ULTRA SERIES | ULTRA155/205
Installation Instructions
Español
Versión
La Página
24
The Santa Fe Ultra155/205 Dehumidifiers are
ventilating dehumidifiers that integrate into the
heating and cooling system to provide the ultimate
in comfort, health and property protection through:
+ Dehumidification
+ Optional Outdoor Air Ventilation
+ Air Filtration
* Previously the Ultra Aire 155H/205H.
800.533.7533 | Santa-Fe-Products.com
Santa-Fe-Products.com | 800.533.7533
Serial Number
Install Date
Sold By
Patent: thermastor.com/patents
Santa Fe ULTRA155/205 Installation & Operation Instructions
1
TS-2019 02/23 Rev A
