Intensity/Volume - 10. Button Hydro-massage 11. -
Page 10: Functions
Functions ■ Functions How the control panel works Status LEDs are located next to most of the keys. These give you information about the current operating state of the respective function. Dark not available, switched off Lighting available, switched off ... -
Page 11: Raising & Lowering The Tub
Check that the door is free from objects, if you are closing it, because it can cause damages. Note: Should your GK Relax be equipped with an manual lock, than you have to manually open and close the door. Emergency button... -
Page 12: Locking Button
Be sure that the door is in the right position be- fore you lock the door. Note: Should your GK Relax be equipped with an manual lock, than use the lock lever to lock and unlock the door. Setting the temperature... -
Page 13: Closing & Opening The Drain (Draining The Tub)
Functions Closing & Opening the Drain (Draining the Tub) To open or close the drain, turn the chrome drain plug knob in the appropriate direction. We recommend closing the drain system when the inflow is active. Filling the tub When you press this button the tub starts filling and the light on the button starts flashing. -
Page 14: Shampoo & Bath Additive
Functions Shampoo & Bath additive Both functions can be used at any time if there is water in the tub. By pressing the button the se- lected dispenser pump starts running as long as you hold the button. If there is no liquid coming out of the system, make sure that both boxes are full. -
Page 15: Sound & Vision
Functions Sound & Vision The feature „Sound & Vision“ can playback music files which are stored on a USB stick on speakers build into the tub body. Furthermore, by means of LEDs on different sides it can suffuse the water with light in various colours. -
Page 16: Disinfection
Functions Disinfection The bathtub can be disinfected only when the tub is empty. If there is water in the tub, then the light on the button is invisible. Press the “DISINFECTION” button remove shower wand from holder. The light on the button should start flash- ing. -
Page 17: Care & Cleaning Of The Tub
Care & Cleaning of the tub ■ Care & Cleaning of the tub Any product used to clean or disinfect your GK bath must be free from any abrasive, alcohol & corrosive ingredients. Never use any kind of customary glass cleansers, solvents (e.g. acetone) or similar detergents or dilutions. -
Page 18: Troubleshooting
Troubleshooting ■ Troubleshooting The temperature regulation by means of the thermostat mixing valve doesn’t properly work. Possibly the cartridge is defective and has to be changed. Disinfection doesn’t work and the button is flashing very fast. The disinfection container is empty. Replace it with a full disin- fection container. -
Page 19: Maintenance / Service
Maintenance / Service ■ Maintenance Check the hoses, tubes and connections from time to time. Make certain that the disinfectant container is monitored. Make certain that you always have enough shampoo and bath ad- ditive. We recommend that you take advantage of our maintenance ser- vice request safety... -
Page 20: Intended Use
Intended use / Certificates, Standards & Regulations ■ Intended use Bathing system for bathing patients with restricted mobility. The bathing system is mainly used in care institutes, to a lesser de- gree also on hospital wards. It is used in a professional environ- ment by trained and competent personnel. -
Page 21: Technical Data
Technical data ■ Technical data - Bathtub GK Relax: Voltage: AC 230 V / AC 115 V Frequency: 50 Hz / 60 Hz Power consumption: 360 VA Fuses: 6.3 A time-delay 15 A time-delay 25 A time-delay ... -
Page 22: Identification Plate
Identification plate / Transport, Storage, Recycling ■ Identification plate Identification plate This plate give you some information's about Product, instance type, production date, serial number,… ■ Transport, Storage, Recycling Operating conditions Max ambient temperature: 40 °C Max relative humidity: 80 % not condensed at 20 °C Atmospheric pressure range: 500 hPa to 1060 hPa Transport and Storage... -
Page 23: Notes
Notes ■ Notes... - Page 24 Georg Krämer Ges.m.b.H. & Co. KG A-4061 Pasching Neuhauserweg 14 Tel. +43 / (0) 7229 / 64450 Fax +43 / (0) 7229 / 70664 service@gk-medizinmechanik.at www.gk-medizinmechanik.at...
