- Page 1 Installation Instructions / Warranty Metris S Metris S Metris S 31063XX1 31067XX1 31263XX1 Metris S Talis S Focus S 31267XX1 32310XX1 31730001...
- Page 2 31063XX1 31067XX1 31263XX1 31267XX1...
- Page 3 32310XX1 31730XX1...
- Page 4 Technical Information / Données techniques / Datos tecnicos Recommended water Pression d’eau recommandée Presión recomendada en 1.7 - 72.5 psi pressure servicio Max. water pressure Pression d’eau maximum Presión en servicio max. 17 psi Recommended hot water Température recommandée Temperatura recomendada del 120�...
-
Page 5: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that • This faucet requires ½" hot and cold supply this unit be installed by a licensed, profes- lines (not included). sional plumber. • Keep this booklet and the receipt (or other •... -
Page 6: Installation
English Note: To prevent shipping damage, the spout is 2.5 mm attached to the spout escutcheon with two adhesive strips. Remove the strips before installing the spout. adhesive strips bandes adhésives tiras adhesivas Installation rouge For proper operation of the faucet, the hot rojo supply must be on the left, and the cold supply must be on the right. -
Page 7: Instalación
Français Español Avis: Aviso: Pour empêcher les dommages d’expédition, le Para prevenir envío daño, el surtidor es conectado bec est attaché à la rosace avec deux bandes al de escudete con dos tiras adhesivas. adhésives. Quite las tiras antes de instalar el surtidor. Enlevez les bandes avant installer le bec. - Page 8 English Place the handles over the valve mounting nuts. Tighten the handles by rotating the escutch- eons clockwise. The handles should be parallel to the basin. If necessary, remove, rotate, and reinstall the handle.
- Page 9 Français Español Placez les poignées sur les écrous de montage Coloque las manijas sobre las tuercas de montaje des valves. de las válvulas. Serrez les poignées en tournant les rosaces dans Apriete las manijas girando los escudetes en le sens horaire. sentido horario.
- Page 10 English Rotate the spout escutcheon if necessary, so that the hole for the pull rod is at the rear. Place the spout on the mounting surface. Install the fiber washer, metal washer, and mounting nut. Tighten the mounting nut. Tighten the tensioning screws. Screw the connecting hoses into the spout tee.
- Page 11 Français Español Si nécessaire, faites tourner la rosace du bec de Gire el escudete del surtidor si fuera necesario, de façon à ce que le trou de la tirette soit situé à modo que el orificio para el tirador quede hacia l’arrière.
- Page 12 English Install the pop-up drain Remove the plunger. Unscrew the drain outlet flange from the tee. Unscrew the tailpiece from the tee. Wrap the threads with Teflon tape. Install the tailpiece on the tee. Install the sealing gasket on the flange. Rest the flange in the sink outlet.
- Page 13 Français Español Installez l’obturateur à clapet Instale el tapón elevable Retirez le plongeur. Retire el émbolo. Dévissez la collerette de l’obturateur du raccord Desenrosque la brida de salida del drenaje del en T. tubo en “T”. Dévissez la queue du raccord en T. Desenrosque la alcachofa del tubo en “T”.
- Page 14 Replacement Parts / Pièces détachées / Repuestos 1, 20 Metris S...
- Page 15 Talis S Focus S...
- Page 16 hot handle poignée eau chaude mando agua caliente 7503XX0 cold handle poignée eau froide mando agua fría 7502XX0 complete valve robinet d’arrêt cpl. válvula completa 7357001 hot cartridge mécanisme eau chaude montura augua caliente 00001 cold cartridge mécanisme eau froide montura agua fría 00001 connection hose...
- Page 17 Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Faucets and Showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 18 Nettoyez vos produits de robinetterie et de douche aussi souvent que nécessaire. • Utilisez la quantité de produit nettoyant et respectez la durée recommandée par le fabricant. Ne laissez pas le produit sur les articles de robinetterie plus longtemps que nécessaire. •...
-
Page 19: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe"). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 16, and installed in either the United States or Canada. - Page 20 Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
