Summary of Contents for gk-medizinmechanik GK Basic
- Page 2 Congratulations on your decision to purchase a GK Bathtub. have acquired Austrian quality product which will considerably ease the strain in- volved in patient care. Due to their advanced ergonomic design, GK Bathtubs are simple and straightforward to use. In spite of that, we would ask you to study the instructions carefully before...
-
Page 3: Table Of Contents
Contents ■ Contents Contents … For your safety … Preparations for bathing … Components … Functions … Raising & Lowering of the tub … Setting the temperature … Shower … Filling the tub … Drain the tub … Disinfection … Flowmeter …... -
Page 4: For Your Safety
For your safety ■ For your safety Make certain that this bathing system is operated only by trained personnel. Always check the water temperature before the client enters the bathtub or when the shower spray is applied to the client. ... -
Page 5: Preparations For Bathing
Preparations for bathing ■ Preparations for bathing If the drain knob isn’t in the drain system put it back now. Put the pillow to the right position. If you are using a stretcher you don’t have to apply the pil- low. -
Page 6: Components
Components... - Page 7 Components ■ Components Up/Down Button Overflow Fill in spout Drain Shower Adjustable foot...
- Page 8 Komponenten Fittings Shower-head with shower-holder GK Basic with lif- ter GK Ikarus...
-
Page 9: Functions
Functions ■ Functions Raising & Lowering the tub This tub allows caregivers to bathe clients in an ergonomic envi- ronment. Adjusting the tub to a comfortable working height en- hances the bathing process. The “UP” and “DOWN” buttons are used to raise or lower the tub. -
Page 10: Filling The Tub
Functions Filling the tub Move the inflow valve against the clockwise direc- tion to fill the tub. If the right amount of water is in the tub close the valve to stop the water flow. Drain the tub To open or close the drain, turn the chrome drain plug knob in the respective direction. -
Page 11: Care & Cleaning Of The Tub
Care & cleaning of the tub ■ Care & Cleaning of the tub Any product used to clean or disinfect your GK bath must be free from any abrasive, alcohol & corrosive ingredients. Never use any kind of customary glass cleansers, solvents (e.g. acetone) or similar detergents or dilutions. -
Page 12: Maintenance, Service
Maintenance ■ Maintenance Check the hoses, tubes and connections from time to time. Make certain that the disinfectant container is monitored. We recommend that you take advantage of our maintenance ser- vice and request a safety and functional check every 12 months. -
Page 13: Intended Use, Standards And Regulations
Intended use ■ Intended use Bathing system for bathing patients with restricted mobility. The bathing system is mainly used in care institutes, to a lesser de- gree also on hospital wards. It is used in a professional environ- ment by trained and competent personnel. ■... -
Page 14: Technical Data
Technical data ■ Technical data - Bathtub GK Basic: Voltage: AC 230 V / AC 115 V Frequency: 50 Hz / 60 Hz Power consumption: 70 VA Protection class: Degree of protection: IPX4 Protection type: Type B ... -
Page 15: Identification Plate And Labels
Identification plate ■ Identification plate and labels Identification plate This plate give you some information's about the Product, for instance type, production date, serial number,… ISO 9001 Our production is subject to a quality management system according to ISO 9001. CE Kennzeichnung It has been tested for compliance with the essential requirements... - Page 16 Georg Krämer Ges.m.b.H. & Co. KG A-4061 Pasching Neuhauserweg 14 Tel. +43 / (0) 7229 / 64450 Fax +43 / (0) 7229 / 70664 service@gk-medizinmechanik.at www.gk-medizinmechanik.at...
