User's Manual
User's Manual
KMDA-3602
Ver.A1.0
Date:19, September, 2018

Advertisement

Table of Contents
loading

Related Manuals for JHCTech KMDA-3602

Summary of Contents for JHCTech KMDA-3602

  • Page 1 User’s Manual User’s Manual KMDA-3602 Ver.A1.0 Date:19, September, 2018...
  • Page 2 User’s Manual Version Note Ver. Note Date Writer A1.0 first publish 20180919 Tracy Liu...
  • Page 3 Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. RTL is a trademark of Realtek Semi-Conductor Co., Ltd. All other product names or trademarks are properties of their respective owners. For more information on this and other JHC products, please visit our websites at: http://www.jhctech.com.cn...
  • Page 4 User’s Manual Product Warranty (2 years) JHC warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by JHC, or which have been subject to misuse, abuse, accident or improper installation.
  • Page 5 Technical Support and Assistance Step 1. Visit the JHC web site at www.jhctech.com.cn where you can find the latest information about the product. Step 2. Contact your distributor, sales representative, or JHC’s customer service center for technical support if you need additional assistance.

  • Page 6: Table Of Contents

    User’s Manual CONTENTS General Information ............................1 1.1 Introduction ............................2 1.2 Features ............................2 1.3 Specifications ........................... 3 1.3.1 General ..........................3 1.3.2 Display ..........................3 1.3.3 Ethernet ..........................3 1.3.4 Audio ..........................3 1.3.5 Power Consumption......................4 1.4 Environmental Specifications ......................4 1.5 3602 Series Specifications .......................
  • Page 7 User’s Manual 2.4.8 COM1/2 Connector ......................18 2.4.9 Remote Switch signal Connector..................19 2.4.10 AT/ATX SW ........................19 2.4.11 LED ........................... 19 2.5 Installation ............................. 20 2.5.1 HDD/SSD Installation ......................20 2.5.2 Installing mini-PCIe ......................24 2.5.3 Installing MSATA ....................... 30 2.5.4 Installing GPU module .......................

  • Page 8: General Information

    User’s Manual General Information...

  • Page 9: Introduction

    HD Graphics and NVIDA or AMD MXM3.1 GPU module. KMDA-3602 offers 1*HDMI, 1*DP(Intel HD 4K) and 1*VGA, 1*HDMI and 3*DP(GPU 4K), 7*Gigabit LAN ports, 6*USB3.0, 2*mini PCIe which support dual 4G LTE/wifi/BT. 1*mSATA, 1*M.2, 1*2.5” SATA HDD/SSD are used for storage, The SATA HDD/SSD is cooled by aluminum chassis. With DC 6~48V wide power input, ITPS delay power on/off function.

  • Page 10: Specifications

    User’s Manual 1.3 Specifications 1.3.1 General ® CPU: Intel Skylake-S/Kabylake-S LGA1151 CPU GPU: MXM3.1 NVIDIA GTX/AMD RX series GPU (KMDA-3602-T001 has no GPU) ® Chipset: Intel Q170 System Memory: 2*DDR4 2133/2400MHz SODIMM, Up to 32GB Watchdog Timer: 255-level interval timer, setup by software...

  • Page 11: Power Consumption

    Minimum power input DC 24V/5A—(KMDA-3602-S001) DC 19V/2A--(KMDA-3602-T001) 1.4 Environmental Specifications Operating temperature: -20 ~ 65° C (Fanless, 35W CPU without GPU, SSD, Airflow)—(KMDA-3602-T001) -10 ~ 50° C (Fanless 35W CPU+80W GPU)—(KMDA-3602-S001) Relative humidity: 10~90% @ 40° C (non-condensing) Storage temperature: -40 ~ 85°...

  • Page 12: Mechanical Specifications

    User’s Manual Display 2*HDMI, 4*DP, 1*VGA 1*HDMI, 1*DP, 1*VGA I-port Audio √ √ Expansion 2*mini-PCIe 1*M.2 1*mSATA 2*mini-PCIe 1*M.2 1*mSATA 1.6 Mechanical Specifications Main Board Front(AXM-I950) Figure 1.0 Figure 1.1...
  • Page 13 User’s Manual Main Board Rear(AXM-I950) Figure 1.2 Sub-card(ECB-147-T001) Figure 1.3 Sub-card(ECB-147-S002) Figure 1.4...
  • Page 14 User’s Manual Sub-card(ECB-148) Figure 1.5 KMDA-3602 Dimension: Unit: mm Figure 1.6...

  • Page 15: Hardware Installation

    User’s Manual Hardware Installation...

  • Page 16: Introduction

    2.2.1 Setting Jumpers You can configure your KMDA-3602 to match the needs of your application by setting the jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 17: Jumper Location

    2.3 Jumper Location The KMDA-3602 high-performance Box Computer has a number of jumpers inside the chassis that allows you to configure your system to suit your application. The table below shows the function of each of the board’s jumpers:...

  • Page 18: Clr_Cmos1-Clear Cmos Data

    User’s Manual 2.3.1 CLR_CMOS1-Clear CMOS Data Figure 2.4 If you encounter the followings a) CMOS data becomes corrupted. b) You forget the supervisor or user password. you can reconfigure the system with the default values stored in the ROM BIOS. To load the default values stored in the ROM BIOS, please follow the steps below.

  • Page 19: Com7-Itps Mode And Power Off Delay Select

    Figure 2.5 NOTE: Pin7/8/9/10 are for ITPS mode select; Pin1/2/3/4/5/6 are for ITPS mode power off delay; 2.4 I/O/Button/LED Indication NOTE: I/O Indication takes KMDA-3602-S001 for example, Other sub-series products only have different number of interfaces. Front view: Figure 2.6...

  • Page 20: Ethernet Connector (Lan)

    Figure 2.7 2.4.1 Ethernet Connector (LAN) The KMDA-3602-S001 is equipped with 6 Intel I210AT chips and 1 Intel I219LM for 10/100/1000Mbps Ethernet controllers. The product provides 7*RJ45, with LED indicators on the front side to show its Active/Link status (Green LED) and Speed status (yellow LED).

  • Page 21: Usb Connector

    The USB device allows data exchange between your computer and a wide range of simultaneously accessible external Plug and Play peripherals. The KMDA-3602 provides 6*USB3.0, 3*USB2.0(one inside for dongle). The USB interface complies with USB UHCI, Rev. 2.0 compliance. The USB interface can be disabled in the system BIOS setup.

  • Page 22: Hdmi

    Signal Signal DATA2_P DATA0_N DATA2_N CLK_P DATA1_P CLK_N DETECT DATA1_N DATA0_P (NOTE: KMDA-3602-T001 has one HDMI port) 2.4.4 DP The KMDA-3602-S001 provides four high-resolution DP ports, it supports the most resolution up to 4096*2304@60Hz. Table 2.5 for DP pin assignments.

  • Page 23: Dio Connector

    DATA2_P (NOTE: KMDA-3602-T001 has one DP port) 2.4.5 DIO Connector The KMDA-3602-S001 provides a 8-bit iso. DIO by a 2*10Pin 8-bit DI/DO terminal connector in front. The Pin assignments are as follows: Figure 2.13 8-bit DI/DO Connector Table 2.6: 8-bit DI/DO Pin Assignments...

  • Page 24: Power Input Connector (Dc-In)

    DIO2_13 DIO2_6 DIO2_14 DIO2_7 DIO2_15 2.4.6 Power Input Connector (DC-IN) The KMDA-3602 provides a wide power input (DC 6~48V) by a 5-pin terminal. Table 2.8 for pin assignments. Figure 2.15 power input connector Table 2.8:DC-IN port pin assignments Signal Signal...

  • Page 25: Vga

    User’s Manual 2.4.7 VGA The KMDA-3602 provides a high-resolution VGA interface via D-sub 15-pin connector to support a VGA CRT monitor, it supports the most resolution up to 2650*1600@60Hz. Table 2.9 for pin assignments. Figure 2.16 VGA Connector Table 2.9: VGA port pin assignments...

  • Page 26: Remote Switch Signal Connector

    2.4.10 AT/ATX SW The KMDA-3602 provides a AT/ATX SW, which users can set Power-on mode by it. When you dial it at AT, it means power on by AC Power; When you dial it at ATX, it means power on by Power button.

  • Page 27: Installation

    User’s Manual Table 2.12 for LEDs state of CPU temperature class. Table 2.12: LEDs state of CPU temperature class. State Warning Yellow High Green Normal 2.5 Installation 2.5.1 HDD/SSD Installation Step 1: Unscrew 4 screws on the underside, remove the bottom bracket; Step 2: Unscrew 6 screws on the bottom cover;...
  • Page 28 User’s Manual...
  • Page 29 User’s Manual...
  • Page 30 User’s Manual...

  • Page 31: Installing Mini-Pcie

    User’s Manual 2.5.2 Installing mini-PCIe Step 1: Unscrew 4 screws on the underside, remove the bottom bracket; Unscrew 6 screws on the bottom cover; Unscrew 2 screws on the front/rear panel; Rotate the bottom assembly 180°, separate the SATA cable which connected the HDD/SSD with the mother board, remove the bottom cover;...
  • Page 32 User’s Manual...
  • Page 33 User’s Manual...
  • Page 34 User’s Manual...
  • Page 35 User’s Manual...
  • Page 36 User’s Manual Step 2: Hold the Mini PCIe module with its notch aligned with the Mini PCIe socket of the board and insert it at a 30 degrees angle into the socket; Step 3: Screw one screw to the holder; Step 4: Follow the reverse steps of disassembly to complete the product installation.

  • Page 37: Installing Msata

    User’s Manual 2.5.3 Installing MSATA Step 1: The step here is the same as above chapter “2.5.2 Installing Mini PCIe Module -Step 1”, For details, please refer to the above chapter “2.5.2 Installing Mini PCIe Module -Step 1” Step 2: Unscrew 2 screws on the GPU module, remove the GPU module; Step 3: Unscrew 10 screws and 8 serial copper columns on the mother board, remove the mother board;...
  • Page 38 User’s Manual Step 3: Hold the MSATA module with its notch aligned with the MSATA socket on the back of the mother board and insert it at a 30 degrees angle into the socket; Screw one screw to the holder as shown in the picture. Step 4: Follow the reverse steps of disassembly to complete the product installation.

  • Page 39: Installing Gpu Module

    User’s Manual 2.5.4 Installing GPU module Step 1: The step here is the same as above chapter “2.5.2 Installing Mini PCIe Module -Step 1”, For details, please refer to the above chapter “2.5.2 Installing Mini PCIe Module -Step 1” Step 2: Unscrew 2 screws on the GPU module, remove the GPU module; Step 3: Hold the GPU module with its notch aligned with the MXM3.1 socket of the board and insert it;...
  • Page 40 User’s Manual...

  • Page 41: Bios Setup

    User’s Manual BIOS Setup...

  • Page 42: Bios Description

    User’s Manual 3.1 BIOS Description BIOS is the communication bridge between hardware and software. How to correctly set the BIOS parameters is crucial for the system to work stably and whether the system works at its best. This chapter describes how to change the system settings through the BIOS settings. For details, please refer to the following.

  • Page 43: Bios Navigation Keys

    User’s Manual 3.2.1 BIOS Navigation Keys Enter the SETUP settings interface, The BIOS navigation keys are listed below: Table 3.1: The BIOS navigation keys FUNCTION Exit the current menu ↑↓→← Scrolls through the items on a menu Change Opt. Enter Select General Help Previous Value...
  • Page 44 User’s Manual BIOS Information This item shows the information of the BIOS vendor, version, build date and time etc. Board Information This item shows the basic information of the motherboard, including the Board ID and BIOS Version of the motherboard. Processor Information This item shows the basic information about the currently used processor, including name, type, speed, ID, core, Microcode version, etc.

  • Page 45: Advanced Menu

    User’s Manual This item shows the version number of the ME firmware ME firmware SKU This item shows the ME firmware model number System Language Set the language interface of the BIOS. System Date Set the date. The format of the date is <week><month><day><year>. System Time Set the time.
  • Page 46 User’s Manual This item contains the PCH firmware configuration, enter this sub-menu, there will be detailed details of the ME, as well as related settings of the AMT function. Trusted Computing Trusted computing, enter this sub-menu, there will be the setting of the encryption security module (the motherboard will install the encryption module hardware will take effect) ACPI Settings Advanced configuration and power management interface settings, enter this submenu, there will be...
  • Page 47 User’s Manual CPU Temperature Limit of OFF Set the temperature at which the fan stops rotating; CPU Temperature Limit of Start Set the temperature at which the fan starts to rotate; CPU Fan Start PWM Set the PWM of the fan rotation, the higher the value, the higher the speed at which the fan starts. CPU Slope PWM Set the Slope of the PWM, the higher the value, the faster the fan accelerates.

  • Page 48: Chipset Menu

    User’s Manual SIO Configuration Super IO configuration, enter this sub-menu, there will be the port configuration of the serial/parallel port which are included in IO. CSM Configuration CSM (Compatibility Support Module) configuration, enter this sub-menu, there will be various settings to support UEFI startup and non-UEFI startup.
  • Page 49 User’s Manual System Agent (SA) Configuration Memory Configuration Memory configuration, enter this submenu, there will be detailed memory information. Graphics Configuration Image processing configuration, enter this sub-menu, there will be CPU-integrated graphics related settings. PEG Port Configuration PEG graphics configuration, enter this sub-menu, there will be related settings for the external graphics card.

  • Page 50: Security Menu

    User’s Manual 3.2.5 Security menu Administrator Password Set the administrator password. User Password Set the normal user password.

  • Page 51: Boot Menu

    User’s Manual 3.2.6 Boot menu Setup Prompt Timeout Setup prompts for waiting time. This option is to set the time to wait for the Del key to enter the BIOS setup after booting. Bootup NumLock State Set the state of the small numeric keypad at startup. Quiet Boot Switch full screen logo control Fast Boot...

  • Page 52: Save&Exit Menu

    User’s Manual 3.2.7 Save&Exit menu This item includes: Save changes and Exit; Discard Changes and Exit; Save Changes and Exit; Discard Changes and Reset; Save Changes; Discard Changes; Default Changes; Boot Override You can directly select the device to be started, press “Enter” to start directly. 3.3 Updating the BIOS The BIOS (Basic Input and Output System) Setup Utility displays the system’s configuration status and provides you with options to set system parameters.
  • Page 53 User’s Manual on, the system is configured with the values you stored in CMOS. The BIOS provides the underlying driver for hardware resources and is the bridge between hardware and operating system. Now hardware and various applications are constantly updated. When your system encounters problems, such as the system does not support the latest published CPU, you need to upgrade your BIOS.

  • Page 54: Driver Installation

    User’s Manual Driver Installation...

  • Page 55: Follow The Sequence Below To Install The Drivers

    User’s Manual The KMDA-3602 comes with a CD-ROM that contains all drivers and utilities that meet your needs. 4.1 Follow the sequence below to install the drivers: Figure 4.1 Step 1 – Install AMT Driver Step 2 – Install Audio Driver Step 3 –...

  • Page 56: Cpu Temp Led Driver

    3. The system will help you install the driver automatically 4.3 CPU TEMP LED driver The KMDA-3602 provides temperature showing in LEDs, economic and reliable. Users can monitor the working state of the CPU according to the display of the LED. Please perform the following operations, making LEDs work normally.

  • Page 57: System Resource

    User’s Manual SYSTEM RESOURCE...

  • Page 58: Wdt And Gpio

    User’s Manual 5.1 WDT and GPIO /* ====================================================================== * void jhctech_init(); * function description: library initializated, This function must be called before calling other functions * parameter description： * creation date： 5*======================================================================*/ /* ====================================================================== * void jhctech_init(); * function description: library release, Pair with jhctech_init, release the library's occupied resources when not needed * parameter description：...
  • Page 59 User’s Manual Parameter: port represents the number of the GPIO, 1 or 2 Mode 8 bit of a bit, each bit controls the input and output mode of a GPIO pin, Bit =1, the corresponding pin is used as the input port. Bit =0, the corresponding pin is used as an output port.
  • Page 60 User’s Manual /*========================================================================== 1 * int smbus_16pin_gpio_input(int port); * function description：read the motherboard GPIO input level * parameter description： Return value：return a byte (8 bit), each bit of the 8 bit corresponding to the level state of a GPIO Return value Bit7 Bit6 Bit5...
