Air Filtration; Changing The Filter - Santa Fe IMPACT Series Installation & Operation Instructions

Air Filtration

The Santa Fe Impact155 is equipped with a MERV-13 filter. An optional MERV-11 filter is available at
www.ThermastorFilters.com. The filter should be checked and replaced every three to six months. Operating
the unit with a dirty filter will reduce dehumidifier capacity and efficiency.
DO NOT operate the unit without the standard MERV-13 filter or optional MERV-11 filter. Filter non-compliance
voids the product warranty.
CAUTION!
MAKE SURE UNIT IS OFF BEFORE CHANGING THE FILTER. FAILURE TO FOLLOW FILTER HANDLING INSTRUCTIONS MAY
RESULT IN IMPROPER FUNCTION OF THE DEHUMIDIFIER AND CAUSE PREMATURE FILTER WEAR OR UNIT DAMAGE.

Changing the Filter

For greatest filtration and efficiency of the Santa Fe Impact155, it is recommended the air filter be
replaced every three to six months with a MERV-13 filter.
Step 1: Release the latch from the
cabinet by pulling it down and out.
Remove the filter door by pulling it
out of the bottom tab.
Step 2: Remove the filter by gently pulling it straight out of the unit. Insert new filter by gently
pushing it straight into the unit. Make sure the AIR FLOW arrow on the filter is pointing into the unit.
Step 3: Insert filter door into bottom
tab. Push latch down and swing door
shut. Once the door is shut, release
the latch.
10
Santa Fe Impact155 Installation & Operation Instructions
To Remove,
pull out straight.
Filter Filter
Front View
To Replace,
push in straight.
Filter Filter
Front View
Bottom
Tab
MERV-8 Filter
