PENDANT OVERVIEW

LCD DISPLAY
DEPRESSING BUTTON ACTIVATES
MOTOR "ON" AND ADVANCES TOOL.
DEPRESSING BUTTON ACTIVATES
DEPRESSING BUTTON TURNS
MOTOR "OFF" AND CYCLES VALVE TO
RELIEVE PRESSURE TRAP.
MENU / ENTER / ARROW BUTTONS
EXECUTES A COMMAND
• UP BUTTON MOVES CURSOR UPWARD
• DOWN BUTTON MOVES BUTTON DOWNWARD
• LEFT BUTTON MOVES CURSOR
LEFT OR RETURNS BACK
• RIGHT BUTTON MOVES CURSOR
RIGHT OR CHANGES VALUE
NOTE: WHEN IN MANUAL MODE -
PRESSING THE "UP" ARROW DARKENS CONTRAST
PRESSING THE "DOWN" ARROW LIGHTENS CONTRAST
"ADVANCE" BUTTON"
"ON" BUTTON"
MOTOR "ON"
"OFF" BUTTON"
CHANGES VALUE
CHANGES VALUE
••• 8 •••
Power Control Center
ADVANCE
ON
OFF
MENU
ENTER
