Configure the SHDSL Network Interface
For the Master Unit:
1. At the (config)# prompt, enter interface shdsl 1/1 to activate the interface configuration
mode for the SHDSL network interface.
2. Enter equipment-type co to configure the unit to source timing into the SHDSL network
connection. Use this option in a campus environment when operating two SHDSL network
interface modules (NIMs) back-to-back.
3. Enter linerate 2312 to define the line rate for the SHDSL interface for the CO side.
4. Enter no shutdown to activate the SHDSL interface.
5. Enter exit to return to the Global Configuration mode.
For the Slave Unit:
1. At the (config)# prompt, enter interface shdsl 1/1 to activate the interface configuration
mode for the SHDSL network interface.
2. Enter equipment-type cpe. Use this option when interfacing directly with your service
provider or when acting as the slave NIM in a campus environment.
3. Enter no shutdown to activate the SHDSL interface.
4. Enter exit to return to the Global Configuration mode.
Configure the Virtual PPP Interface
The following steps show how to configure a PPP virtual interface to the corporate router for the
master unit.Enter interface fr 1 to create a Frame Relay virtual interface labeled 1.
1. At the (config)# prompt, enter interface ppp 1 to create a PPP virtual interface labeled 1.
2. Assign an IP address to the PPP endpoint using a 30-bit mask.
•
Master: Enter ip address 192.168.72.2 255.255.255.252
•
Slave: Enter ip address 192.168.72.1 255.255.255.252
3. Enter no shutdown to activate the PPP interface.
4. Enter exit to return to the Global Configuration mode.
Create the Cross-Connect
For both the master and slave units, enter cross-connect 1 shdsl 1/1 ppp 1 to connect the
SHDSL network connection (shdsl 1/1) to the virtual PPP interface (ppp 1).
Configure the Routes
Depending on your network setup, configure your unit's static route to the far side/Internet
access at the local site beginning at the (config)# prompt.
Set up the default route (i.e., address of internet router).
•
Master: ip route 10.10.20.0 255.255.255.0 192.168.72.1
•
Slave: ip route 0.0.0.0 0.0.0.0 192.168.72.2
64200867L1-42B
Technical Support 1-888-4ADTRAN (1-888-423-8726)
3
