NetVanta
Series
(with SHDSL Network Interface Module)
Quick Configuration Guide
Equipment Required
•
Category 5 - UTP cable for connecting the system to the existing network.
•
VT100 terminal or PC with VT100 emulation software.
•
DB-9 (male) to DB-9 (female) straight-through serial cable for configuring the unit.
This quick configuration guide provides step-by-step instructions for configuring
your application. The configuration scripts are available on the ADTRAN OS
Documentation CD.
The configuration parameters used in the example outlined in this document are for
instructional purposes only. Please replace all underlined entries (example) with your
specific parameters to configure your application.
Network Diagram
Connection Diagram
Branch Office
PBX
VPN
VPN
WAN
WAN
LAN
LAN
PWR
PWR
STAT
STAT
TD
TD
RD
RD
TD
TD
RD
TD
RD
RD
NetVanta
eth 0/1
LAN IP: 10.10.20.7/24
Configure the Unit
The NetVanta may be initially accessed and managed either via a console session or through a
Telnet session. See Initiate a Console Session on page 2 for instructions. Initiating a Telnet
session requires using a hub and two Ethernet cables (one for the PC and one for the unit). The
default Ethernet IP address is 10.10.10.1. Refer to Configure a Telnet Session on page 4 to
change Telnet session settings.
64200867L1-42B
t1 1/2
t1 1/1
NetVanta 3200
DS0s 1-10 Data,
21-24 Voice
FR 1
DLCI 16
Annex D Signaling
192.168.72.1/30
Technical Support 1-888-4ADTRAN (1-888-423-8726)
Corporate HQ
LAN IP: 10.10.10.1/24
WAN IP: 192.168.72.2/30
November 2004
Advertisement
Table of Contents
Related Manuals for ADTRAN NetVanta Series
Summary of Contents for ADTRAN NetVanta Series
- Page 1 DB-9 (male) to DB-9 (female) straight-through serial cable for configuring the unit. This quick configuration guide provides step-by-step instructions for configuring your application. The configuration scripts are available on the ADTRAN OS Documentation CD. The configuration parameters used in the example outlined in this document are for instructional purposes only.
- Page 2 NetVanta. You must change the IP address of your PC before you can proceed. ADTRAN recommends that you set the Ethernet speed and duplex to match the switch or hub into which it is plugged. For example:...
- Page 3 Configure the SHDSL Network Interface For the Master Unit: 1. At the (config)# prompt, enter interface shdsl 1/1 to activate the interface configuration mode for the SHDSL network interface. 2. Enter equipment-type co to configure the unit to source timing into the SHDSL network connection.
- Page 4 Configure a Telnet Session The following steps show how to access the Telnet configuration parameters and change the password. The default password for initializing a Telnet session is password (all lowercase). For security purposes, change the password to something unique. For this example, replace the underlined word with a password of your choosing.
