Lantech IES-2208CA-DNV User Manual

Dual speed sfp combo managed industrial switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Lantech
IES-2208CA-DNV
8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo
Managed Industrial Switch
User Manual
V2.01
Jan. 2013

Advertisement

Table of Contents
loading

Related Manuals for Lantech IES-2208CA-DNV

Summary of Contents for Lantech IES-2208CA-DNV

  • Page 1 Lantech IES-2208CA-DNV 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Managed Industrial Switch User Manual V2.01 Jan. 2013...

  • Page 2: Table Of Contents

    Table of Content Chapter 1 Introduction ..........1 Hardware Features ........1 Software Features .......... 4 Package Contents .......... 7 Chapter 2 Hardware Description ......8 Physical Dimension ........8 Front Panel............. 8 Bottom View ........... 9 LED Indicators..........10 Chapter 3 Hardware Installation ......
  • Page 3 System Login ..........25 System ............26 Time - SNTP ..........29 Account - Admin ........... 32 IP Addressing – IPV4 ........33 Syslog ............35 Syslog Configuration ............. 35 SNMP Configuration ........36 SNMP - Agent ............... 36 6.20.1 SNMP Trap Configuration ......
  • Page 4 6.18.1 RSTP Setting ..........57 6.18.2 RSTP Information ..........59 6.19 Pro-Ring II S..........60 6.20 Multicast Support ......... 62 6.21 LLDP ............65 6.22.1 LLDP Neighbors .......... 66 6.23 Filtering Database ........67 6.24 VLAN ............69 6.24.1. VLAN Configuration ........69 6.24.2 Switch Status ..........
  • Page 5 Appendix A—RJ-45 Pin Assignment ..... 92 RJ-45 Pin Assignments .......... 92 RJ-45 Pin Assignment of PoE ........ 95 Appendix B—Command Sets ......... 97 Switch Setting Commands Set ........97 Admin Password Commands Set ......... 98 IP Setting Commands Set ..........98 SNTP Commands Set ..........
  • Page 6 System Warning Commands Set ........ 121 Mac Address Table Commands Set ......124 Port Statistics Commands Set ........125 Port Monitoring Commands Set ........125 System Event Log Commands Set ......126 Ping Commands Set ........... 126 SFP Monitor Commands Set ........126 Loading Average Commands Set .......
  • Page 7 FCC Warning This Equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy.

  • Page 8: Chapter 1 Introduction

    Chapter 1 Introduction The 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Managed Industrial Switch is a cost-effective solution and meets the high reliability requirements demanded by industrial applications. Using fiber port can extend the connection distance that increases the network elasticity and performance. 1.1 Hardware Features IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX/ FX...
  • Page 9 DRAM 32Mbytes 10/100TX: 8 x ports RJ-45 with Auto MDI/MDI-X function 10/100/1000T/SFP Combo port: 2 x RJ-45 + 2 x 100/1000 Connector SFP socket with DDM RS-232 connector: RJ-45 type 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E cable EIA/TIA-568 100-ohm (100m) 100Base-TX: 2-pair UTP/STP Cat.
  • Page 10 SFP port: LNK/ACT(Green), 1000T: LNK/ACT(Green), 1000M(Green) External Power Supply: DC 12~48V, Redundant power DC 12~48V and connective removable terminal block for Power Supply master and slave power Power 9.86 W at full load Consumption Operating 5% to 95% (Non-condensing) Humidity Operating C ~ 75 Temperature...

  • Page 11: Software Features

    1.2 Software Features Management SNMP v1 v2c, v3/ Web/Telnet/CLI RFC 1215 Trap, RFC1213 MIBII, RFC 1157 SNMP MIB, RFC 1493 SNMP MIB Bridge MIB, RFC 2674 VLAN MIB, RFC 1643 , RFC 1757, RSTP MIB, Private MIB, LLDP MIB Port Based VLAN IEEE 802.1Q Tag VLAN (256 entries)/ VLAN ID (Up to 4K, VLAN VLAN ID can be assigned from 1 to 4094.)
  • Page 12 Supports IGMP snooping v1,v2 IGMP 256 multicast groups and IGMP query Supports 10 IP addresses that have permission to access IP Security the switch management and to prevent unauthorized intruder. Login Security Supports IEEE802.1X Authentication/RADIUS Support ingress packet filter and egress packet limit The egress rate control supports all of packet type and the limit rates are 100K~102400Kbps(10/100), 100K~256000Kbps(1000)
  • Page 13 Provides DNS client feature and supports Primary and Secondary DNS server SNTP Supports SNTP to synchronize system clock in Internet Firmware Update Supports TFTP firmware update, TFTP backup and restore. Configuration Supports binary format configuration file for system quick Upload/Download installation Each port allows importing 128bits of alphabetic string of ifAlias...

  • Page 14: Package Contents

    1.3 Package Contents Please refer to the package content list below to verify them against the checklist.  8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Managed Industrial Switch x 1  User manual x 1  Pluggable Terminal Block x 1 ...

  • Page 15: Chapter 2 Hardware Description

    Chapter 2 Hardware Description In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling information, and wiring installation. 2.1 Physical Dimension 74.5mm x 105mm x 182mm(W x D x H) 2.2 Front Panel Front Panel of the industrial switch...

  • Page 16: Bottom View

    2.3 Bottom View The bottom panel of the Industrial Managed Industrial Switch has one terminal block connector of two DC power inputs and one fault alarm. Bottom Panel of the industrial switch...

  • Page 17: Led Indicators

    2.4 LED Indicators The diagnostic LEDs that provide real-time information of system and optional status are located on the front panel of the industrial switch. The following table provides the description of the LED status and their meanings for the switch. Color Status Meaning...
  • Page 18 The SFP port is linking Link/Active The port is transmitting or receiving packets (P9, P10 Green Blinks from the TX device. SFP) No device attached A network device is detected. The port is transmitting or receiving packets Green Blinking from the TX device. No device attached P1 ~ P8 The port is operating in full-duplex mode.

  • Page 19: Chapter 3 Hardware Installation

    Chapter 3 Hardware Installation In this paragraph, we will describe how to install the Pro-Ring2s Managed Industrial Switch and the installation points attended to it. 3.1 Installation Steps 1. Unpack the Industrial switch 2. Power on the Industrial switch. Please refer to the Wiring the Power Inputs section for knowing the information about how to wire the power.

  • Page 20: Wiring The Power Inputs

    3.2 Wiring the Power Inputs Please follow the steps below to insert the power wire. 1. Insert AC or DC power wires into the contacts 1 and 2 for power 1, or 5 and 6 for power. 2. Tighten the wire-clamp screws for preventing the wires from loosing. [NOTE] The wire gauge for the terminal block should be in the range between 12 ~ 24 AWG.

  • Page 21: Wiring The Fault Alarm Contact

    3.3 Wiring the Fault Alarm Contact The fault alarm contacts are in the middle of the terminal block connector as the picture shows below. Inserting the wires, the switch will detect the fault status of the power failure, or port link failure (available for managed model) and then forms an open circuit. The following illustration shows an application example for wiring the fault alarm contacts.

  • Page 22: Cabling

    3.4 Cabling  Use four twisted-pair, Category 5e or above cabling for RJ-45 port connection. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long.  Fiber segment using single-mode connector type must use 9/125 µm single-mode fiber cable.
  • Page 23 To connect the transceiver and LC cable, please follow the steps shown below: First, insert the transceiver into the SFP module. Notice that the triangle mark is the bottom of the module. Transceiver to the SFP module Transceiver Inserted Second, insert the fiber cable of LC connector into the transceiver.
  • Page 24 LC connector to the transceiver...
  • Page 25 To remove the LC connector from the transceiver, please follow the steps shown below: First, press the upper side of the LC connector to release from the transceiver and pull it out. Remove LC connector Second, push down the metal loop and pull the transceiver out by the plastic handle. Pull out from the transceiver...

  • Page 26: Chapter 4 Network Application

    Chapter 4 Network Application This chapter provides some sample applications to help user to have more actual idea of industrial switch function application. A sample application of the industrial switch is as below:...

  • Page 27: Pro-Ring2S Application

    4.1 Pro-Ring2s Application Pro-Ring II is a new Ring mechanism for Lantech Industrial Switches in which it eliminates the need to pre-set the Master switch in old Pro-Ring and yet to protect the network by much secure topologies than ever. Pro-Ring II works as a Ring Chain to reduce the risk of master switch linking down whereas the setup becomes much easier.

  • Page 28: Chapter 5 Console Management

    Chapter 5 Console Management 5.1 Connecting to the Console Port The supplied cable which one end is RS-232 connector and the other end is RJ-45 connector. Attach the end of RS-232 connector to PC or terminal and the other end of RJ-45 connector to the console port of the switch.

  • Page 29: Login In The Console Interface

    5.3 Login in the Console Interface When the connection between Switch and PC is ready, turn on the PC and run a terminal emulation program or Hyper Terminal and configure its communication parameters to match the following default characteristics of the console port: Baud Rate: 9600 bps Data Bits: 8 Parity: none...

  • Page 30: Cli Management

    5.4 CLI Management The system supports the console management—CLI command. After you log in on to the system, you will see a command prompt. To enter CLI management interface, type in “enable” command. CLI command interface...

  • Page 31: Chapter 6 Web-Based Management

    Chapter 6 Web-Based Management This section introduces the configuration and functions of the Web-Based management. 6.1 About Web-based Management There is an embedded HTML web site residing in flash memory on CPU board of the switch, which offers advanced management features and allows users to manage the switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.

  • Page 32: System Login

    6.3 System Login Launch the Internet Explorer on the PC Key in “http:// “+” the IP address of the switch”, and then Press “Enter”. The login screen will appear right after Key in the user name and password. The default user name and password are the same as ‘root’.

  • Page 33: System

    6.4 System 6.4.1 General – Switch Information User can find the system name, description, location and contact personnel to identify the switch. The version table below is a read-only field to show the basic information of the switch.  System Name: Assign the system name of the switch (The maximum length is 64 bytes) ...
  • Page 34 Switch settings interface 6.4.2 General – CPU Load Average Sometimes the user was worry about that ‘ Could my switch process too many network packets ? So the network throughput was keeping decreasing “. In this option, you can monitor the CPU of switch to see if the switch was in full loading status or not.

  • Page 36: Time - Sntp

    6.5 Time - SNTP SNTP (Simple Network Time Protocol) is a simplified version of NTP which is an Internet protocol used to synchronize the clocks of computers to some time reference. Because time usually just advances, the time on different node stations will be different. With the communicating programs running on those devices, it would cause time to jump forward and back, a non-desirable effect.
  • Page 37 PDT - Pacific Daylight PST - Pacific Standard -8 hours 4 am ADT - Alaskan Daylight ALA - Alaskan Standard -9 hours 3 am HAW - Hawaiian -10 hours 2 am Standard Nome, Alaska -11 hours 1 am CET - Central European FWT - French Winter MET - Middle European +1 hour...
  • Page 38 Guam Standard, USSR Zone 9 IDLE - International Date Line NZST - New Zealand +12 hours Midnight Standard NZT - New Zealand  SNTP Sever Address: Set the SNTP server IP address. You can assign a local network time server IP address or an internet time server IP address. ...

  • Page 39: Account - Admin

    SNTP Configuration interface 6.6 Account - Admin Change web management login user name and password for the management security issue.  User name: Type in the new user name (The default is ‘root’)  New Password: Type in the new password (The default is ‘root’) ...

  • Page 40: Ip Addressing - Ipv4

    Account Authentication interface 6.7 IP Addressing – IPV4 The switch is a network device which needs to be assigned an IP address for being identified on the network. Users have to decide a means of assigning IP address to the switch.
  • Page 41 IP Addressing interface...

  • Page 42: Syslog

    6.8 Syslog This page allows the user to decide whether to send the system event log, and select the mode which the system event log will be sent to client only, server only, or both client and server. What kind of event log will be issued to the client/server depends on the selection on the Event Configuration tab.

  • Page 43: Snmp Configuration

    6.9 SNMP Configuration Simple Network Management Protocol (SNMP) is the protocol developed to manage nodes (servers, workstations, routers, switches and hubs etc.) on an IP network. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth. Network management systems learn of problems by receiving traps or change notices from network devices implementing SNMP.
  • Page 44 SNMP Agent Configuration interface...

  • Page 45: Snmp Trap Configuration

    6.20.1 SNMP Trap Configuration A trap manager is a management station that receives the trap messages generated by the switch. If no trap manager is defined, no traps will be issued. To define a management station as a trap manager, assign an IP address, enter the SNMP community strings, and select the SNMP trap version.

  • Page 46: System Alert - Relay Alarm

    6.10 System Alert - Relay Alarm The Fault Relay Alarm function provides the Power Failure and Port Link Down/Broken detection. With both power input 1 and power input 2 installed and the check boxes of power 1/power 2 ticked, the FAULT LED indicator will then be possible to light up when any one of the power failures occurs.
  • Page 47 are also five types of event—Device Cold Start, Authentication Failure, X-Ring Topology Change, and Port Event—available to be issued as the e-mail alert. Besides, this function provides the authentication mechanism including an authentication step through which the client effectively logs in to the SMTP server during the process of sending e- mail alert.

  • Page 48: System Alert - Event

    6.8.2 System Alert - Event Having ticked the Syslog/SMTP checkboxes, the event log/email alert will be sent to the system log server and the SMTP server respectively. Also, Port event log/alert (link up, link down, and both) can be sent to the system log server/SMTP server respectively by setting the trigger condition.
  • Page 49 respectively.  SNMP Authentication Failure: When the SNMP authentication fails, the system will issue the event log/email alert to the system log/SMTP server respectively. Event Configuration interface...

  • Page 50: Dhcp Server

    6.11 DHCP Server DHCP is the abbreviation of Dynamic Host Configuration Protocol that is a protocol for assigning dynamic IP addresses to devices on a network. With dynamic addressing, a device can have a different IP address every time it connects to the network. In some systems, the device's IP address can even change while it is still connected.

  • Page 51: Client Table

    6.6.2 Client Table When the DHCP server function is enabled, the system will collect the DHCP client information including the assigned IP address, the MAC address of the client device, the IP assigning type, status and lease time. 6.6.3 IP Bindings Assign the dynamic IP address bound with the port to the connected client.

  • Page 53: Port - Configuration

    6.12 Port - Configuration In Port control you can configure the settings of each port to control the connection parameters, and the status of each port is listed beneath.  Port No.: The port number which you want to be configured. ...

  • Page 54: Port Status

    Port Control interface 6.13 Port Status It will show you the status of port configuration setting .

  • Page 55: Port Statistics

    6.14 Port Statistics The following chart provides the current statistic information which displays the real-time packet transfer status for each port. The user might use the information to plan and implement the network, or check and find the problem when the collision or heavy traffic occurs.
  • Page 56 Port Statistics interfac...

  • Page 57: Port - Port Alert

    Port – Port Alert 6.15 Having ticked the Syslog/SMTP checkboxes, the event log/email alert will be sent to the system log server and the SMTP server respectively. Also, Port event log/alert (link up, link down, and both) can be sent to the system log server/SMTP server respectively by setting the trigger condition.

  • Page 58: Rate Control -Rate Limit

    Rate Control –Rate Limit 6.16 You can set up every port’s bandwidth rate and frame limitation type. All the ports support port egress rate control. For example, assume port 1 is 10Mbps, users can set it’s effective egress rate is 1Mbps, ingress rate is 500Kbps. The switch performs the ingress rate by packet counter to meet the specified rate ...
  • Page 59  Storm Control: select the frame type that wants to filter. There are four frame types for selecting:   Broadcast/Multicast/Flooded Unicast  Broadcast/Multicast  Broadcast only Broadcast/Multicast/Flooded Unicast, Broadcast/Multicast and Bbroadcast only types are only for ingress frames. The egress rate only supports All type. ...

  • Page 60: Aggregation - Configuration

    6.17 Aggregation - Configuration Port trunking is the combination of several ports or network cables to expand the connection speed beyond the limits of any one single port or network cable. Link Aggregation Control Protocol (LACP), which is a protocol running on layer 2, provides a standardized means in accordance with IEEE 802.3ad to bundle several physical ports together to form a single logical channel.

  • Page 61: Configuration

    6.17.1 Configuration  Group ID: There are 5 trunk groups to be selected. Assign the "Group ID" to the trunk group.  TYPE: When choose LACP, the trunk group is using LACP. A port which joins an LACP trunk group has to make an agreement with its member ports first. Please notice that a trunk group, including member ports split between two switches, has to enable the LACP function of the two switches.
  • Page 62 Port Trunk—Aggregator Setting interface (four ports are added to the left field with LACP enabled)

  • Page 63: Aggregator - Status

    6.17.2 Aggregator – Status You can check the setting of Port aggregation in Status.

  • Page 64: Spanning Tree

    6.18 Spanning Tree The Rapid Spanning Tree Protocol (RSTP) is an evolution of the Spanning Tree Protocol and provides for faster spanning tree convergence after a topology change. The system also supports STP and the system will auto-detect the connected device that is running STP or RSTP protocol.
  • Page 65 the port concerned can only be connected to exactly another bridge (i.e. it is served by a point-to-point LAN segment), or can be connected to two or more bridges (i.e. it is served by a shared medium LAN segment). This function allows the P2P status of the link to be manipulated administratively.

  • Page 66: Rstp Information

    6.18.2 RSTP Information This web page provides the port and switch information about RSTP. RSTP System Configuration interface...

  • Page 67: Pro-Ring Ii S

    6.19 Pro-Ring II S Pro-Ring IIs is a new Ring mechanism for Lantech Industrial Switches in which it protects the network by flexible topology than ever. Pro-Ring IIs works as a Single Ring and Multiple Ring to recover the broken ring in less than 20 ms for up to 50 switch nodes..
  • Page 68 RSTP Port Configuration interface...

  • Page 69: Multicast Support

    6.20 Multicast Support The Internet Group Management Protocol (IGMP) is an internal protocol of the Internet Protocol (IP) suite. IP manages multicast traffic by using switches, routers, and hosts that support IGMP. Enabling IGMP allows the ports to detect IGMP queries, report packets, and manage IP multicast traffic through the switch.
  • Page 70 IGMP Configuration interface 6.20.2 Static Filtering Multicasts are similar to broadcasts, they are sent to all end stations on a LAN or VLAN. Multicast filtering is the function, which end stations can receive the multicast traffic if the connected ports had been included in the specific multicast groups. With multicast filtering, network devices only forward multicast traffic to the ports that are connected to the registered end stations.
  • Page 71 field and click to remove it. Delete...

  • Page 72: Lldp

    6.21 LLDP Link Layer Discovery Protocol (LLDP) is defined in the IEEE 802.1AB, it is an emerging standard which provides a solution for the configuration issues caused by expanding LANs. LLDP specifically defines a standard method for Ethernet network devices such as switches, routers and wireless LAN access points to advertise information about themselves to other nodes on the network and store the information they discover.

  • Page 73: Lldp Neighbors

    6.22.1 LLDP Neighbors It will show you the information about Port Neighbor via LLDP protocol.

  • Page 74: Filtering Database

    6.23 Filtering Database Use the MAC address table to ensure the port security. 6.23.1 Configuration  MAC Address Configuration:: Set the Aging time of MAC address table and define the event about port fail will influent the MAC table automatically or not. ...
  • Page 75 6.23.1 Dynamic MAC table You can monitor the learning status of MAC address table in this function..

  • Page 76: Vlan

    6.24 VLAN A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain, which would allow you to isolate network traffic, so only the members of the same VLAN will receive traffic from the ones of the same VLAN. Basically, creating a VLAN on a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.
  • Page 77  802.1Q VLAN Setting: Enable GVRP mode and define the Management VLAN ID. GVRP (GARP VLAN Registration Protocol or Generic VLAN Registration Protocol) is a protocol that facilitates control of virtual local area networks (VLANs) within a larger network . GVRP conforms to the IEEE 802.1Q specification, which defines a method of tagging frames with VLAN configuration data.
  • Page 78 The trunk port has to be connected to a trunk/hybrid port of the other switch. Both the tagged VID of the two ports have to be the same. 3. Hybrid Link: A segment which consists of Access and Trunk links. The hybrid port has both the features of access and trunk ports.

  • Page 79: Switch Status

    6.24.2 Switch Status You can see the status of VLAN setting in this function..

  • Page 80: Qos

    6.25 QoS Quality of Service (QoS) is the ability to provide different priority to different applications, users or data flows, or to guarantee a certain level of performance to a data flow. QoS guarantees are important if the network capacity is insufficient, especially for real-time streaming multimedia applications such as voice over IP or Video Teleconferencing, since these often require fixed bit rate and are delay sensitive, and in networks where the capacity is a limited resource, for example in cellular data communication.

  • Page 81: Port Priority

    6.25.2 Port Priority Configure the priority level for each port. With the drop-down selection item of Priority Type above being selected as Port-based, this control item will then be available to set the queuing policy for each port.  Port x: Each port has 4 priority levels—High, Middle, Low, and Lowest—to be chosen.

  • Page 82: Cos Mapping To Queue

    6.25.3 COS Mapping to Queue Set up the COS priority level. With the drop-down selection item of Priority Type above being selected as COS only/COS first, this control item will then be available to set the queuing policy for each port. ...

  • Page 83: Dscp Mapping To Queue

    6.25.4 DSCP mapping to queue Set up the DSCP priority. With the drop-down selection item of Priority Type above being selected as DSCP only/SDCP first, this control item will then be available to set the queuing policy for each port. ...
  • Page 84 highest priority.  Click to have the configuration take effect. Apply...

  • Page 85: Port Mirroring

    6.25. Port Mirroring The Port mirroring is a method for monitor traffic in switched networks. Traffic through ports can be monitored by one specific port, which means traffic goes in or out monitored (source) ports will be duplicated into mirror (destination) port. ...

  • Page 86: Security

    6.26. Security You can block the un-authorized client in this function. 6.26.1 IP Source Guard - Configuration IP Source Guard function allows the user to assign 10 specific IP addresses that have permission to manage the switch through the http and telnet services for the securing switch management.

  • Page 87: Ip Source Guard - Static Table

    6.26.2 IP Source Guard – Static Table  Security IP 1 ~ 10: The system allows the user to assign up to 10 specific IP addresses for access security. Only these 10 IP addresses can access and manage the switch through the HTTP/Telnet service once IP Security Mode is enabled. ...

  • Page 88: X/Radius

    6.26.3 802.1X/Radius 802.1x is an IEEE authentication specification which prevents the client from accessing a wireless access point or wired switch until it provides authority, like the user name and password that are verified by an authentication server (such as RADIUS server). After enabling the IEEE 802.1X function, you can configure the parameters of this function.
  • Page 89 6.26.3.2 Port Setting You can configure the 802.1x authentication state for each port. The state provides Disable, Accept, Reject, and Authorize.  Reject: The specified port is required to be held in the unauthorized state.  Accept: The specified port is required to be held in the authorized state. ...
  • Page 90 6.26.3.3 Port Status You can monitor the port Authorized state in this function.

  • Page 91: Mac Filtering

    6.26.4 MAC Filtering You can block the un-authorized MAC by switch in this function.

  • Page 92: Port Security

    6.26.5 Port Security You can block the un-authorized MAC by oer port in this function.

  • Page 93: Maintenance

    6.27. Maintenance 6.27.1 Save Configuration Save the current setting of switch .. 6.27.2 Restart Device Make the switch warm start. 6.27.3 Factory Defaults Reset switch to default configuration. Click “Reset” to reset all configurations to the default value.
  • Page 94 6.27.4 Firmware Upgrade  TFTP Server IP Address: Type in your TFTP server IP.  Firmware File Name: Type in the name of the firmware image file to be updated.  Click Upgrade You can also browser the firmware on your hard drive by web update.
  • Page 95 6.27.5 Export/Import You can restore a previous backup configuration from the TFTP server to recover the settings. Before doing that, you must locate the image file on the TFTP server first and the switch will download back the flash image. ...
  • Page 96 6.27.6 Diagnostics 6.27.6.1 Ping You can ping other network device in this function. 6.27.6.2 DDM Port No.: Specify the SFP port and show the SFP module information.  Temperature: Display the internal temperature of the SFP default threshold and present value. ...
  • Page 97  TX PWR: Display the transmission power of the SFP default threshold and present value.  RX PWR: Display the received power of the SFP default threshold and present value.  Syslog/SMTP: The port will send an e-mail or log on local to administrator when detecting the exceptional value.

  • Page 98: Troubles Shooting

    Troubles shooting  Verify that is using the right power cord/adapter (DC 24-48V), please don’t use the power adapter with DC output higher than 48V, or it may damage this device.  Select the proper UTP/STP cable to construct the user network. Use unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ-45 connections that depend on the connector type the switch equipped: 100Ω...

  • Page 99: Appendix A-Rj-45 Pin Assignment

    Appendix A—RJ-45 Pin Assignment RJ-45 Pin Assignments The UTP/STP ports will automatically sense for Fast Ethernet (10Base-T/100Base-TX connections), or Gigabit Ethernet (10Base-T/100Base-TX/1000Base-T connections). Auto MDI/MDIX means that the switch can connect to another switch or workstation without changing straight through or crossover cabling. See the figures below for straight through and crossover cable schematic.
  • Page 100  10/100Base-TX Cable Schematic The following two figures show the 10/100Base-TX cable schematic. Straight-through cable schematic Cross over cable schematic  10/100/1000Base-TX Pin outs The following figure shows the 10/100/1000 Ethernet RJ-45 pin outs.  10/100/1000Base-TX Cable Schematic...
  • Page 101 Straight through cables schematic Cross over cables schematic...

  • Page 102: Pin Assignment Of Poe

    RJ-45 Pin Assignment of PoE With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data; pins 4, 5, 7 and 8 are used for power supplying.  Pin out of Cisco non-802.3af standard PD Signal VCC - VCC -...
  • Page 103  Pin out of PoE Endspan Hub/Switch Signal / Name TX+/VCC+ TX-/VCC+ TX+/VCC- TX-/VCC- ‘+’ and ‘-‘ signs represent the polarity of the wires that make up each wire pair. Note Before you power PD, please check the RJ-45 connector pin assignment follow IEEE802.3af standard;...

  • Page 104: Appendix B-Command Sets

    Appendix B—Command Sets Commands Set List User EXEC Privileged EXEC Global configuration VLAN database Interface configuration Netstar Commands Level Description Example enable Enter Privileged EXEC switch>enable mode quit Logout command line switch>quit shell show Show switch switch>show config configuration Show system up time switch>uptime uptime disable Leave Privileged...

  • Page 105: Admin Password Commands Set

    system location Set switch system switch>enable [System Location] location string switch#configure switch(config)#system location system description Set switch system switch>enable [System Description] description string switch#configure switch(config)#system description xxx system contact Set switch system switch>enable [System Contact] contact window string switch#configure switch(config)#system contact show system-info Show system switch>show system-info...

  • Page 106: Sntp Commands Set

    192.168.1.254 ip dhcp Enable DHCP client switch>enable function of switch switch#configure switch(config)#ip dhcp show ip Show IP information of switch>enable switch switch#show ip no ip dhcp Disable DHCP client switch>enable function of switch switch#configure switch(config)#no ip dhcp SNTP Commands Set Netstar Commands Level Description Example...

  • Page 107: Lldp Commands Set

    Format:[yyyymmdd- function is inactive, switch(config)# sntp daylight- hh:mm] this command can’t be period 20120808-01:01 applied. 20120809-01:01 Parameter format: [yyyymmdd-hh:mm] ntp daylight-offset Set offset of daylight switch>enable [Minute] saving time, if SNTP switch#configure function is inactive, switch(config)#sntp daylight- this command can’t be offset 60 applied.

  • Page 108: Backup & Restore Commands Set

    show lldp Show LLDP switch>enable information switch#show lldp Disable LLDP switch>enable no lldp switch#configure switch(config)#no lldp Backup & Restore Commands Set Netstar Commands Level Description Defaults Example tftp [server IP] backup Save configuration to switch>enable [file name] TFTP and need to switch#configure specify the IP of TFTP switch(config)# tftp...
  • Page 109 192.168.1.100 dhcpserver highip Configure high IP switch>enable address for IP pool switch#configure [High IP] switch(config)#dhcpserver highip 192.168.1.200 dhcpserver subnetmask Configure subnet switch>enable [Subnet mask] mask for DHCP clients switch#configure switch(config)#dhcpserver subnetmask 255.255.255.0 dhcpserver gateway Configure gateway for switch>enable [Gateway] DHCP clients switch#configure switch(config)#dhcpserver gateway 192.168.1.254...

  • Page 110: Port Control Commands Set

    binding information of DHCP switch#show dhcpserver ip- server binding Disable DHCP server switch>enable no dhcpserver function switch#configure switch(config)#no dhcpserver Port Control Commands Set Netstar Commands Level Description Example interface fastEthernet Choose the port for switch>enable [Portid] modification. switch#configure switch(config)#interface fastEthernet 2 state Use the state interface switch>enable...
  • Page 111 port.. flowcontrol mode Configure flow control switch>enable [symmetric|asymmetric] switch#configure switch(config)#interface fastEthernet 2 switch(config-if)# flowcontrol mode asymmetric no flowcontrol Disable flow control of switch>enable interface switch#configure switch(config)#interface fastEthernet 2 switch(config-if)# no flowcontrol security enable Enable security of switch>enable interface switch#configure switch(config)#interface fastEthernet 2 switch(config-if)#security enable no security...

  • Page 112: Port Status Commands Set

    switch(config)#interface fastEthernet 2 switch(config-if)#show interface configuration Port Status Commands Set Netstar Commands Level Description Example show interface status show interface actual switch>enable status switch#configure switch(config)#interface fastEthernet 2 switch switch (config-if)#show interface status Rate Limit Commands Set Netstar Commands Level Description Example ratelimit type all Set interface ingress...

  • Page 113: Trunk Commands Set

    only limit frame type to switch#configure “only accept broadcast switch(config)#interface frame” fastEthernet 2 switch(config-if)# ratelimit type broadcast-only ratelimit in Set interface input switch>enable [kbps] bandwidth. zero switch#configure means no limit. switch(config)#interface fastEthernet 2 switch(config-if)# ratelimit in 160 ratelimit out Set interface output switch>enable [kbps] bandwidth.
  • Page 114 [Workport] list, This parameter could be a port switch(config)#aggregator group range(ex.1-4) or a port 2 1,4,3 lacp workp 3 list separate by a comma(ex.2, 3, 6) [Workport]: The amount of work ports, this value could not be less than zero or be large than the amount of member ports.

  • Page 115: Pro-Ring Iis Commands Set

    lacp 1 Remove a trunk group switch>enable no aggregator group [GroupID] switch#configure switch(config)#no aggregator group 1 PRO-RING IIS Commands Set Netstar Commands Level Description Example prorstp enable Enable PRO-RING IIS switch>enable for this interface switch#configure switch(config)#interface fastEthernet 2 switch(config-if)# prorstp enable prorstp-root Configure PRO-RING switch>enable...
  • Page 116 rstp priority [0~61440] Configure RSTP switch>enable bridge priority switch#configure parameter switch(config)#rstp priority 4096 rstp max-age [6~40] Configure RSTP max switch>enable age parameter switch#configure switch(config)#rstp max-age 6 rstp hello-time [1~10] Configure RSTP hello switch>enable time parameter. switch#configure switch(config)#rstp hello-time 1 rstp forward-time [4~30] Configure RSTP switch>enable...

  • Page 117: Vlan Commands Set

    fastEthernet 2 switch(config-if)#rstp admin-edge false rstp admin-non-stp Admin NonSTP on this switch>enable [True|False] interface switch#configure switch(config)#interface fastEthernet 2 switch(config-if)#rstp admin-non- stp false show rstp Show RSTP switch>enable information. switch#show rstp no rstp Disable RSTP. switch>enable switch#configure switch(config)#no rstp VLAN Commands Set Netstar Commands Level Description Example...
  • Page 118 [GroupID] port switch(vlan)#vlan port-based [PortNumbers] grpname test grpid 2 port 2,3,4 show vlan [GroupID] Show VLAN switch>enable information switch#vlan database show vlan switch(vlan)#show vlan 2 no vlan [VID] Delete port base switch>enable group ID switch#vlan database switch(vlan)#no vlan 2 IEEE 802.1Q VLAN Configure switch>enable vlan 8021q mnt-vid...
  • Page 119 [UntaggedVID] port belong to a trunk switch(vlan)#vlan 8021q port 3 group, this command hybrid-link untag 4 tag 3,6,8 [TaggedVID List] can’t be applied. switch(vlan)#vlan 8021q port 3 hybrid-link untag 5 tag 6-8 vlan 8021q port Assign a qinq link for switch>enable [PortNumber] VLAN by port, if the...

  • Page 120: Snmp Commands Set

    tag 6-8 vlan 8021q aggreator Assign a qinq link for switch>enable [PortNumber] VLAN by trunk group switch#vlan database hybrid-link-qinq untag [UntaggedVID] switch(vlan)#vlan 8021q aggreator 3 hybrid-link-qinq [TaggedVID List] untag 4 tag 3,6,8 switch(vlan)#vlan 8021q aggreator 3 hybrid-link-qinq untag 5 tag 6-8 show vlan [GroupID] Show VLAN...

  • Page 121: Traffic Prioritization Commands Set

    snmp snmpv3-user Create a SNMPv3 switch>enable user profile [UserID] switch#configure switch(config)#snmp snmpv3- password [Authentication user root password 123 123 Password] [Privacy Password] no snmp community- Disable SNMP switch>enable community strings switch#configure strings [Community] function switch(config)#no snmp community-strings public no snmp trap server Remove SNMP trap switch>enable setting...

  • Page 122: Igmp Commands Set

    qos priority cos Configure COS switch>enable [Priority][lowest|low|mid Priority switch#configure dle|high] switch(config)#qos priority cos 0 middle qos priority Configure COS Port switch>enable cosportdefault default switch#configure [Port][Priority] switch(config)#qos priority cosportdefault 1 1 qos priority tos Configure TOS Priority switch>enable [Priority][lowest|low|mid switch#configure dle|high] switch(config)#qos priority tos 3 high show qos...

  • Page 123: Multicast Static Filtering Table Commands Set

    igmp last-query-interval Configure Last switch>enable [1~250 tenths of a sec.] Member Query switch#configure Interval switch(config)# igmp last-query- interval 100 igmp query-interval Configure Query switch>enable [1~250 sec.] Interval switch#configure switch(config)# igmp query- interval 100 query-response-interval Configure Query switch>enable [1~250 tenths of a sec.] Response Interval switch#configure switch(config)# igmp query-...

  • Page 124: Ip Security Commands Set

    fastEthernet 2 switch(config-if)#no multicast- filtering 225.100.100.100 show multicast-filtering Show multicast switch>enable filtering table switch# show multicast-filtering IP Security Commands Set Netstar Commands Level Description Example security enable Enable IP security switch>enable function switch#configure switch(config)#security enable security http Enable IP security of switch>enable HTTP server switch#configure...

  • Page 125: Port Security Commands Set

    switch(config)#no security telnet no security snmp Disable IP security of switch>enable SNMP server switch#configure switch(config)#no security snmp Port Security Commands Set Netstar Commands Level Description Example mac-address-table static Configure MAC switch>enable hwaddr address entry of switch#configure [HW-Addr] interface (static). switch(config)#interface fastEthernet 2 switch(config-if)#mac-address- table static hwaddr...

  • Page 126: Commands Set

    filter hwaddr MAC address table switch#configure [HW-Addr] (filter) switch(config)#no mac-address- table filter hwaddr 000012348678 802.1x Commands Set Netstar Commands Level Description Example 8021x enable Enable IEEE802.1x switch>enable function switch#configure switch(config)# 8021x enable 8021x system radiusip Use the 802.1x switch>enable system radius IP switch#configure [Radius Server IP] global configuration...
  • Page 127 8021x misc quietperiod Use the 802.1x misc switch>enable [Seconds] quiet period global switch#configure configuration switch(config)# 8021x misc command to specify quietperiod 10 the quiet period value of the switch. 8021x misc txperiod Use the 802.1x misc switch>enable TX period global switch#configure [Seconds] configuration...

  • Page 128: Fault Alarm Commands Set

    | authorize] configuration switch(config)#interface command to set the fastethernet 3 state of the selected switch(config-if)#8021x portstate port. authorize show 8021x Displays a summary of switch>enable the 802.1x properties switch#show 8021x and also the port sates. no 8021x Disable 802.1x switch>enable function switch#configure switch(config)#no 8021x...
  • Page 129 systemlog ip Set System log server switch>enable [IP address] IP address. switch#configure switch(config)# syslog ip 192.168.1.100 show syslog Show SYSLOG switch>enable configuration and log switch#configure table. switch#show syslog Disable systemlog switch>enable no syslog functon switch#configure switch(config)#no syslog smtp enable Enable SMTP function switch>enable switch#configure switch(config)#smtp enable smtp serverip...
  • Page 130 smtp password Configure switch>enable [password] authentication switch#configure password switch(config)#smtp password 1234 smtp rcptemail Configure Rcpt e-mail switch>enable [Index] [Email address] Address switch#configure switch(config)#smtp rcptemail 1 Alert@test.com show smtp Show the information switch>enable of SMTP switch#show smtp no smtp Disable SMTP switch>enable function switch#configure...

  • Page 131: Mac Address Table Commands Set

    show event Show event selection switch>enable switch#show event Disable device restart switch>enable no event device-restart [Syslog|SMTP|Both] event type switch#configure switch(config)# no event device- restart both no event authentication- Disable Authentication switch>enable failure event typ switch#configure failure [Syslog|SMTP|Both] switch(config)#no event authentication-failure both no event syslog Disable port event for switch>enable...

  • Page 132: Port Statistics Commands Set

    table switch(config)#no mac-address- table Configure mac switch>enable agingtime [seconds 0~3825 steps 15] address table aging switch#configure time switch(config)#agingtime 30 auto-flush Auto flush mac switch>enable [enable|disable] address table when switch#configure ports link down switch(config)#auto-flush enable Port Statistics Commands Set Netstar Commands Level Description Example show interface...

  • Page 133: System Event Log Commands Set

    switch(config-if)#monitor source Show port monitor switch>enable show monitor information switch#show monitor show monitor Show port monitor switch>enable information switch#configure switch(config)#interface fastEthernet 2 switch(config-if)#show monitor no monitor Disable source port of switch>enable monitor function switch#configure switch(config)#interface fastEthernet 2 switch(config-if)#no monitor System Event Log Commands Set Netstar Commands Level Description Example...
  • Page 134 event loadavg Set system load switch>enable [Systemlog|SMTP|Both] average event type switch#configure switch(config)# event loadavg both Power over Ethernet Commands Set Netstar Commands Level Description Example Enter POE configure switch>enable mode switch#poe Set PoE system Port switch>enable system knockoff- disabled Knockoff Disabled switch#poe [Enable|Disable] switch(poe)# system knockoff-...
  • Page 135 Set PoE port Legacy switch>enable port [PortNumbers] switch#poe legacy [Enable|Disable] switch(poe)# port 1 legacy enable port [PortNumbers] Set PoE port Priority switch>enable priority switch#poe [Low|High|Critical] switch(poe)# port 1 priority high Set PoE auto-ping switch>enable Enable switch#poe autoping enable switch(poe)#autoping enable autoping Set PoE auto-ping switch>enable...

  • Page 136: Save Configuration Commands Set

    switch#show poe Save Configuration Commands Set Netstar Commands Level Description Example write memory Save user switch>enable configuration into switch#write memory permanent memory (flash rom) Factory Default Commands Set Netstar Commands Level Description Example default Restore to factory switch>enable default configuration switch#configure [keepip|keepadmin|both switch(config)#default both...

Table of Contents
