PAM & PGM SERIES
PRO - MAG
40 & 50 SERIES
AIR & GASOLINE POWER PUMPS
A
3.5 and 8 H.P.
Gas Pumps
Part Sheet #: 54393
Revised: 12-01
The world's most complete line of industrial, hydraulic and
mechanical lifting and positioning equipment.
SIMPLEX DIVISION OF TEMPLETON, KENLY & CO., INC.
2525 Gardner Road • Broadview, Illinois 60155 • (708) 865-1500 / Fax (708) 865-0894
www.tksimplex.com
HYDRAULIC & MECHANICAL POWER
Operating & Maintenance Instructions
For 1
H.P. Air & Gasoline Pumps
1/2
and 8 H.P. Gasoline Pump.
1.5 H.P. Air Pumps
Advertisement
Related Manuals for Simplex PAM Series
Summary of Contents for Simplex PAM Series
- Page 1 Part Sheet #: 54393 Revised: 12-01 The world's most complete line of industrial, hydraulic and mechanical lifting and positioning equipment. SIMPLEX DIVISION OF TEMPLETON, KENLY & CO., INC. 2525 Gardner Road • Broadview, Illinois 60155 • (708) 865-1500 / Fax (708) 865-0894 www.tksimplex.com...
- Page 2 SAFETY Working Pressure 1-1. working pressure is 10,000 PSI (700 kg/cm ). Make sure The pump's maximum that all hydraulic equipment used with this pump are rated at 10,000 PSI operat- ing pressure. Hydraulic Connections 1-2. Never disconnect or connect any pressurized hydraulic hoses or fittings. Shift, or open all hydraulic controls several times to assure that the system has been depressurized.
-
Page 3: Instructions Before Use
Oil level should be plate -- with cylinders retracted Do not and motor off. Add Simplex oil as necessary. mix different grades of oil, or types of oil. connections are tight and Make sure all desired gauge, valve, hose and quick coupler secure before operating (See Section 1.2). - Page 4 1. Completely change the hydraulic oil and clean the oil filter screen and magnet (located in the reservoir) twice a year. (Use Simplex oil only, Model # AO1, 1 gallon). Change the oil more frequently when used in extremely dusty areas or when the oil has been overheated.
-
Page 5: Operation
OPERATION 3-1. Control Valves: * Useable 3/8 NPTF port a. 2-Way Valve for Single Acting Rams To Advance..turn lever to the right & start motor. To Hold....turn motor off. To Retract....turn lever to the left. b. 3-Way Valve for Single Acting Rams Return ports only. -
Page 6: Maintenance
TRICAL OUTLETS BEFORE PERFORMING MAINTENANCE OR REPAIR PROCEDURES. 4-1. Maintain Oil Level -- check hydraulic oil level every 30 hours of operation. Add Simplex oil (Model # AO1 -- 1 gallon) when necessary. Oil level should be no more than 2" from top of reservoir plate -- with cylinders retracted and motor off. -
Page 7: Troubleshooting
TROUBLESHOOTING If the procedures listed below do not remedy the problem -- the pump will require service and should be taken to an authorized Simplex service center for repair Problem Cause -- Solution Sporadic Cylinder Action 1. Air in the hydraulic system. See Sec. 3-3 for correct bleeding procedure. - Page 8 18948 PUMP ASSEMBIES 40 SERIES GAS PUMP 11 12 9 42 - 8 -...
- Page 9 18948 PUMP ASSEMBIES 40 SERIES GAS PUMP ITEM PART NO. QTY. ITEM PART NO. QTY. DISCRIPTION DISCRIPTION 68507 2 Piston Pump Body 68892 Retaining Ring 68360 81093 PIpe Plug Roller Bearing 66033 68004 Ext. Relief Seat Thrust Bearing 66474 68003 Ext.
- Page 10 18721 PUMP ASSEMBIES FOR 40 SERIES AIR PUMP 9 42 11 12 9 42 For 5 & 10 Gallon Reservoir. - 10 -...
- Page 11 18721 PUMP ASSEMBIES FOR 40 SERIES AIR PUMP ITEM PART NO. QTY. ITEM PART NO. QTY. DISCRIPTION DISCRIPTION 68507 2 Piston Pump Body 68892 Retaining Ring 68360 81093 PIpe Plug Roller Bearing 66033 Thrust Bearing 68004 Ext. Relief Seat 66474 68003 Ext.
- Page 12 # 69296 8 HP Gasoline Motor 35 36 15 16 - 12 -...
- Page 13 # 69296 8 HP Gasoline Motor Descreption Item # Part # Quantity 4Piston Pump Body 68529 Roller Bearing 68360 Bearing 66033 Bearing Race 66474 Eccentric Asm. 68906 Thrust Bearing 66106 Bearing Race 66108 Adapter Shaft Asm. 68829 O-Ring 56020322 Retaining Ring 68978 .210 Piston Adapter 68915...
- Page 14 - 14 -...
- Page 15 - 15 -...
- Page 16 PGM & PAM POWER PUMPS DESCRIPTION 18135 OIL / GAL. 11 11 68000 BREATHER VENT 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 66012 MOTOR GASKET 1 1 1 1 1 1 1 1 68231 PUMP GASKET RES.
- Page 17 PGM & PAM POWER PUMPS Assembly #68829 Item Part Description Qty. 68219 Adapter-Shaft 66030 Bearing 68901 Seal Assembly #68535 Item Part Description Qty. 68209 Piston 5602010 O-Ring 68145 Back-Up Ring 93837 Roll Pin Assembly #69082 - AIR Assembly #68906 - GAS Item Part Description...
- Page 18 3 WAY & 4 WAY VALVE MANIFOLD SECTION A-A SECTION B-B Assembly #69570 3 Way Manifold Item Part No. Description Qty. 69570 69569 Ret. Valve Manifold 68197 Nozzle-Valve 68004 Seat-Ext. Relief 68003 Cone-Ext. Relief 66085 Spring Rel. Valve 69104 Adjusting Screw 84084 Flush SOC 3/8-18 PTF 97641...
- Page 19 3 WAY & 4 WAY LOCKING VALVE MANIFOLD Assembly #68581 4 Way Lock Valve Manifold Item Part Description Qty. 68591 Valve Body 92549 Ball - 1/4 68637 Release Gland 5602113 O-Ring 2-113 89435 Release Screw Assm. 56021115 O-Ring 2-111 5602010 O-Ring 2-010 66083 Adjusting Screw...
- Page 20 - 20 -...
- Page 21 18379 VALVE ASSEMBLY 68349 RETRACTOR VALVE ASSEMBLY "A" "A" View "A-A" 68349 - Use 18379 - Use ITEM PART NO. QTY. QTY. DESCRIPTION 18379 68349 68160 Rotor Assembly 56020112 O-Ring 68180 Subplate-Valve. 5602225 O-Ring 68026 Thrust Washer 68155 Thrust Bearing 5602012 O-Ring 68035...
- Page 22 43022 VALVE AIR TORQUE OC - 22 -...
- Page 23 41950 MOTOR PENDANT AIR ASSEMBLY - 23 -...
-
Page 24: Air Valve Assembly
AIR VALVE ASSEMBLY TUBE FROM FILTER/LUBE ADVANCE RETRACT COIL COIL MOTOR 7" LG 43515 AIR VALVE 4W / 2POS - 24 -... - Page 25 68790 FILTER / LUBE ASSEMBLY ASSEMBLE WITH LOCTITE 242 - 25 -...
- Page 26 69470 FILTER BLOCK ASSEMBLY - 26 -...
