Keithley Instruments
28775 Aurora Road
Cleveland, Ohio 44139
1-800-935-5595
tek.com/keithley
Description
The Keithley Instruments TRX-1100V-X is a 3-slot high-voltage, low-noise triaxial cable. Examples of how you
can use this cable are applications that characterize and test high-voltage, low-leakage devices, materials, and
modules, such as silicon carbide (SiC), gallium nitride (GaN), power MOSFETs, transient suppression devices,
circuit protection devices, power modules, and batteries where high-voltage sourcing and low-current
measurements are required.
This cable is commonly used with the Keithley Instruments Model 2470 High Voltage SourceMeter
Dimensions
Part number
TRX-1100V-.5
TRX-1100V-1
TRX-1100V-2
TRX-1100V-3
071365000 / May 2019
3-Slot HV Low-Noise Triaxial Cable Instructions
Figure 1: TRX-1100V-X triaxial cable
Length
0.5 m (1.6 ft)
1 m (3.3 ft)
2 m (6.6 ft)
3 m (9.8 ft)
*P071365000*
Model TRX-1100V-X
®
Instrument.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tektronix Keithley TRX-1100V-X
Summary of Contents for Tektronix Keithley TRX-1100V-X
- Page 1 Model TRX-1100V-X Keithley Instruments 3-Slot HV Low-Noise Triaxial Cable Instructions 28775 Aurora Road Cleveland, Ohio 44139 1-800-935-5595 tek.com/keithley Description The Keithley Instruments TRX-1100V-X is a 3-slot high-voltage, low-noise triaxial cable. Examples of how you can use this cable are applications that characterize and test high-voltage, low-leakage devices, materials, and modules, such as silicon carbide (SiC), gallium nitride (GaN), power MOSFETs, transient suppression devices, circuit protection devices, power modules, and batteries where high-voltage sourcing and low-current measurements are required.
- Page 2 Model TRX-1100V-X 3-Slot HV Low-Noise Triaxial Cable Instructions Electrical characteristics Leakage current: Center conductor to inner shield: < 100 x 10 A at 1200 VDC Inner shield to outer shield: < 100 x 10 A at 1200 VDC ...
- Page 3 Safety precautions The following safety precautions should be observed before using this product and any associated instrumentation. Although some instruments and accessories would normally be used with nonhazardous voltages, there are situations where hazardous conditions may be present. This product is intended for use by personnel who recognize shock hazards and are familiar with the safety precautions required to avoid possible injury.
- Page 4 The CAUTION heading in the user documentation explains hazards that could damage the instrument. Such damage may invalidate the warranty. The CAUTION heading with the symbol in the user documentation explains hazards that could result in moderate or minor injury or damage the instrument. Always read the associated information very carefully before performing the indicated procedure.
